Savoye Dining Chairs – Important,
Do not tighten the bolts of the chair during assembly
until the chair back has been inserted into the arms (Step
3 in the assembly process). Due to the design of the
chair, if the arms are fully tightened before the back is
inserted, the back will not fit into the designated holes.
Please keep all bolts loose during the assembly process
so that there is some room for movement and adjustment.
Once the back has been inserted into the chair arms, then
fully tighten all bolts.
If you have questions regarding assembly of this product,
please contact us at 855-766-3949.
Thank you,
Please Read Carefully.
P. . 1/3
Advertisement
Table of Contents
Summary of Contents for ADALYN HOME AL350SR
- Page 1 Savoye Dining Chairs – Important, P. . 1/3 Please Read Carefully. Do not tighten the bolts of the chair during assembly until the chair back has been inserted into the arms (Step 3 in the assembly process). Due to the design of the chair, if the arms are fully tightened before the back is inserted, the back will not fit into the designated holes.
- Page 2 P. 2/3 AL350SR/AL350SN/AL350SK/AL350SG ASSEMBLY INSTRUCTIONS STEP 2 STEP 1 STEP 3 Completed Step 1: Attach the Seat Box with Seat Cushion (B) to RSF Arm Chair With Leg (C) by inserting Flat Washer (4), Spring Washer (3), Short Bolt (2) into the holes at the side bar of the Seat Box with Seat Cushion (B).
- Page 3 P. 3/3 PARTS LIST CHAIR BACK SEAT BOX WITH SEAT (1PC) CUSHION (1PC) (C) RSF ARM CHAIR WITH (D) LSF ARM CHAIR WITH LEG (1PC) LEG (1PC) HARDWARE PACK # : PAL350SH Q'TY DESCRIPTION SIZE Long Bolt 4 pcs 6 pcs Short Bolt 10 pcs Spring Washer...
