1
Connect the Beacon and the adapter to the Port B
connection on the Ag Leader 6500/7500 cabling
Note: The null modem cable is not needed for Beacons
3
Tap the Setup wrench icon, then the
4
From the GPS/Guidance setup screen, select the
wrench icon next to "Autodetect"
BN2001-13
Ag Leader 6500, 7500 & Beacon
Ag Leader 6500 & 7500 Display Setup
icon
rev 7
Quick Reference Card
2
Connect the Power Tee to the Can B power/
terminator connection on the Display cable
5
Ensure the Differential source is set to "RTK external"
DigiFarm Technical Support
319.531.7574
support@digifarm.com
DigiFarm
Advertisement
Summary of Contents for DigiFarm Ag Leader 6500
- Page 1 DigiFarm Quick Reference Card Ag Leader 6500, 7500 & Beacon Ag Leader 6500 & 7500 Display Setup Connect the Beacon and the adapter to the Port B Connect the Power Tee to the Can B power/ terminator connection on the Display cable...
- Page 2 DigiFarm Quick Reference Card Ag Leader 6500, 7500 & Beacon Android Quick Reference Card iOS Quick Reference Card Note: Not all android devices function the same; please try your device before purchasing. Pair the Beacon with android device Pair the Beacon with the IOS device via the settings app...
