Summary of Contents for Hunterhelp MASTER 3
- Page 1 Speak the language of nature! HUNTERHELP MASTER 3 USER MANUAL...
- Page 2 Hunterhelp M3. Designed to attract birds and animals for viewing, taking pictures of, or culling for sanitary or research purposes, Hunterhelp М3 is a dedicated digital sound producing device. It reproduces the audio pieces recorded as special format tracks on a plug-in memory card.
- Page 3 2. SPECIFICATIONS 85.5 х 128 х 33 Dimensions, mm Weight (with batteries out), g 170 Maximum power, W Frequency response, Hz 20 - 20 000 External power, V 9 (6 АА batteries) Internal power supply, V Recommended radiating resistance, Ohm Bitrate/track discretization 16 bits/48 kHz...
- Page 4 ‘up’ selection key ‘down’ volume ‘up’ volume ‘down’ ‘hot’ key: shortcut to pre-selected track light sensor Figure 1: Hunterhelp M3 design and control elements...
- Page 5 4. GETTING STARTED Internal batteries installation Press the locking mechanism to remove the battery cover. Insert the batteries (6 AA batteries or accumulator cells) observing the polarity. Note! Use only alkaline batteries. Use of zinc-carbon batteries may result in faulty operation. External power supply Remove the rubber cover to plug the external power source (battery) into connector 3 (Fig.1).
- Page 6 hard on the memory card when inserting it into the call. • To avoid data loss do not insert the memory card in set with the call into a PC card reader; do not remove the memory card when the call is 5.
- Page 7 Note! The number and the names of folders with calls may vary depending on the sound library recorded on the memory card. The original Hunterhelp card may have the maximum of 8 folders. Each folder may contain up to 99 tracks.
- Page 8 Press keys 10 and 11 to select track. Press 8 to play. The display will show the track name, running and full time, and loudness scale. The playback mode allows for switching to ‘hot track’ (without having to stop the playback). The ‘hot track’ switching is available on both the channels by pressing keys 10 and 11 to move within the track list.
- Page 9 To adjust the equalizer settings: press 12 and 13 to select the frequency scale and 10 and 11 to adjust the settings. After you have moved the cursor (using keys 12 or 13) to the target range, press 8 to activate/deactivate the equalizer mode in the upper left-hand corner.
- Page 10 6. MAIN MENU ITEMS The main menu consists of two sub-menus – SETTINGS and MY FOLDER. To enter the main menu, press 7. Press 10, 11 to select and 8 to enter the target menu item. To escape from the selected menu item, press 9. All user settings will be saved when the device is switched off.
- Page 11 indicated by a tick (in the upper left hand corner of the display). The absence of the tick means the function is inactive. Press 8 to activate/deactivate repeat. Pause setting Pause setting enables user to set the duration of pauses between cycles of a repeating track.
- Page 12 6.1.3 Remote control To operate the call remotely (using a radio channel), the call must be connected to the remote control device. Hunterhelp М3 can be connected to only one remote control device, whereas one remote control device can be connected to as many calls as you wish.
- Page 13 ‘Disconnect’ To disconnect the remote control from the call, the ‘Disconnect’ sub- menu and press 8. The ‘Remote control disconnected’ message will appear on the screen: To escape to settings menu, press 9. To escape to folder or track list, press 7.
- Page 14 To escape to settings menu, press 9. To escape to folder or track list, press 7. All the settings will be saved. 6.2 MY FOLDER menu item My Folder menu item enables you to create and edit lists of frequently played tracks (up to 10 tracks).
- Page 15 The created playlist will be available in MY FOLDER, located on the general folder list. Delete call ‘Delete Call’ edits your playlist. To select the track to be deleted, press 8. The screen will show the ‘Call deleted’ message: To escape to settings menu, press 9. To escape to folder or track list, press 7.
- Page 16 7. TROUBLESHOOTING Malfunction Possible cause Malfunction repair • Too short pressing on Hold key 6 pressed for 2 to key 6. 3 seconds. • AA batteries depleted. Replace batteries. The device won’t start. • External power source Replace external power generates voltage under source.
- Page 17 8. WARRANTY Thank you for the choice of our product. We guarantee trouble-free operation of Hunterhelp S3 provided you observe the operating rules specified in this user manual. Warranty repair will be denied if the product shows signs of 1. mechanical damage of its display, connectors or other components;...
- Page 18 9. Details of dealer Serial number ___________________________________ Dealer’s name ___________________________________ __________________________________ Dealer’s stamp Date of sale _______________ 10. Manufacturer Lema LLC 3 Okruzhnoye Shosse, Bld.1, 163045 Arkhangelsk Tel. (8182) 29-77-27, 46-03-66 Fax (8182) 29-77-27 e-mail: info@hunterhelp.ru...
