Summary of Contents for Infinity ERS 110DT
- Page 1 ™ OTAL PEAKER OLUTIONS ERS 110II ERS 110DT ERS 210II ERS 310 ERS HV250 Owner’s Guide...
-
Page 2: Planning Your System
NTRODUCTION Infinity ERS ™ Series The ERS Series of in-wall/ceiling loudspeakers continues Infinity’s longstanding commitment to accurate sound reproduction. Our patented Ceramic Metal Matrix Diaphragm (CMMD ™ ) drivers and precision dividing networks deliver uncompromised performance in any stereo, multichannel home theater or whole-house music system. -
Page 3: Installation
In 6- or 7-channel configurations, place the rear channel(s) behind the listening position, as shown in Figure 3. Note: An Infinity powered subwoofer will add impact and realism to both music and film soundtracks. Contact your Infinity dealer for recommendations on subwoofer models for your application. -
Page 4: Speaker Connections
Figure 4. Connect each + terminal on the back of the amplifier or receiver to the respective + (red) terminal on each speaker. Connect the – (black) terminals in the same way. Important! Do not reverse polarities (i.e., + to – , or – to +) when making connections. -
Page 5: Existing Construction
≥1/2" 3. Note: Always allow at least 4. Cut the drywall. one-half inch between a wall stud and the speaker cutout or the locking tabs will not be able to swivel into place. 6. Place the frame assembly 5. Connect the speaker wires to the speaker. -
Page 6: New Construction
(inner section of template in the assembly kit) securely into the recess in the baffle.This will protect the speaker components and baffle from paint residue. Use a high-quality spray paint, and apply a thin coat of color. -
Page 7: Specifications
3-1/2" (89mm) Weight (Net) 3.1 lb (1.4kg) Infinity continually strives to update and improve existing products, as well as create new ones. The specifications and construction details in this and related Infinity publications are therefore subject to change without notice. - Page 8 * Trademarks of Dolby Laboratories. DTS is a registered trademark of Digital Theater Systems, Inc. Infinity is a registered trademark, and ERS and CMMD (patent nos. 6,327,372 and 6,404,897) are trademarks, of Harman International Industries, Incorporated. Part No. 406-000-05203 1/05...
