Summary of Contents for Valley Microscope VM200 Series
- Page 1 VM200 VM200 Series Biological Microscope Instruction Manual To ensure your safety and to obtain satisfactory performance, please study this manual before using the microscope.
-
Page 2: Technical Parameters
1. Technical Parameters 1. Total Magnification Eyepiece 10× Objective 4× 10× 40× 100× Magnification 40× 100× 400× 1000× 2. Head : Inclined 30°, Monocular head or Binocular/Trinocular Siedentopf head, Interpupillary adjustable distance of 48-75mm, Diopter adjustable range ±5°, anti-fungal. 3. Nosepiece: 4 position nosepiece. 4. - Page 3 2. Parts of the Microscope VM200 Series Binocular Microscope Component Parts: A1—— Eyepiece A2—— Head（Monocular, Binocular or Trinocular） A3—— Objective A4—— Mechanical Stage A5—— Abbe Condenser A6—— Illuminator A7—— Base A8—— Main Body A9—— DC Input Socket A10—— Power Adapter A11——...
-
Page 4: Operation
When the microscope is not in use turn off the power and keep covered with provided dust cover. ▲ To maintain the instrument’s top performance it is recommended that it be serviced regularly. In case of damage contact Valley Microscope via email: service@valleymicroscope.com ▲... - Page 5 Disassembly or repairs by Unauthorized persons. The microscope has been factory adjusted before shipping. Unauthorized persons should not disassemble or remove any other parts. If you have any questions, please contact either Valley Microscope or your local distributor. Excessive input voltage.
-
Page 6: Troubleshooting
Troubleshooting Please use this table below for solving problems. If this table does not offer a solution contact Valley Microscope: service@valleymicroscope.com Trouble Cause Solution Plug is unreliable Check cables Switch on but no Bulb is broken Replace bulb light. Fuse is broken Replace fuse Bulb is flickering. - Page 7 Objective isn’t in correct optical Rotate the objective to One side of image is path. correct position. dark or image is Specimen isn’t placed Place specimen level in moving as focusing. correctly. specimen holder. Objective touches Cover glass of specimen Place specimen specimen when doesn’t meet the requirement.
