SUPERCRACKER
You're taking a bath with your hair dryer, you like bungee jumping without a
rope? You always take it one step further? A regular boost just isn't enough? Try
our Supercracker. It will give you the ridiculous boost you always dreamed of!
SUPERCRACKER @ Electric Roots
Version 1.0
10/19/2020
42x30mm
Advertisement
Summary of Contents for Electric Roots SUPERCRACKER
- Page 1 You're taking a bath with your hair dryer, you like bungee jumping without a rope? You always take it one step further? A regular boost just isn't enough? Try our Supercracker. It will give you the ridiculous boost you always dreamed of! 42x30mm SUPERCRACKER @ Electric Roots Version 1.0...
- Page 2 Knobs LOUD Controls the amount of gain Resistors Capacitors Transistors 100nF BS170 / 2N7000 10uF (elec) 2N5457 100k 100uF (elec) 100nF Diodes Potentiometers Other 9V Zener LOUD SPDT on/on 1N4001 SUPERCRACKER @ Electric Roots Version 1.0 10/19/2020...
- Page 3 Beware of Counterfeit components, if you want quality products, order a kit, don’t use ceramic capacitors over 1nF they tend to have microphonic characteristics in some setups. The 2N7000 can be replaced with BS170, just flip it 180 degrees! Wiring SUPERCRACKER @ Electric Roots Version 1.0 10/19/2020...
- Page 4 Notes CLR is usually 4k7 – 10k. The value depends on how bright you like your status LED. Mods Try a different diode for D1 SUPERCRACKER @ Electric Roots Version 1.0 10/19/2020...
- Page 5 Schematic License By buying and using this product you confirm that you have read, understood and accepted our Terms and Conditions ( electric-roots.com/termsandconditions SUPERCRACKER @ Electric Roots Version 1.0 10/19/2020...
