- Page 1 No, ＩＭ-CO201806 C O R type Instruction Manual...
-
Page 2: Table Of Contents
Cautions at startup and during operation Cautions during non-operation Cautions during storage and long non-operation Daily checks and maintenance Pump troubleshooting (at startup) Pump troubleshooting (during operation) Procedures for aligning the shaft coupling 10～13 1CO Assembling (disassembling) procedures 14～17 2COR Assembling (disassembling) procedures... - Page 3 Introduction Thank you very mch for purchasing a Mitsuwa Cross over Pump. This instruction manual provides guidance on how to use a Cross over Pump (hereafter referred to as a pump). The manual describes procedures for installing, operating, inspecting, and maintaining the pump and check items for the actual users of the pump.
-
Page 4: For Safety
For safety work Before starting work, check the safety precautions and work procedures with Danger Danger Danger Danger ● the person in charge of site work according to the work plan and perform work ！ ！ ！ ！ safely. Before inspecting, maintaining, or overhauling the product, check whether the Warning Warning Warning... -
Page 5: Cautions For Installation
Cautions for installation The pump foundation must be constructed on soils with an adequate bearing capacity and must be strong enough to withstand equipment vibration and Important Important Important Important ● ！ ！ ！ ！ weight. There must be no pools of water on the pump foundation. Firmly secure the pump with anchor bolts. -
Page 6: Pump Startup Procedures
Pump startup procedures （1） Make sure that the main power supply to the electric motor is off. （2） Check for loose pipe connections and pump bolts. （3） Turn the pulley (coupling) by hand to check whether it turns smoothly. （4） Before fitting the belt (coupling bolt), check the rotation direction of the electric motor. -
Page 7: Cautions During Non-Operation
Cautions during non-operation If no countermeasures against water hammer such as a check valve have been taken, fully close the discharge valve and then stop the pump. At this moment, ● allow the internal pressure in the pump to escape with the air vent valve. (Be Danger Danger Danger... -
Page 8: Daily Checks And Maintenance
Daily checks and maintenance Frequency Check items Check and action Check the oil condition through the sight glass. Change oil if it is contaminated or add oil if there is not enough. Every week Check the oil condition. The following week, if you have the same problem, you need to replace the mechanical seal. -
Page 9: Pump Troubleshooting (At Startup)
Pump troubleshooting (at startup) Main causes Problem 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 The pump does not work. ◎ ○ ◎ ○ Water is not pumped up. ○... -
Page 10: Pump Troubleshooting (During Operation)
Pump troubleshooting (during operation) Main causes Problems 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Pumping water is ○ ◎ ◎ ◎ ○ ○ ○ ○... -
Page 11: Procedures For Aligning The Shaft Coupling
Procedures for aligning the shaft coupling The pump is provided with a factory-aligned shaft coupling. The shaft coupling may be misaligned during pump installation or piping. When pump installation or piping is completed, check the alignment and realign it if necessary. If you continue to operate the pump with the shaft coupling misaligned, the pump may fail at an early stage. -
Page 12: 1Co Assembling (Disassembling) Procedures
1CO Assembling (disassembling) procedures The procedures for assembling the pump are as shown below. Disassembly is the reverse of assembly. The procedures for assembling the standard type are described. For special specifications, contact your dealer or the product manufacturer. 【Schematic diagram of the pump】... - Page 13 1、 Assembling the casing 【Assembly on the casing side】 ① Align the outer casing B (suction side) with the inner volute and fit the inner volute flange into the outer casing B. Pull out the inner volute flange with a flat-tipped rod and firmly fit the flange into the casing by hand.
- Page 14 Attach the O ring to the bearing plate, Fit the bearing plate into the bearing case. ② Pay attention to adjust the positions of the bearing plate hole and the bearing case plug hole as aligned. Washer Bearing plate Bearings wave O ring Plug Bearing case...
- Page 15 ④ Insert the mechanical seal stator(large) into the mechanical seal case and fasten it with the mechanical seal Mechanical seal stetionary plate Spring washer stationary plate and round screw(3pcs). O ring Round screw ⑤ Attach the O ring to the bearing case and assemble the bearing case and mechanical seal case with bolts(5pcs).
-
Page 16: 2Cor Assembling (Disassembling) Procedures
2COR Assembling (disassembling) procedures The procedures for assembling the pump are as shown below. Disassembly is the reverse of assembly. The procedures for assembling the standard type are described. For special specifications, contact your dealer or the product manufacturer. 【Schematic diagram of the pump】 Parts Q'ty Parts... - Page 17 1. Assembling the casing 【Assembly on the casing side】 ① Align the casing (on the suction side) with the volute liner and fit the volute liner flange into the casing. Pull out the volute liner flange with a flat-tipped rod and firmly fit the flange into the casing by hand.
- Page 18 2. Assembling the bearing 【Bearing assembly】 Bearing case cover A ① Put the bearing case and bearing case Bearing case cover A together. Bearing Ｂ ② Insert bearings A, B, and C each into the shaft O ring with a pressure of about 10 MPa. When Bearing Ａ...
- Page 19 ④ Attach the oil drain plug and sight glass to the seal case. ⑤ Insert the seal washer (with liquid gasket applied to both sides) and mechanical seal rotor (large) into the casing cover and fasten them with the mechanical seal stationary plate. Seal washer Mechanical seal ⑥...
- Page 20 Head office (Zip code: 511-0251) 3617, Shinkurahara, Ooaza-yamada, Toincho, Inabegun, Mie, Japan TEL: +81-594-76-1100 FAX: +81-594-76-1101 http://www.mitsuwapump.jp/ http://www.mitsuwapump.jp/ http://www.mitsuwapump.jp/ http://www.mitsuwapump.jp/...
