Infinity Reference 1052w Reference page 2

LARGE-ROLL
RUBBER SURROUNDS
This material provides optimal
cone-edge suspension and absorbs
distortions that may travel up the
cone edge. The benefit is an audible
reduction in distortion.
PROGRESSIVE SPIDER
Each Reference subwoofer features
a progressive spider, applying
progressively more force as the
cone travel approaches its limit.
The result is a subwoofer in better
control when pushed to extreme
excursions, delivering more bass,
free from distortion and breakup.
8 5 0 w 1 0 5 0 w
8" (200mm) Subwoofer 10" (250mm) Subwoofer
Polypropylene woofer cone Polypropylene woofer cone
Proprietary reduced-depth frame Proprietary reduced-depth frame
Single 4-ohm voice coil Single 4-ohm voice coil
Sensitivity: 91dB Sensitivity: 91dB
Frequency response: 30Hz – 400Hz Frequency response: 25Hz – 400Hz
Power handling, RMS: 200 watts Power handling, RMS: 250 watts
Power handling, peak: 800 watts Power handling, peak: 1000 watts
s u b w o o f e r s
PROPRIETARY TINSEL-
LEAD SUPPORT
This prevents tinsel-lead slap
and ensures that the leads stay
attached to the cone, even at
the woofer's excursion limits.
PROPRIETARY FRAME
The unique frame design used on
all Reference subwoofers provides
a decrease in mounting depth, while
maximizing woofer excursion. If you
want to add subwoofers in a pickup
or in a confined space, these
subs are the ideal solution.
1 0 5 2 w
10" (250mm)
Dual-Voice-Coil Subwoofer
Polypropylene woofer cone
Proprietary reduced-depth frame
Dual 4-ohm voice coils
Sensitivity: 91dB
Frequency response: 25Hz – 400Hz
Power handling, RMS: 250 watts
Power handling, peak: 1000 watts
LA R G E - R O LL
RUBBER SURROUND
P R O G R E SS I V E
SPIDER
V E N T E D
POLEPIECE
P R O P R I E TA R Y
BASKET
1 2 5 0 w 1 2 5 2 w
12" (300mm) Subwoofer 12" (300mm)
Dual-Voice-Coil Subwoofer
Polypropylene woofer cone
Polypropylene woofer cone
Proprietary reduced-depth frame
Proprietary reduced-depth frame
Single 4-ohm voice coil
Dual 4-ohm voice coils
Sensitivity: 93dB
Sensitivity: 93dB
Frequency response: 23Hz – 400Hz
Frequency response: 23Hz – 400Hz
Power handling, RMS: 300 watts
Power handling, RMS: 300 watts
Power handling, peak: 1000 watts
Power handling, peak: 1000 watts
