LPC P-cap Panel PC 2VET Series
With Gen 11 Core-i7/i5
User Manual
Published in Taiwan
Release Date : Oct 2021
Revision : V0.1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPC-P150S-2VETx and is the answer not in the manual?

Questions and answers

Summary of Contents for Elgens LPC-P150S-2VETx

  • Page 1 LPC P-cap Panel PC 2VET Series With Gen 11 Core-i7/i5 User Manual Published in Taiwan Release Date : Oct 2021 Revision : V0.1...
  • Page 2 Disclaimer This information in this document is subject to change without notice. In no event shall ELGENS Co., Ltd. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 GETTING STARTED ..................... 4 1.1 B LPC P- 2VET S ................4 RIEF ESCRIPTION OF ERIES 1.2 S ......................5 YSTEM PECIFICATIONS 1.3 D ........................... 7 IMENSION 1.4 G IO P ....................11 ENERAL LACEMENT 1.5 F LPC-2VET ..................

  • Page 4: Chapter 1 Getting Started

    HDD tray, audio jack, 2 RJ45 Ethernet, DC input, and 4 USB ports. The unit supports Windows 10. The Elgens fanless touch panel computer is ideal for use as Web Browser, Terminal and HMI at all levels of automation control.

  • Page 5: System Specifications

    1.2 System Specifications Model LPC-P156W- LPC-P185W- LPC-P150S-2VETx LPC-P190S-2VETx Number 2VETx 2VETx 1024*768 1920*1080 1920*1080 1280*1024 Resolution Color 16.7M 16.2M 16.2M 16.7M Luminance 300 nits 450 nits 350 nits 350 nits View Angle 176/176 170/170 178/178 170/160 Contrast Ratio 2500 1000...
  • Page 6 H = High Brightness 1000 nits LED backlight (Optional to 1600 nits backlight) OB = Optical Bonding G = Glass without touch AG = Anti-Glare AR = Anti-Reflection V = Vandal Proof Glass T = Backside Heatsink for Operating Temperature 60°C Contact Elgens Sales for detail information...

  • Page 7: Dimension

    1.3 Dimension 1.3.1 LPC-P150S-2VETx Drawing...
  • Page 8 1.3.2 LPC-P156W-2VETx Drawing...
  • Page 9 1.3.3 LPC-P185W-2VETx Drawing...
  • Page 10 1.3.4 LPC-P190S-2VETx Drawing...

  • Page 11: General Rear Io Placement

    1.4 General Rear IO Placement COM 1~4 is RS-232 as default and can be adjustable to RS-422/485 by BIOS. Power input terminal block pin definition is as below.

  • Page 12: Front View Of Lpc-2Vetx Series

    1.5 Front View of LPC-2VETx Series 1.6 Rear View of LPC-2VETx Series...

  • Page 13: Top / Bottom Io View

    1.7 Top / Bottom IO View...

  • Page 14: Chapter 2 System Setup

    Chapter 2 System Setup 2.1 Installing of DDR4 SO-DIMM Step 1 Install DDR4 RAM module into SO-DIMM slot. Step 2 Make sure the RAM module is locked by the memory slot.

  • Page 15: Installing Of M.2

    2.2 Installing of M.2 Step 1 Install M.2 into the M.2 slot. Step 2 Fasten one PH-M3x4L screw. 2.3 Installing of HDD...

  • Page 16: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup 3.1 Entering Setup BIOS provides an interface for users to check and change system configuration. The BIOS setup program is accessed by pressing the <Del> key when POST display output is shown. Figure 2-1 : Entering Setup Screen...

  • Page 17: Main Menu

    3.2 Main Menu The main menu displays BIOS version and system information. There are two options on Main menu. Figure 2-2 : BIOS Main Menu System Date Set the Date. Use Tab to switch between Date elements. System Time Set the Time. Use Tab to switch between Time elements.

  • Page 18: Advanced Function

    3.3 Advanced Function Select Advanced tab to enter advanced BIOS Setup options such as CPU configuration SATA configuration, and USB configuration. Figure 4-3 : BIOS Advanced Menu...
  • Page 19 3.3.1 CPU Configuration Figure 2-3-1 : CPU Configurations CPU Flex Ratio Override Enable/Disable CPU Flex Ratio Programming. Hardware Prefetcher To turn on/off the MLC streamer prefetcher. Adjacent Cache Line Prefetch To turn on/off prefetching of adjacent cache lines. Intel (VMX) Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.
  • Page 20 3.3.2 Power & Performance Figure 2-3-2 : Power & Performance 3.3.2.1 CPU - Power Management Control Figure 2-3-3 : CPU - Power Management Control Boot performance mode Select the performance state that the BIOS will set starting from reset vector. Intel®...
  • Page 21 3.3.2.2 GT - Power Management Control Figure 2-3-2-2 : GT - Power Management Control RC6 (Render Standby) Check to enable render standby support. Maximum GT frequency Maximum GT frequency limited by the user.Choose between 300MHz (RPN) and 1150 MHz (RP0). Value beyond the range will be clipped to min/max supported by SKU.
  • Page 22 3.3.4 Intel Time Coordinated Computing Figure 4-3-5 : Intel TCC Intel® Time Coordinated Computing options. #AC Split Lock Enable or Disable Alignment Check Exception (#AC). When enabled, this will assert an #AC when any atomic operation has an operand that crosses two cache lines. Intel(R) TCC Mode Enable or Disable Intel(R) TCC mode.
  • Page 23 3.3.6 ACPI Setting Figure 4-3-1 : ACPI Settings Enable Hibernation Enables or disables system's ability to hibernate (OS/S4 Sleep State). This option may be not effective with some OS. ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.
  • Page 24 3.3.8 IT8786 Super IO Configuration Figure 4-3-5 : Super IO Settings Serial Port 1 Configuration Set parameters of serial port 1 (COM 1). Serial Port 2 Configuration Set parameters of serial port 2 (COM 2). Serial Port 3 Configuration Set parameters of serial port 3 (COM 3). Serial Port 4 Configuration Set parameters of serial port 4 (COM 4).
  • Page 25 3.3.10 Serial Port Console Redirection Figure 4-3-7 : Serial Port Console Redirection Settings Console Redirection Console redirection enable or disable. Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. Legacy Console Redirection Settings Legacy Console Redirection Settings Serial Port for Out-of-Band management/Windows Emergency Management Services...
  • Page 26 3.3.11 Intel TXT information Figure 4-3-9 : Intel TXT Information Display Intel TXT information. 3.3.12 Acoustic Management Configuration Figure 4-3-11 : Acoustic Management Settings Acoustic Management Configuration Option to enable or disable Automatic Acoustic Management. 3.3.13 PCI Subsystem Settings Figure 4-3-7 : PCI Subsystem Settings BME DMA Mitigation Re-enable Bus Master Attribute disabled during Pci enumeration for PCI Bridges after SMM Locked.
  • Page 27 3.3.14 USB Configuration Figure 4-3-14 : USB Settings Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. XHCI Hand-off This is a workaround for OS-es without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.
  • Page 28 3.3.15 CSM Configuration Figure 4-3-13 : CSM Settings Network Stack Enable/disable UEFI Network Stack. CSM Support Enable/disable CSM Support. GateA20 Active UPON REQUEST - GA20 can be disabled using BIOS services. ALWAYS - do not allow disabling GA20; this option is useful when any RT code is executed above 1MB.
  • Page 29 3.3.16 NVME Configuration Figure 4-3-13 : NVME Settings Display NVMe Controller and drive information. 3.3.17 Network Stack Configuration Figure 4-3-12 : Network Stack Settings Network Stack Enable/disable UEFI Network Stack. Ipv4 PXE Support Enable Ipv4 PXE Boot Support. If disabled IPV4 PXE boot option will not be created. Ipv4 HTTP Support Enable/disable IPv4 HTTP boot support Ipv6 PXE Support...

  • Page 30: Chipset

    3.4 Chipset Figure 4-4 : Chipset Menu System Agent (SA) Configuration System Agent (SA) Parameters. PCH-IO Configuration PCH Parameters. SW Ignition Configuration SW Ignition Configuration. Settings Delay Timer and value of Voltage limit. 3.4.1 System Agent (SA) Configuration Figure 4-4-1 : USB Settings VT-d VT-d capability.
  • Page 31 3.4.1.1 Memory Information of System Agent (SA) Figure 4-4-3 : Memory Information Display memory information. In-Band ECC Support Enable/Disable In-Band ECC. Either the IBECC or the TME can be enabled.
  • Page 32 3.4.1.2 Graphics Configuration Figure 4-4-4 : Graphics Configuration PCH LAN Controller Enable or disable onboard NIC. Graphics Configuration Graphics turbo IMON current values supported (14-31). Skip Scanning of External Gfx Card If Enable, it will not scan for External Gfx Card on PEG and PCH PCIE ports. Primary Display Select which of IGFX/PEG/PCI graphics device should be Primary Display or select HG for Hybrid Gfx.
  • Page 33 3.4.1.3 VMD Configuration Figure 4-4-5 : VMD Configuration Enable VMD controller Enable/Disable to VMD controller. Enable VMD Global Mapping Enable/Disable to VMD Global Mapping. 3.4.1.4 SA PCI Express Configuration Figure 4-4-5 : SA PCI Express Configuration PCI Express Clock Gating PCI Express Clock Gating Enable/Disable for each root port.
  • Page 34 3.4.2 PCH-IO Configuration Figure 4-4-6 : PCH-IO Configuration PCH LAN Controller Enable or disable onboard NIC. Wake on LAN Enable or disable integrated LAN to wake the system. State After G3 Specify what state to go to when power is re-applied after a power failure (G3 state). 3.4.2.1 PCI Express Configuration Figure 4-4-7 : PCI Express Configuration...
  • Page 35 3.4.2.2 SATA & RST Configuration Figure 4-3-10 : 2.4.2.2 SATA & RST Configurations SATA Controller(s) Enable or disable SATA Device. SATA Mode Selection Determines how SATA controller(s) operate. Software Feature Mask Configuration RAID OROM/RST driver will refer to the SWFM configuration to enable or disable the storage features.
  • Page 36 3.4.2.3 BIOS Security Configuration of PCH-IO Figure 4-4-6 : BIOS Security Settings Force unlock on all GPIO pads If Enabled BIOS will force all GPIO pads to be in unlocked state. BIOS Lock Enable/disable the PCH BIOS lock enable (BLE bit) feature. 3.4.3 SW Ignition Configuration Figure 4-4-6 : SW Ignition Configuration Force unlock on all GPIO pads...

  • Page 37: Security

    3.4.4 LVDS Configuration The LVDS Configuration option will be present if LVDS panel is connected on system. Figure 4-4-8 : LVDS Panel Settings LCD Panel Type Select LCD Panel Resolution. 3.5 Security Figure 4-5 : BIOS Security Menu Administrator Password Set Administrator Password.
  • Page 38 Secure Boot configuration. 3.5.1 HDD Security Configuration Figure 4-5-1 : HDD Security Settings Set User Password Set HDD user password. ***Advisable to Power Cycle System after Setting Hard Disk Passwords. *** Discard or save changes option in setup does not have any impact on HDD when password is set or removed.

  • Page 39: Boot

    3.6 Boot Figure 4-6 : BIOS Boot Menu Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state. Quiet Boot Enables or disables Quiet Boot option. Boot Option #x Sets the system boot order.

  • Page 40: Save & Exit

    3.7 Save & Exit Figure 4-7 : Bios Save and Exit Menu Save Changes and Exit Exit system setup after saving the changes. Discard Changes and Exit Exit system setup without saving any changes. Save Changes and Reset Reset the system after saving the changes. Discard Changes and Reset Reset system setup without saving any changes.

  • Page 41: Appendix A : Gpio Guide

    APPENDIX A : GPIO GUIDE Function Description The EMBC-5000 offers a 16-bit GPIO a pair of 10-bit internal connector, and a watchdog timer. GPIO definition is shown below : JDIO2 JDIO1 JDIO1 JDIO2 GPIO GPIO Definition Definitio GPIO 0 GPIO 8 GPIO 1 GPIO 9 GPIO 2...
  • Page 42 Software Package Contain Distribution folders include x32 and x64 versions, use the batch file for driver installation. There are included as fallowed : Win10_32.bat, and Win10_64.bat : Installation for driver, and Uninstall_32.bat, and Uninstall_64.bat : Uninstallation for driver Run batch file as Administrator. Make sure Windows version before installation.
  • Page 43 Sample Execute demo tool. Windows Linux Sample, as shown below : Vecow_DIO Vecow_DIO_loopback Vecow_POE Vecow_WDT © Vecow EMBC-5000 User Appendix A Manual...

  • Page 44: Appendix B : Software Functions

    APPENDIX B : Software Functions Driver API Guide In Header folder, Vecow.h and VecowLinux.h contain usabled API for Windows/Linux. BOOL initial_SIO(BYTE Isolate_Type, BYTE DIO_NPN) Initial machine for IO and watch dogtimer. Isolate_Type : DIO type. 0 : Isolated DIO; 1 : Non-Isolated DIO (GPIO). DIO_NPN : DI/DO type.
  • Page 45 BOOL set_IO1_configuration(BYTE Iso, BYTE DI_mode, BYTE DO_mode, WORD Mask) BOOL set_IO2_configuration(BYTE Iso, BYTE DI_mode, BYTE DO_mode, WORD Mask) Set DIO configuration. Isolate_Type : DIO type. 1 : Isolated DIO; 0 : Non-Isolated DIO (GPIO). DI_mode ([7:0]) : DI type, pin setting by hexadecimal bitmask only for Isolated DIO. 0xFF : PNP (Source) mode for European rule;...
  • Page 46 BOOL get_GPIO1(WORD *GPIO_data) Get GPIO. GPIO_data ([15:0]) : GPIO state, pin setting by hexadecimal bitmask. 1 : High; 0 : Low. Return : TRUE (1) : Success. FALSE (0) : Fail (Initial error or hardware problem). BOOL set_GPIO1(WORD GPIO_data) Set GPIO. GPIO_data ([15:0]) : GPIO state, pin setting by hexadecimal bitmask.

  • Page 47: Appendix C : Raid Functions

    APPENDIX C : RAID Functions The 11th Generation Intel processors (Intel Tiger Lake) utilizes the new Intel Volume Management Device technology, which optimizes the storage devices' data processing effectiveness and power consumption. When you install Windows 10 retail or enterprise version, both need to load the IRST driver so Windows can detect a storage drive.
  • Page 48 4. Save Changes and Reset. When asked if you want to save changes, click "Yes". 5. Access BIOS menu again, select Intel(R) Rapid Storage Technology. 6. Select Create RAID Volume on BIOS menu. 7. Select disks to create RAID Volume then Save Changes and Reset to install OS with UEFI mode.
  • Page 49 OS Installation The system is featured with three SATA, include two internal SATA, and one M.2 Key B (3052) storage. We take two SATA for Windows 10 OS installation as an example. 1. Please download "Intel Rapid Storage Technology (IRST) driver", Download Link from Intel Optane™...
  • Page 50 4. After the copying is completed, make sure the folder includes the following files. 5. Select Windows 10 USB drive to enter Windows 10 setup interface Follow the installation instruction, the system should enter the storage setting interface, the bottom of the screen should display a message "We couldn't find any drives.
  • Page 51 6. Click on Browse icon. 7. Select Intel VMD driver folder which has been saved in, then click on OK to continue the process. Appendix C...
  • Page 52 8. Select the top driver, and then click on Next button to continue the process. 9. Windows 10 OS will automatically install the Intel VMD driver, after the process is complete, you will see the list of all drives and partitions on your computer. You can choose to "Refresh", "Format", "Delete"...
  • Page 53 To Install All Device Drivers of the System The instructions are as follows : 1. To install Chipset driver 2. To install Graphics driver 3. To install ME driver 4. To install SerialIO driver 5. To install Network driver 6. To install Audio driver ®...
  • Page 54 To get Intel® Optane™ Memory and Storage Management application The Intel® Optane™ Memory and Storage Management application/user interface is a Microsoft Store* app. It provides users with monitoring and management capabilities for the Intel® Rapid Storage Technology (Intel® RST) storage subsystem, Download Link. Note : The Intel®...
  • Page 55 Intel® Optane™ Memory and Storage Management User Interface The volume will be shown in the OS-related applications, and it will display Pass-through SATA and PCIe disks, Empty SATA ports, RAID volumes, and Intel® Optane™ memory volumes. The following guide link can assist you when managing Intel® Optane™ memory devices.
  • Page 56 If one of the hard drives has failed and needs to be replaced The Intel application will have a screen that indicates the status of the member drives and will let you know which port has the failed drive. Recovery and Auto Rebuild When Use the SAME RAID HDD/SSD Open the Intel®...

This manual is also suitable for:
