Summary of Contents for Chapter Qube Reference 500M
- Page 1 Chapter Qube Reference 500M Qube Reference 500M Quick Start Guide...
- Page 2 Functions 1. Left touch sensor options a. Front LED brightness control b. Internal LED brightness control 2. Right touch sensor options a. Input display b. Input toggle c. Input Earth Select c. Input Earth Select 3. Standby button options a. Mute b.
- Page 3 1. Left touch sensor options Front LED brightness control To change the brightness of the front panel and standby panel blue lights, press and hold the LEFT touch sensor strip on the blue lights, press and hold the LEFT touch sensor strip on the front panel for 4-5 seconds until the front panel lights start to flash.
- Page 4 Please ensure that the unit is not in “MUTE” mode, and that none of the AGND & HOT connection (AGND is with Chapter front panel RED Lights are illuminated or are flashing before starting. floated from the chassis via a...
- Page 5 2. Right touch sensor options Input Toggle You can toggle between the XLR and RCA inputs by using the Right touch sensor strip. Right touch sensor strip. Please ensure that the unit is not in “MUTE” mode, and that none of the front panel RED Lights are illuminated or are flashing before starting.
- Page 6 You can enter and exit “STANDBY” mode by pressing and holding the STANDBY touch sensor for more than 2 seconds. Touch Sensor Operation The Qube Reference 500M uses state of the art QPROX touch sensor technology first developed by QPROX for the Apple iPod.
