Infinity Reference 1021t Instructions page 2

3/8"
8mm
2-1/4"
57mm
3-3/16"
80mm
4-11/16"
120mm
5020cs
5-1/8" 3-7/8"
6-1/4"
129mm 98mm
159mm
4-5/16"
5020cs ,6020cs ,
109mm
6520cs ,6520scs ,
6820cs
1-5/16"
3-1/2"
32mm
89mm
5020cs 6020cs
BL (T-m) 3.54 3.80
DCR (ohms) 2.27 2.13
Mms (g) 10.86 15.10
Sd (sq cm) 103.9 132.7
Cms (µm/N) 528 236
Vas (l) 8.00 5.84
Fs (Hz) 66.5 84.3
Qes 0.82 1.18
Qms 6.27 6.61
Qt 0.73 1.00
1wSPL (dB) 86.5 86.6
SPL 2.83V 92.0 92.4
SPECIFICATIONS 5020cs 6020cs
Type: 5-1/4" 2-Way 6-1/2" 2-Way
Component System Component System
Nominal Impedance: 2.65 Ohms 2.65 Ohms
Power Handling, RMS: 75W 90W
Power Handling, Peak: 225W 270W
Frequency Response: 67Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 93dB
