Summary of Contents for Igneus Ceramiko 1200
- Page 1 Igneus Ceramiko 1200 wood fired oven Assembly and operation manual...
- Page 2 Contents 1. About your Igneus Ceramiko 1200 oven 1a. Oven finish 1b. Soot 1c. If your oven chips or cracks 1d. Oven reinforcement fibres 1e. Oven maintenance 2. Igneus Ceramiko 1200 Oven assembly 2a. Oven and Flue Clearances 2b. Oven Delivery 2c.
- Page 3 4. The Clean Air Act 1993 and smoke control areas 4a. Use in Smoke Control Areas 4b. Refuelling 4c. Overloading 5. Igneus Ceramiko 1200 Oven warranty 5a. Investigation of claims against warranty 5b. Warranty Qualifications 5c. Limitation Liability 5d. How to register a claim against the warranty...
- Page 4 Failure to do so may void the oven warranty. 1a. Igneus Ceramiko 1200 oven finish The Igneus Ceramiko is a refractory based oven, which means that due to the nature of the materials used to make your oven and the hand casting process, natural variations between ovens is expected.
-
Page 5: Oven Assembly
1e. Oven maintenance At last, a self-cleaning oven! The Igneus Ceramiko 1200 needs very little cleaning and maintenance. Any spilled or food which drops onto the cooking floor will be burnt off by the heat achieved within the oven in a matter of minutes. When your oven has totally cooled down, (which can take up to 24+ hours) simply dust out the ash before the next firing in a safe way (see section 3f). - Page 6 2c. Oven dimensions...
- Page 7 100mm extra all the way round the circumference of the oven for the insulation and render. The Igneus Ceramiko 1200 oven can be finished in a range of different designs using differing non-combustible materials such as render, brick, stone or mosaic tiles. For inspiration, why not visit our website gallery for design ideas to suit your home or garden.
- Page 8 Laying the oven floor: Step 1: Set down the front floor segment into position first. Notice the front floor segment is the mouth of the oven and a different shape to the other three floor segments. Check the front segment is in the desired location and check that it is level and centralised.
- Page 9 The Igneus Ceramiko 1200 oven is supplied with a 6 inch/150mm single skinned flue as standard. Place your flue into the flue hole in the Igneus Ceramiko 1200 oven, this should be a snug fit, but not tight, as chimney expansion occurs when the oven is in use.
- Page 10 Always wear a protective mask and goggles when cutting and handling insulation wool and board. Finishing Your Oven: There are many different types of enclosures you can create with an Igneus Ceramiko 1200 oven using different building materials from wood to brick, tiles, render and stone, the options are almost endless.
- Page 11 Loosely place your insulation material around the oven, you are using the insulation not only for insulation purposes but also to generate an aesthetic shape. The Igneus Ceramiko insulation kit includes a large amount of ceramic wool blanket, however you may need to still add additional fireproof insulation to generate your preferred oven shape.
- Page 12 You are now ready to render your oven. Step 4. Apply your render to the mesh. We recommend the use of the Igneus Ceramiko Render Kit for this job, however if making your own render use sand and cement, 4 parts plastering sand, 1 part cement,...
- Page 13 DO NOT leave the oven unattended whilst in operation 3b. What wood to use in your oven Igneus Wood Fired Ovens strongly recommend using kiln dried hardwood such as Alder, or compressed Beech briquettes in your oven. Note – seasoned wood, green wood or any wood with moisture content above 20% will cause your oven to generate excessive smoke and it will struggle to reach high temperatures.
- Page 14 The lighting process typically takes around 40 minutes in the Igneus Ceramiko 1200 oven. Step 3 Once you have reached optimum cooking temperatures, (450+ degrees Celsius) you are ready to start the cooking process.
- Page 15 3e. How to cook in your Igneus Ceramiko 1200 oven: The Igneus Ceramiko 1200 oven has the same cooking abilities as all of our wood fired oven range. You can cook virtually anything in a wood fired oven and achieve a range of different cooking techniques.
-
Page 16: The Clean Air Act 1993 And Smoke Control Areas
Clean Air Act requirements. 4a. Use in Smoke Control Areas The Igneus Ceramiko 1200 oven is manufactured on our behalf by a UK based factory. The master design of this oven held by the factory has been approved by Defra as suitable for use in smoke control areas when burning wood and in accordance with the instructions in this manual. - Page 17 Instructions, as outlined in this manual and it must comply with local building regulations. 3) The Igneus Ceramiko 1200 oven is subject to normal use, as defined by the operational manual. The parent company of Igneus Wood Fired Ovens does not warrant the Igneus Ceramiko 1200 oven when any other fuels apart from dry untreated kiln dried hardwood logs or briquettes are burnt.
- Page 18 5d. How to register a claim against the warranty To claim against this warranty and for it to be valid, Igneus Wood Fired Ovens must be notified by telephone 01423 575885, or in writing to; Igneus Wood Fired Ovens, c/o Quality Shops Online Ltd, Old Penny Gate, Off Halfpenny Lane, Knaresborough, HG5 0SL.
- Page 19 6. Important fire and safety notice The Igneus Ceramiko 1200 is a wood fired oven which will reach extremely high temperatures, so please ensure that you follow the installation instructions carefully. Failure to follow this Manual and Health and Safety instructions may result in oven damage, cause damage to property, cause bodily injuries or in some cases even cause death.
- Page 20 UK Fire Safety Legislation we strongly suggest that anyone who may tackle a fire should be adequately trained by a fire safety professional. For further information, visit us at www.igneuswoodfiredovens.com © Quality Shops Online ltd (T/A Igneus Wood Fired Ovens) 2022. All rights reserved.
