- Page 1 OPERATION & MAINTENANCE MANUAL FIRE DAMPER, TYPE: FID B SAFEVENT ApS Mads Clausens Vej 6 TEL: +45 88 63 89 00 DK-9800 Hjoerring MAIL: sales@safevent.dk Denmark URL: www.safevent.dk/en...
-
Page 2: Table Of Contents
TABLE OF CONTENT 1. INTRODUCTION ..................3 2. SUBJECT ....................3 3. DEVICE INTENDED USE .................. 3 3.1 APPLICATION ..................3 3.2 FIRE RESISTANCE ................... 3 3.3 EXECUTION VERSIONS ................3 3.4 DIMENSION TYPE SERIES ................4 4. DESIGN AND OPERATING PRINCIPLE ............... 4 4.1 DESIGN .................... - Page 3 CAUTION! The product should be stored and used in rooms where: • there is no access to dust, gases, caustic vapors and other aggressive chemical vapors that can destroy the insulating elements and structural elements; • the flaps are not affected by direct sunlight and UV radiation;...
-
Page 4: Introduction
– FID B/T relief dampers – FID B/G CAUTION! Cut-off fire dampers for fire ventilation systems the FID B/V and fire dampers for mixed fire ventilation systems the FID B/M, have one declaration of performance in accordance with the requirements of law. -
Page 5: Dimension Type Series
Aside from the standard dimensions, the fire dampers may also be manufactured in intermediate sizes. The damper casing can be made longer on request. Maximum surface area of type FID B dampers: 0,96 m². The minimum damper surface area is 0,04 m². -
Page 6: Trigger Control Gears
It is recommended that the fire damper is opened and closed when the ventilation system is turned off. 4.3 TRIGGER CONTROL GEARS The following trigger control gears are available for the FID B fire dampers: ELECTRIC ACTUATOR: BF 230-T... -
Page 7: Basic Dimensions
The FID B dampers can be installed at a distance from the following building partitions: walls with a wooden structure of the thickness required for fire resistance... -
Page 8: Pre-Assembly Inspection
Damper FID B BxH Wooden blocks The FID B fire damper will work properly if the isolation partition rotation axis is horizontal. If the case of fire damper must have vertical axial, state this when ordering. The trigger control gear may be located on the right or on the left-hand side of the damper at any direction of air flow. -
Page 9: Installation Of Damper In Panel Walls
It is crucial to keep the device embedding envelope so that the trigger control gear is outside of the wall envelope and easily accessible. 6.3.01 INSTALLATION OF DAMPER IN PANEL WALLS FID B BxH damper Multi-zone smoke extract duct – e.g., made of... -
Page 10: Installation Of Damper In Rigid Floor - Above The Rigid Floor
6.3.03 INSTALLATION OF DAMPER IN RIGID FLOOR – ABOVE THE RIGID FLOOR FID B BxH damper Multi-zone smoke extract duct – e.g., made of fire-rated boards A strip of fire- resistant board along the entire length of the side BxH... -
Page 11: Installation Of The Damper On Vertical Ducts
6.3.06 INSTALLATION OF THE DAMPER ON VERTICAL DUCTS FID B BxH damper Multi-zone smoke extract duct – e.g., made of fire-rated boards A strip of fire- resistant board along the entire length of the side BxH System of ceiling hanger... -
Page 12: Connection Of A Multi-Zone Fireproof Duct, E.g. Made Of Fire Rated Boards
6.3.08 CONNECTION OF A MULTI-ZONE FIREPROOF DUCT, E.G. MADE OF FIRE RATED BOARDS FID B BxH damper Multi-zone smoke extract duct – e.g., made of fire-rated boards A strip of fire- resistant board along the entire length of the side BxH... -
Page 13: Inspection Access
4 extreme screws as shown in the drawing above. 6.3.11 RB CONNECTION SUBFRAME The FID B damper can be delivered by the manufacturer with a system assembly frame for single- compartment fire ventilation ducts. Flanges allow the connection of ventilation ducts with the use of clamps for fixing ducts. -
Page 14: Mwb System Grille
6.3.12 MWB SYSTEM GRILLE The FID B damper can be delivered by the manufacturer with a system cover grille. In case of specific architectural requirements, the structure of the system masking grilles allows covering the damper and the grille with additional masking grilles. -
Page 15: Introduction Of Electric Cables For Electric Power Supply Of The Actuator
The following shows the connection diagrams and basic electrical data for the trigger control gears supplied with the FID B fire dampers. 6.4.01 TYPES OF ELECTRIC ACTUATORS... - Page 16 6.4.02.02 TECHNICAL SPECIFICATIONS FOR THE BE24, BE24-ST, BE230, BLE24, BLE24-ST AND BLE230 ACTUATORS TECHNICAL SPECIFICATIONS BE24, BE24-ST BE230 BLE24, BLE24-ST BLE230 POWER SUPPLY AC 24V 50/60Hz AC 220-240V AC 24V 50/60Hz AC 220-240V DC 24 V 50/60 Hz DC 24V 50/60 Hz POWER DEMAND: - FOR SPRING TENSIONING...
- Page 17 6.5.02.04 TECHNICAL SPECIFICATIONS FOR THE BFL24, BFL24-T, BFL230, BFL230-T, BFN24, BFN24-T, BFN230 AND BFN230-T TECHNICAL SPECIFICATIONS BFL24, BFL24-T BFL230, BFL230-T BFN24, BFN24-T BFN230, BFN230-T POWER SUPPLY AC 24 V 50/60 Hz AC 220–240 V AC 24 V 50/60 Hz AC 220-240 V DC 24 V 50/60 Hz DC 24 V...
-
Page 18: Connection Diagrams Of Electrical Actuators
6.6.01 CONNECTION DIAGRAMS OF ELECTRICAL ACTUATORS 6.6.01.01 CONNECTION DIAGRAM FOR THE BF24T and BF230-T ACTUATORS 6.6.01.02 CONNECTION DIAGRAM FOR THE BFL24-T, BFL230-T, BFN24-T, BFN230-T, BF24-TN AND BF230-TN ACTUATORS 6.6.01.03 CONNECTION DIAGRAM FOR THE MLF 24T, MLF 230T, MF 24T AND MF 230T ACTUATORS Page 17 / 23... - Page 19 6.6.01.04 CONNECTION DIAGRAM FOR THE BE24, BLE24, BE230 AND BLE230 ACTUATORS 6.6.01.05 CONNECTION DIAGRAM FOR BEE24, BEN24, BEE230 AND BEN230 ACTUATORS NOTE: The BE, BLE, BEE and BEE actuator operating control requires a three-wire system. The actuator sense of rotation is switched by applying the supply voltage to terminal 2 or 3, depending on the desired sense.
-
Page 20: Rst/Kw1 Trigger Control Gear
6.6.01.06 CONNECTION DIAGRAM FOR THE EXBF ACTUATORS CAUTION! For proper operation of a device equipped with electrical actuators, it is recommended that the rated voltage housed tolerance of 24V±10% or 230V±10%. Power supply devices other than listed above may cause malfunction and will not be covered by the warranty conditions. 6.7 RST/KW1 TRIGGER CONTROL GEAR The RST/KW1/S version has the limit switches installed in the gear itself. - Page 21 6.7.02 CONNECTION DIAGRAM FOR TRANSFORMER MODULE TYPE MP230/24 CAUTION! - The location of the limit switches is shown for the fire damper in the safety position. CAUTION! For proper operation of a device equipped with electrical actuators, it is recommended that the rated voltage housed tolerance of 24V±2% or 230V±2%.
-
Page 22: Independent Limit Switches - Rst Version
8. MAINTENANCE AND SERVICING The FID B fire damper requires periodic technical inspection and maintenance at least every 12 months throughout its operating life, i.e., during the warranty and post-warranty period. Inspection and maintenance may only be carried out by the manufacturer or contractors authorized to service this product. -
Page 23: Warranty Terms And Conditions
1. Safevent ApS grants 12 months of warranty for the equipment quality from the date of purchase, unless the sales contract states otherwise. 2. Submit each warranty claim to Safevent ApS in 7 days from the date of discovery of a warranty eligible defect. - Page 24 The device's thermal trigger was affected by a temperature greater than Tmax (page 2 of this operation and maintenance manual). 13. Any circumstances listed in Item 10 will relieve Safevent ApS from the obligation of surety. Page 23 / 23...
- Page 25 SAFEVENT ApS Mads Clausens Vej 6 DK-9800 Hjoerring Denmark TEL: +45 88 63 89 00 MAIL: sales@safevent.dk URL: www.safevent.dk/en...
