24", 30" & 48" BANQUETTE HARDWARE LIST
(48) #8x1" Round Washer Head Screws
30" QUINCY BOOTH
(2) 5/16-18 x 1" Bolt + 5/16-18 Nut (Hex Flange)
(1) 3/4" Spacer Board
(2) 9-1/2"W Back Boards
(2) 7-1/2"W Seat Boards
(2) Seat Brackets
TOOLS NEEDED
Tape Measure
Drill
#2 Square Head Bit
2- ½" Open End Wrench
DESIGNED AND BUILT IN MIDDLE AMERICA
QUINCY BANQUETTE HARDWARE LIST
DRAWN BY:
DATE:
CHECKED BY:
DATE:
WEIGHT:
66.37 LBS
®
UPHOLSTERED PANEL FOR
SEAT AND/OR BACK
60" & 72" BANQUETTE HARDWARE LIST
PART NO:
(72) #8x1" Round Washer Head Screws
QBH-30
(3) 5/16-18 x 1" Bolt + 5/16-18 Nut (Hex Flange)
REV:
SCALE:
SIZE:
0
1:12
(1) 3/4" Spacer Board
(2) 9-1/2"W Back Boards
(2) 7-1/2"W Seat Boards
(3) Seat Brackets
UPHOLSTERED PANEL HARDWARE LIST
(2) Flat Washers
(2) Thumb Screws
Questions? contact us at service@crowworks.com.
SHEET NO:
2
A
2 OF 4
CROWWORKS.COM
Advertisement
Summary of Contents for CROW WORKS QUINCY Series
- Page 1 Crow Works, and were created and developed for use on, and in connection with the specified project. Under no condition is this drawing or any part of, to be reproduced, used by or disclosed to any person, firm, or corp.
- Page 2 All ideas, designs, planning, drawings, and specifications are owned by, and are the property of Crow Works, and were created and developed for use on, and in connection with the specified project.
- Page 3 QUINCY BANQUETTE ASSEMBLY INSTRUCTIONS (OPTIONAL) 2 " 9-1/2" 4 " 3/4" FOR DOUBLE-SIDED BOOTH 2 " 7-1/2" 4 " 4 " 3/4" 3/4" Secure booths to each other using (2) hex flange 2 " 1/2" bolts and nuts. ADDING UPHOLSTERED PANELS STEP A Set upholstered panel wood spine into the slot between the two boards and center the...
