Installation Settings Guide
In this guide we will describe the advanced
installation settings that you can access from
KONOz's main menu. We recommend that
an HVAC service professional uses these settings
to fine-tune your thermostat's performance for
your home.
You can access the installation settings by going to
the main menu and selecting the gear icon. You
will see "IS" on the screen and will be prompted to
select "yes" or "no". Select "yes" to access the
installation settings. Rotate the knob to view
settings and press the knob to confirm.
Once in the installer settings, rotate the knob to
change a setting value. Press the knob to confirm
the new value and proceed to the next option.
There are three ways to exit the settings:
1. Continue through the remaining settings until you
pass setting 99.
2. Press and hold the knob for 3 seconds after you
confirm any changes to your settings.
3. Wait 60 seconds after you confirm any changes
to your settings.
System Type & Configuration
You will first see your current system type and configuration – confirm by pressing the knob
and then you will begin navigating through the available settings.
HVAC system type
F = Furnace
HP = Heat Pump
All manuals and user guides at all-guides.com
Available System
Modes
HVAC system subtype
Furnace Systems
ELEC: Electric fan. Thermostat calls fan
to run with heat
GAS: Gas fan. Thermostat does not call
fan to run with heat
BOIL: Boiler. No fan connected to
heating system
Heat Pump
o: Changeover valve = O
b: Changeover valve = B
Installation Settings Guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LUX KONOz
Summary of Contents for LUX KONOz
- Page 1 All manuals and user guides at all-guides.com Installation Settings Guide In this guide we will describe the advanced installation settings that you can access from KONOz’s main menu. We recommend that an HVAC service professional uses these settings to fine-tune your thermostat’s performance for your home.
- Page 2 C for Celsius -02 Temperature Calibration KONOz is factory calibrated, but you can use this setting to adjust the temperature sensor for your home. The screen will alternate between your calibration temperature and the offset value – to remove calibration, make sure that the offset value is set to 0.
- Page 3 All manuals and user guides at all-guides.com -04 Maximum Heat Limit Use this setting to set a maximum temperature limit for your heating system. The limit can be as high as 90°F (32°C) or as low as 60°F (15°C). *Note: Not available for cool only systems Default Temperature: 90°F -05 Minimum Heat Limit Use this setting to set a minimum temperature limit for your heating system.
- Page 4 All manuals and user guides at all-guides.com -07 Minimum Cool Limit Use this setting to set a minimum temperature limit for your cooling system. The minimum cool limit range is dependent on the values you entered for your heating and cooling limits. Default Temperature: 50°F -08 System Type Use this setting to modify the system type.
- Page 5 Use this setting to set a swing value. Your swing setting determines how far the ambient Temperature can deviate from the set temperature before KONOz turns on your heating or cooling system. You can select 0, .25°, .5°, 1° or 2.25°.
- Page 6 All manuals and user guides at all-guides.com -13 Stage 2 (Auxiliary) Heating Offest (for heat pump systems) Use this setting to set a value that your thermostat will use to decide when to turn on your second stage of heating. You can select Off, 1, 2, 3, 4 or 5 degrees F. Off, no second stage heat 1°...
- Page 7 Compressor Bypass On Compressor Bypass Off -99 Factory Reset Use this setting to initiate a factory reset and to setup your KONOz from scratch. Reset KONOz Do Not Reset KONOz Installation Settings Guide...
- Page 8 -Additional Features Lock: Press and hold the knob for 10 seconds on the main run screen to lock local control of KONOz. When locked, press and hold the knob for 10 seconds to unlock. Power Cycle: Remove KONOz from its base and locate the black reset button on the back of the thermostat.
