- Page 1 PRO 100 Smart Projector User Manual...
-
Page 2: User Notice
Product Information Product Name: WEMAX PRO 100 Model: M135FGE-Pro Manufactured by: Formovie (Chongqing) Innovative Technology Co., Ltd. Address: 4-401, #2 Longgang Road, Guojiatuo Area, Jiangbei District, Chongqing, China WEMAX®, a brand of Ampula Inc., Bellevue, WA 98005... -
Page 3: Product Overview
Product Overview Exterior Lens Speaker Mesh TOF Module Camera Ports Speaker Right Air Inlet Speaker Heat Dissipation Vents Rubber Feet Power Button 1/4'' Female Threaded Tripod Mount (length 6mm) Caution : - Do not place any flammable objects near the heat dissipation vent. - Page 4 Suspended Ceiling Installation Suspended ceiling installation is one of the installation methods that you hang the projector in an overhead location, for example, on a high ceiling, through a ceiling mount. A projector supporting suspended ceiling installation has threaded holes on the bottom, you can install the project on the mount by attaching the screws into the holes.
-
Page 5: Connection Ports
Connection Ports ① ③ HDMI 2 - HDMI input port 2 HDMI 1(ARC) - HDMI input port 1 - (ARC) Audio return channel port USB 2.0 - Supports USB 2.0 communication protocol ② ④ USB 2.0 - Supports USB 2.0 communication protocol - Headphone port S/PDIF... - Page 6 Remote Control Power: Xifo!uif!qspkfdups!jt!pgg-!tipsu!qsftt! up!uvso!po/ Xifo!uif!qspkfdups!jt!po-!tipsu!qsftt! up!pqfo!uif!nfov-!mpoh!qsftt!up!uvso! pgg!uif!qspkfdups/ Voice: Mpoh!qsftt!uif!wpjdf!dpouspm!cvuupo! boe!ubmljoh!dmptf!up!uif!sfnpuf!dpouspm/ Launch Board: Bddftt!uif!mbvodi!cpbse! joufsgbdf/ Navigation Pad: Npwf!up!vq-!epxo-!mfgu-!ps! sjhiu-!uifo!qsftt!uif!njeemf! up!dpogjsn/ Home: Sfuvso!up!ipnf!tdsffo/ Return: Sfuvso!up!uif!qsfwjpvt!nfov/ Menu: Tipsu!qsftt!up!bddftt!uif!qspdftt! nbobhfs-!mpoh!qsftt!up!bddftt!uif! mbvodi!cpbse/ Volume: Jodsfbtf!uif!wpmvnf< Efdsfbtf!uif!wpmvnf/! Pairing the Remote Control: Ipme!uif!sfnpuf!dpouspm!dmptf!up!uif! qspkfdups!xjuijo!b!ejtubodf!pg!31!dn-!uifo! tjnvmubofpvtmz!qsftt!uif!Nfov!cvuupo!boe! uif!Ipnf!cvuupo!up!qbjs/! Caution: - Pay attention to the positive and negative poles when installing batteries in the remote control.
- Page 7 Quick Start Guide1 Note: The user interface will be updated from time to Power on/off Plug in the power adapter, then press the power button to turn on. When the projector is on, press the power button on the top to open the power options, then press the power button again to shut down.
- Page 8 Auto Focus is enabled by default, moving the projector will automatically trigger the screen to focus. To turn it off, go to > Image > Auto Focus. 【Settings】 08:08 lmage and Sound / lmage Screen Focus Adjust the focus distance of the projector Auto Focus The lens focal length can be automatically adjusted when the projection distance changes...
- Page 9 Auto Obstacle Avoidance & Auto Screen Alignment Auto Obstacle Avoidance & Auto Screen Alignment are enabled by default. If the projector is moved, it will automatically detect objects in the projection area and scale the image to avoid it. If screen is used, the projector will match the projected image with your screen automatically during auto screen adjusting process.
- Page 10 System Press 【Launch Board】 button on the remote control or select 【Launch Board】 in the shortcut menu bar at the top of the homepage to access the launch board interface. All installed Apps can be found on this page. 08:08 Settings File Manager Cast Projection...
- Page 11 Intellectual Temperature Control The LED light source and motherboard temperature are monitored by the projector's system, and the fan's speed is automatically adjusted based on the temperature detected by the sensor. - The projector has two brightness modes to choose from when operating at a normal temperature.
- Page 12 Daily Maintenance Heat Dissipation Outlet Note: Avoid touching the heat dissipation vent on the rear, as it can become very hot Note: Do not place any objects within 20 cm of the projector's air vents, as this will affect the heat dissipation effect. Cleaning Be sure to clean the projector casing and lens regularly using the...
- Page 13 Troubleshooting Fault Solution No projected image Restart the projector. If the problem remains, try tabbing the reset hole to reset the projector. System crashes Restart the projector. If the problem remains, try tabbing the reset hole to reset the projector. Screen display error Restart the projector.
- Page 14 说明书制作说明 1. 成品尺寸：80x140mm 2. 材质：105g哑粉 3. 印刷颜色： 单色 PANTONE Cool Gray 11 C 4. 装订方式：风琴折 说明书版本变更 版本 说明 时间 新版发行 2020.02.25 遥控器更新 2020.04.20 更新UI，增加FengOS系统介绍 2020.08.20...
- Page 15 Product Certifications This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 16 Product Certifications Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. For DTS patents, see h p://patents.dts.com. Manufactured under license from DTS, Inc. (for companies headquartered in the U.S./Japan/Taiwan) or under license from DTS Licensing Limited (for all other companies).
