- Page 1 NH3 KIT ASSEMBLY GUIDE MIINST NH3 KIT GUIDE...
- Page 2 We’ve done our best to ensure the accuracy of this guide. It is intended to assist you in installing various manufacturer’s components. In no event will DyTerra be liable to any party for any direct, indirect, special or other consequential damages related to the use of this Assembly Guide.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SETTING UP AN NH3 KIT ......................2 CONTINENTAL SUPERFLOW ......................4 CONTINENTAL COOLER BREAKDOWN ................... 5 RAVEN COOLER ......................... 6 CONTINENTAL METER SETUP ...................... 7 MVD MANIFOLD - NO SECTION CONTROL ..................8 MVD MANIFOLD - SECTION CONTROL ................... 9 JOHN BLUE MANIFOLD - NO SECTION CONTROL ................10... -
Page 4: Setting Up An Nh3 Kit
Cut a piece of hose to fit between the splitter and the furthest manifold. According to the manifold assembly instructions, all other hoses should be cut the same length as your longest hose. Failing to do so will distribute NH3 unevenly to each manifold, which will result in streaking. - Page 5 Q. Why are people using smaller EVA hose from their manifolds to the ground? What are the advantages? A. Smaller diameter EVA hose will increase the pressure in the lines. This will keep the NH3 liquid for longer which will cause less frost. The increase in pressure will also prevent tubes from plugging up.
-
Page 6: Continental Superflow
CONTINENTAL SUPERFLOW CONTINENTAL SUPERFLOW WITH RAVEN VALVES AND FLOWMETER Part Part Number CTA - SF-3000GT A Continental Superflow Cooler B Raven Fast Valve 1" RV1-063-0173-878 C Raven Flowmeter RV1-063-0173-867 D 1½" Strainer MIPAGET24-100 E 1½" Ball Valve BVSS243... -
Page 7: Continental Cooler Breakdown
CONTINENTAL COOLER BREAKDOWN O - Ring included in CTA - SF - RK A - SF-1 A - SF-2 Base Barb #7550(4) Bleeder Bolt Valve #09-375-125 (4) #A-411 (2) Screw #A-400-250 Hose Barb O - Ring #A-1132 included in CTA - SF - RK... -
Page 8: Raven Cooler
RAVEN COOLER 2-valve cooler shown below Part Part Number A Vortex Cooler RV1-063-0173-663 B RAVEN Flowmeter RV1-063-0173-869 C RAVEN Flowmeter Sensor RV1-063-0171-669 D Gruvlock Coupling RV1-333-0006-032 E 0-400 PSI Liquid Gauge PGA4004L F RAVEN Control Valve RV1-117-0171-706 G RAVEN On-Off Valve RV1-117-0171-705 H Strainer Kit RVS08... -
Page 9: Continental Meter Setup
CONTINENTAL B-9500 METER SETUP CTB-9500-B MICMS24... -
Page 10: Mvd Manifold No Section Control
MVD MANIFOLD NO SECTION CONTROL Gauge MVD Manifold Product In King Nipple Product Out Stand HELPFUL POINTERS · Use thread tape and thread sealant when installing the king nipple... -
Page 11: Mvd Manifold Section Control
MVD MANIFOLD SECTION CONTROL On/Off Gauge Valve MVD Manifold Product In Hoseclamp Product Out Stand Q. Where should I mount my section on/off valves? Why? A. Mounting your section on/off valves at the manifold ensures a quicker on/off response time for each section. -
Page 12: John Blue Manifold No Section Control
JOHN BLUE MANIFOLD NO SECTION CONTROL Impellicone Manifold Gauge Product Out 6” Nipple Product In King Nipple Stand HELPFUL POINTERS · Use thread tape and thread sealant when installing connecting plumbing · Use thread sealant when installing ¼” plumbing and hosebarbs... -
Page 13: John Blue Manifold - Section Control
MVD MANIFOLD SECTION CONTROL Impellicone Manifold Pressure Gauge Product Out On/Off Valve 6” Nipple 4” Nipple Hoseclamp Stand Q. Where should I mount my section on/off valves? Why? A. Mounting your section on/off valves at the manifold ensures a quicker on/off response time for each section. -
Page 14: John Blue Splitter
Q. Do hoses from the manifolds to the ground have to be uniform in length? A. Yes. Failing to do so will distribute NH3 unevenly to each run, which will result in streaking. Q. Can I plug my splitter ports? A. -
Page 15: Check Valve Section Control Only
Q. Why does my Raven Accuflow have 2 valves? Why is this advantageous? A. The first valve is a control valve which regulates what rate you are applying NH3 at. The second valve is an on/off valve that allows you to quickly stop or start applying NH3. The advantage of having two valves is that when you turn the system off or on, the valve that controls your rate does not move, and will not have to “search”... -
Page 16: High Flow Breakaway Kit
HIGH FLOW BREAKAWAY Flo Max Breakaway EZ Bracket FLO MAX BREAKAWAY CONTINENTAL BREAKAWAY 1 ¼" FLO MAX 1 ½" FLO MAX w/Bracket 1 ¼" CONTINENTAL 1 ½" CONTINENTAL Part #STFM126K Part #STFM150K WITH BRACKET WITH BRACKET Part #CTB - SWV-125-D Part #CTB - SWV-150-D 1¼"... -
Page 17: Hose Lengths
HOSE LENGTHS FOR MAXIMUM ACCURACY, KEEP ALL HOSES BETWEEN SPLITTER & MANIFOLDS EQUAL LENGTH 3 MANIFOLD SETUP 4 MANIFOLD AND UP SETUP NOTE: Hoses from the manifolds to the ground should also be the same length. -
Page 18: Raven 440 Console
RAVEN 440 CONSOLE QUICK SET - UP GUIDE Note: A tutorial also available on DyTerra’s YouTube Channel When the console is powered up for the first time it will flash CAL and US VOLUME PER ACRE. This means the console must be programmed before operation. - Page 19 Additional: To learn about other settings like the SELF TEST and AUTOMATIC RATE +/- please see pages 18 and 19 in the 440 console manual. Also NH3 Calibration setting for the Valve Cal, Meter Cal, Speed Cal, Boom Cal, are all found in the Installation and Operation Manual for the AccuFlow System.
-
Page 20: Raven Troubleshooting
9. If the valve will not turn while holding the Increase/Decrease Switch, replace the valve. 3. Are you still having issues? The flow of NH3 through your metering system is solely controlled by tank pressure. When applying in colder temperatures, tank pressure will drop. If tank pressure drops too low, your cooler will be starved for product, which causes rates to fluctuate. - Page 21 Fig. 2 PROCEDURE TO TEST FLOW METER CABLES: 1. Disconnect cable from flow sensor. 2. Hold flow sensor cable so that the keyway is pointing to the 12 o’ c lock position: KEYWAY 10 O'CLOCK 2 O'CLOCK 6 O'CLOCK PIN DESIGNATIONS 2 o’...
-
Page 22: Dickey-John Troubleshooting
Black + Brown 12V Flush Switch On 3. Are you still having issues? The flow of NH3 through your metering system is solely controlled by tank pressure. When applying in colder temperatures, tank pressure will drop. If tank pressure drops too low, your cooler will be starved for product, which causes rates to fluctuate. -
Page 23: Dickey-John Common Replacement Parts
DICKEY - JOHN COMMON REPLACEMENT DICKEY-john Actuator Part Number: DJ467095060 required when upgrading to a CTA - BVT valve Flow Sensor Module Part Number: DJ457901570AS1 Part Number: DJ457904000... -
Page 24: Raven Valves And Actuators
RAVEN VALVES AND ACTUATORS QUICK REFERENCE GUIDE OLD STYLE VALVE NEW STYLE VALVE DESCRIPTION COMPLETE ASSEMBLY MOTOR ONLY VALVE ONLY SEAL KIT 1" VALVES - NEW STYLE 1" CONTROL VALVE RV1-063-01732-877 RV1-063-0173-664 RV1-334-0001-071 1" ON/OFF VALVE RV1-117-0173-876 RV1-063-0173-665 RV1-334-0001-071 1" FAST VALVE RV1-063-0173-878 RV1-063-0173-666 RV1-334-0001-071...
