Adphox BME-200 Manual

What is Binaural Recording?
A recording method to set two microphones
in ears to reproduce a 3 - D stereo sound
through headphones.
Binaural recording can capture
exactly what you hear.
BME-200
Microphone Features
•
Characteristics to capture the sound evenly from the low to high ranges,
even the dynamic sound of steam locomotives
•
Windscreens essential for outdoor recordings are attached
•
Highly sensitive microphones can capture not only the sound but also the
surrounding atmosphere
•
Great delity even for the most complex sounds such as crashing waves and
zz of tiny bubbles
BME-200
Earphone Features
•
Designed to tolerate ampli cation up to 50dB without howling,
enabling to monitor the stable sound while recording
•
Highly sensitive to reproduce the sound even in the tiniest details
BME - 200
Main Features
Microphone
Type Omnidirectional Electret Condenser
Impedance
1.6 k
Sensitivity 36.5dB
Max Input Sound Pressure Level 105dB S.P.L
Frequency Characteristics 30 - 20,000Hz
Power Plug-in Power ( 1.5-10V )
Earphone
Type
Closed Dynamic Inner-Ear
Driver Diameter 13.5mm
Impedance 19
Sound Pressure Sensitivity 112dB / mW
Max Input
50mW
Frequency Characteristics 100-10,000Hz
Plug
Frequency Characteristics of Microphone Unit of BME-200
Gold-Plated Stereo Mini Plug
( Microphone / Earphone )
Accessories
10dB
•
Earpads 3 pairs 6 pcs
( Sizes: Large, Medium, Small )
•
Windscreens
• 20 50 100 200
Leather Pouch
R D / Manufacturing
& 7F, TOMI TOWER, 10-6-1, Kabe-machi,
Ome-city, Tokyo 198-0036 JAPAN
adphox
COR PORATION
http : //www.adphox.co.jp
Distributing Agent
* Information in this brochure is current as of November 2018.
Appearance and specifications of the product
BME-200 & Accessories
Actual Image
5000 10000 20000 ( Hz )
500 1000 2000
mail@adphox.co.jp
are subject to change without notice.
VIVIDLY RECORD AS YOU HEAR
Binaural Microphone & Earphone
BME - 200
Microphone
Earphone
Windscreen
