Summary of Contents for Air Conditioning Centre KYR-25CO/AG
- Page 1 Portable Air-Conditioning User’s Manual For Models: KYR-25CO/AG KYR-35GW/AG KYR-45GW/AG KYR-55GW/AG Please read this user manual carefully to ensure proper use, maintenance and installation.
-
Page 3: Table Of Contents
Contents 1. Safety Awareness ...................4 2. Name of Parts ....................5 3. Accessories .....................6 4. Appearance and Function of Control Panel .............7 5. Appearance and Function of Remote Control ..........11 6. Operation Introduction ..................9 7. Installation Explanations ................12 8. Maintenance Explanations ................17 9. -
Page 4: Safety Awareness
1. Safety Awareness 1. Safety Awareness VERY IMPORTANT! Please do not install or use your portable air conditioner before you have carefully read this manual. Please keep this instruction manual for an eventual product warranty and for future reference. Warning Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. - Page 5 • The appliance must be placed in an area without any continuously sources of ignition (for example: open flames, gas or electrical appliances in operation). • Do not puncture and do not burn. • This appliance contains Y g (see rating label back of unit) of R290 refrigerant gas. •...
- Page 6 6. Before cleaning the air-conditioner, always turn off or disconnect the power supply. 7. When moving the air-conditioner, always turn off and disconnect the power supply, and move it slowly. 8. To avoid the possibility of fire disaster, the air-conditioner shall not be covered. 9.
- Page 7 the power supply cord can result in damage to the unit and cause electrical shock. 18. Compliance with national gas regulations shall be observed. 19. Keep ventilation openings clear of obstruction. 20. Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorizes their competence to handle refrigerants safely in accordance with an industry recognized assessment specification.
-
Page 8: Name Of Parts
— To avoid the possibility of danger, if power cord is damaged, please turn off the power switch and disconnect the power supply. It must be replaced by — the dealer or a designated repair shop. 2. Name of Parts 2. -
Page 9: Accessories
3. Accessories 3. Accessories Part Description Quantity Exhaust hose Window Connector Housing adaptor Remote Controller Window Kit Remote Controller 1 (optional) Window Connector 1 (optional) Window Kit 1 (optional) Air outlet 1 (optional) Dowel 2 (optional) Universal Window kit 1 (optional) Water pipe 1 (optional) -
Page 10: Appearance And Function Of Control Panel
Batteries 2 (optional) After unpacking, please check whether the above-mentioned accessories are included, and check their purposes in the installation introduction in this manual. 4. Appearance and Function of Control Panel 4. Appearance and Function of Control Panel Cooling & Heat pump model + WIFI Dehumidifying Power on/off Fan speed... -
Page 11: Appearance And Function Of Remote Control
5. Appearance and Function of Remote Control 5. Appearance and Function of Remote Control Remote Control POWER Power on/off TIMER Timer on/off MODE Operation MODE TEMP- Temperature down TEMP+ Temperature up SPEED Fan speed SLEEP Sleep mode SWING Auto swing Notes: - Do not drop the remote controller. -
Page 12: Operation Introduction
6. Operation Introduction 6. Operation Introduction Before starting operations in this section: 1) Find a place where there is a suitable power supply nearby. 2) As shown in Fig.5 and Fig.5a, install the exhaust hose, and adjust the window position well. Fig.5 Fig.5a 3) Connect drain hose well (only for use during heating mode, not KYR25CO)；... - Page 13 Fig.6 6.1. Before using Notice: Ambient operating temperature range: Maximum cooling Minimum cooling ℃ Maximum heating Minimum heating ℃ Check whether the exhaust hose has been mounted properly. Cautions for cooling and dehumidifying operations: When using functions on cooling and dehumidifying, keep an interval of at least 3 minutes between each ON/OFF.
- Page 14 Press the “Mode” button until the “Fan” icon appears. Press the “WIND” button to select wind speed. 6.5 Heating operation (this function is not available for the KYR-25CO/AG unit) Press the “Mode” button until the “Heat” icon appears. Press the “DOWN” or “UP” button to select a desired room temperature. (16℃-31℃) Press the “WIND”...
-
Page 15: Installation Explanations
motor. Make sure the drainage holes are sealed well. If water splash motor is damaged, continuous drainage can be used. To connect the drain hose to the bottom drainage outlet (Fig.6), the unit will also work well. If splash motor is damaged, intermittent drainage can also be used. Under this condition, when the water full indicator lights up, please connect a drain hose to the bottom drainage hole, then all the water in the water tank will be drained outside. - Page 16 Fig.8 7.2 Introduction to Exhaust Hose Installation Fig.9 Temporary installation Twist the housing adaptor and fix the window Connector to the end of the exhaust hose. Insert the fixing clip of the housing adaptor into the openings at back of the air conditioner.
- Page 17 Fig.10 Fig.10a Fig.11 Universal window kit accessory for mobile air conditioner Suitable for windows and doors Included in this kit: 1 piece of zipped fabric 1 roll of hook and loop adhesive tape...
- Page 18 1. Open the window and clean the 2. Cut large strips of adhesive gripping doors and frame before sticking the tape to the dimensions of the window. adhesive tape. Fix them to the frame of your window and then do the same on the inner surface of the window flap (on the handle side).
- Page 19 6. Your sealing kit is now installed, you 5. Open the window gently and open can now turn on and enjoy the the zipper of the fabric piece (at level coolness of your mobile air of the bottom or middle of the window) conditioner! then insert the exhaust duct into the If you no longer want to use your...
-
Page 20: Maintenance Explanations
8. Maintenance Explanations 8. Maintenance Explanations Declaration: 1) Before cleaning, be sure to disconnect the unit from any electric supply outlet; 2) Do not use gasoline or other chemicals to clean the unit; 3) Do not wash the unit directly; 4) If the conditioner is damaged, please contact the dealer or repair shop. -
Page 21: Troubleshooting
8.1 Air Filter If the air filter becomes clogged with dust/dirt, the air filter should be cleaned once every two weeks. Dismounting Open the air inlet grille and take off air filter. Cleaning Clean the air filter with neural detergent in lukewarm（40℃）and dry it in the shade. Mounting Put the air filter into the inlet grille, replace the components as they were. - Page 22 button - Room temperature is higher than the set temperature. (Heating Set a higher temperature mode) - Room temperature is lower than the set temperature. (Cooling Set a lower temperature mode) - The doors or windows are not Make sure all the windows and closed.
- Page 23 For Service & Support Contact Support Portal: You can register your Warranty Open a Support Ticket support.airconditioningcentre.com Email:support@airconditioningcentre.com Tel: 03703 344 345 Air Conditioning Centre is a division of Martin Industries Ltd Rev04.20...
