Page 1 BiJie meeting box Type BJ60S user's manual November, 2020, Edition A...
Page 2: Table Of Contents
Content 1 Product Information............................... 4 1.1 Equipement packaging............................6 1.2 Equipement Interface............................7 1.3 Device connection............................... 7 1.3.1 AP hotspot connection........................7 1.3.2 STA/wired connection........................8 2 Display box setting................................. 9 ......................................9 2.1 System information presentation........................9 2.1.1 Discover mode interface.........................10 2.1.2 Short code mode interface......................
Page 3 Content 2.9.1 Select language..........................21 2.9.2 Wireless display mode........................22 2.9.3 Picture scale............................24 2.9.4 Competion mode..........................24 2.9.5 Maximum number of screens...................... 25 2.9.6 Authorized access function......................26 2.9.7 Miracast HDCP..........................26 2.9.8 Miracast channel..........................27 2.9.9 Reboot plan............................28 2.9.10 Restart now.............................29 2.9.11 NTP server............................
Page 4 Safety precautions Note Before using BJ60S meeting box, please read this manual carefully and keep it properly for future reference. To turn off the main power supply, the plug must be pulled out of the power socket.The power socket should be installed close to the wireless equipment, which is easy to operate.
Page 5 Important Information Important safety measures These safety instructions can maintain a long service life of BiJie meeting box and prevent fire and electric shock. Please read carefully and pay attention to all warnings. install Please do not place the BiJie meeting box in the following environment: ...
Page 6 Important Information Under the following circumstances, it is necessary to turn off the meeting box, unplug the power cord and ask  qualified maintenance personnel to repair the equipment:  The power cord or plug is damaged or worn;  There is liquid flowing into the equipment or the equipment is exposed to rainwater; ...
Page 7: Product Information
Product Instructions Product Information BJ60S meeting box is an enterprise level wireless display device. It is compatible with Airplay, Miracast, WiDi and BJCast wireless display protocols. It supports smart phones and PC computers to conduct screen image and display on the same screen through wireless way.
Page 8 Product Instructions...
Page 9: Equipement Packaging
：Widi (Intel Wireless Display) is the full name of wireless high-definition technology. It realizes the wireless connection between computer and display device through WiFi signal. ④ 4.BJCast ： BJCast protocol is a wireless display protocol independently developed by our company, which supports the transmission and sharing of mirror images between mobile devices. 1.1 Equipement packaging Product...
Page 10: Equipement Interface
Product Instructions 1.2 Equipement Interface Interface name Interface number front LED indicator light * 1 USB interface*1 3.5mm audio output interface * 1 Left LAN*1 Reset key*1 Power button*1 HDMI video output interface*1 back USB interface*1 DC5V interface*1 1.3 Device connection 1.3.1 AP hotspot connection Connect the meeting box and TV (or projector) through HDMI cable, and the display box will be powered on.
Page 11: Sta/Wired Connection
Product Instructions 1.3.2 STA/wired connection Connect the meeting box and TV (or projector) through HDMI cable, and the display box will be powered on. The meeting box can be set to STA mode (connected to the internal LAN through WiFi), or directly plug in the network cable to connect the meeting box to the internal network of the enterprise.
Page 12: Display Box Setting
Product Instructions Display box setting 2.1 System information presentation After the meeting box is turned on successfully, the presention device can present the system configuration information of the machine. BJ60 has "discovery mode" and "short code mode". "Discovery mode" and "short code mode" can be switched through the design menu. Function / mode Discovery Short code...
Page 13: Discover Mode Interface
Product Instructions 2.1.1 Discover mode interface ① ② ③ Functional area illustration Device / hotspot:The device name and AP hotspot SSID name of the machine, and the Infomation device name should be consistent with the AP hotspot name; presentation Hotspot password：Log in the the wireless password of the local AP hotspot; IP address：IP address information of the device Operating Simple operation instruction wallpaper...
Page 14: Short Code Mode Interface
Product Instructions wallpaper Connect the USB port of the display box with the mouse, and click the setting button to set Setting key and adjust the parameters of the display box 2.1.2 Short code mode interface...
Page 15: Display Box Configuration Interface
Product Instructions Functional area illustration The short code is only applicable to the "short mode" using the client mode, and the client Short code only needs to input the short code to complete the display. (the short code mode requires that the box can be connected with the cloud management platform in real time) Infomation Device / hotspot: the device name of the machine;...
Page 16: Configuration Interface
Product Instructions 2.2.2 Configuration interface Click the configuration button in the lower left corner of the system home page to enter the display box configuration interface. (the display box is in the configuration interface and cannot be displayed). 2.3 Device ID Click "device ID"...
Page 17: Wallpapers
Product Instructions 2.4 Wallpapers Users can customize and change the desktop wallpaper of the display device. Prepare a USB flash disk, copy the wallpaper into the USB disk, and insert it into the USB interface of the display box. Click "desktop wallpaper" with the mouse, you can customize the wallpaper of the display box.
Page 18: Interface Setting
Product Instructions 2-10 2.5 Interface setting The user can customize the display information of the screen projection device: suspension window information, home page QR code, home page AP password, wallpaper scrolling function, home page IP, and screen projection...
Page 19 Product Instructions device information. 2-11 2-12...
Page 20: Wired Network
Product Instructions 2.6 Wired network When the display box is inserted into the wired network, the box will automatically present the network connection status. 2-13 2.7 WiFi network The "WiFi network" setting can adjust the working mode of the local wireless module, which can be set to"AP mode"...
Page 21: Ap Mode
Product Instructions 2-14 2.7.1 AP mode In AP mode, the hotspot name is consistent with the local device name, and the AP hotspot connection password can be customized. At the same time, the channel of AP hotspots can be customized. 1 ~ 11 is 2.4G bchannel, 153 ~ 161 is 5G channel.
Page 22: Sta Mode
Product Instructions 2-15 2.7.2 STA mode In STA mode, the wireless display box will automatically search for the wireless network that can be connected, so customers can choose the connection according to their need. To disconnect the WiFi connection, please select the currently connected WiFi network with the mouse, left click and long press to pop up the dialog box, and follow the prompts.
Page 23: About Us
Product Instructions 2.8 About us 2-17 2.9 More settings 2-18...
Page 24: Select Language
Product Instructions 2-19 2.9.1 Select language Users can set the system language of the display box to "simplified Chinese", "traditional Chinese" "English"and "French".
Page 25: Wireless Display Mode
Product Instructions 2-20 2.9.2 Wireless display mode The settings of "discovery mode" and "screen projection mode" can be switched.
Page 26 Product Instructions 2-21 2-22 If the screen projection device needs to support the unified management platform, the IP address of the service platform should be filled in the server address of the cloud management platform. 2-23...
Page 27: Picture Scale
Product Instructions 2.9.3 Picture scale The display ratio of the screen projection can be adjusted. There are two modes of "normal" and "full". 2-24 2.9.4 Competion mode Turn on the competion mode. When the user starts to wireles display, the previous user will be kicked out of the screen display.
Page 28: Maximum Number Of Screens
Product Instructions 2-25 2.9.5 Maximum number of screens The maximum number of screens can be set to the number of screen projection devices at the same time, and the maximum support is 2 split screen.
Page 29: Authorized Access Function
Product Instructions 2-26 2.9.6 Authorized access function The authorized access function supports whether the user authorizes to present the screen on the monitor. 2-27 2.9.7 Miracast HDCP Miracast HDCP turn on the button, click to open“Miracast HDCP” function.
Page 30: Miracast Channel
Product Instructions 2-28 2.9.8 Miracast channel The screen projection equipment supports the replacement of Miracast projection frequency band channel adjustment. 2.4G band：1~11 channel 5.8G band：149~161 channel...
Page 31: Reboot Plan
Product Instructions 2-29 2.9.9 Reboot plan Wireless display device support customize restart plan. 2-30...
Page 32: Restart Now
Product Instructions 2.9.10 Restart now Wireless display device support restart now. 2-31 2.9.11 NTP server Set the screen projection box time and network time synchronization.
Page 33 Product Instructions 2-32...
Page 34: Terminal Wireless Display Instructions
(or use the shortcut of Android screen drop-down menu) can start the wireless presentation function of the mobile phone, then select the BJ60S device and connect, and the mobile phone screen will be displayed on the display device synchronously.
Page 35: Android Device App Display
Product Instructions 3.2 Android device APP display 1) Scan the QR code of the system page of the wireless display device and download the APP display software 2) Install "wireless display APP". 3) According to the APP prompt, select the display device and start the image display QR code scanning button, scanning QR code to wireless display The setting key can adjust the setting parameters of the client Input box:...
Page 36: Airplay On Ios Device
The wireless same screen function of iOS intelligent terminal adopts the Airplay mode to display. BJ60S meeting box supports iPhone and iPad wireless same screen of IOS 7.0 and above systems. When displaying, it is necessary to ensure that the iOS device and the display box must be connected to the same router, or the IOS device is directly connected to the AP hot network of the display device.
Page 37: Windows8/10 Widi Display
“Stop display” button 3.5 Windows8/10 WiDi display Widi display mode is the wireless display function of Windows 8 and windows 10 notebook computers. BJ60S BiJie meeting box is compatible with WiDi display protocol. Users can directly display without installing any software...
Page 38: Windows Pc Client Software Display
Product Instructions and hardware. Click the notification bar in the lower right corner of the computer screen, click the "connection" function, or press the shortcut key "win" + "K" to call up the display interface; The system automatically scans the wireless presentation device, selects the presentation device that needs to be displayed, and then click the connection to start the display.
Page 39: Airplay On Mac Os
Product Instructions Input box: In the discovery mode, input the IP address of the display device to directly connect the device to display; In the mode of short code mode: input the short code to directly connect the device for display. Equipment for display Start display button Software interface minimization...
Page 40: Mac Os Pc Client Software Display
Product Instructions 3.8 Mac OS PC client software display install "wireless display" PC client software, which can be downloaded from the official website of the product; Ensure that the Mac computer and the display device are in the same LAN; According to the client's prompt, select the display device and start the image display;...
Page 41: Usb Transmitter Display
“Exit” software button 3.9 USB transmitter display BJ60S meeting box is compatible with USB transmitter. (USB transmitter to be purchased separately) 1) Insert the USB transmitter into the USB port of BJ60 display box for pairing, and pull out the USB transmitter when the system presents "pairing succeeded";...
Page 42: Troubleshooting
Product Instructions 4 Troubleshooting 1）How to display across network segments The meeting box and transmitter must be in one network segment to automatically search display. Cross network segment networking under layer 3 switch: when the receiver is in the discovery mode, the user needs to manually input the device IP to display;...
Page 43 Product Instructions 10240-1507 display is not supported 14393-1607 16299-1709 17134-1803 17763-1809 normal 6) Press the win + K key to search for the device to display the screen. If you are prompted that Miracast is not supported, you can use the driver wizard to check whether the network card and video card are updated, and if the windows update does not take effect, WiDi will not be able to display the screen.
