- Page 1 Operation and Maintenance Manual Manufacturer Address: Ducts and Cleats 200 W. Plato Blvd. St. Paul, MN 55107 Phone: 651-265-0600 Email: info@ductsandcleats.com...
-
Page 2: A Note About Safety
A Note About Safety Read and understand the manual before operating ISO-Aire equipment. Only plug the unit into a grounded outlet. Unit must be electrically grounded. Insert 3-prong plug on power cord directly into matching grounded receptacle. Do not use with an adapter. Keep wiring and motor dry. - Page 3 A Note About Safety WARNING WARNING WARNING ELECTRICAL SHOCK HAZARD PERSONAL INJURY OR PROPERTY DAMAGE Failure to follow this warning could result in personal HAZARD injury or death. Failure to follow this warning could result in personal Disconnect all electrical power to the unit before injury or property damage.
- Page 4 Une note sur la sécurité AVERTISSEMEMT AVERTISSEMEMT WARNING RISQUE DE CHOC ÉLECTRIQUE RISQUE DE BLESSURE CORPORELLE OU DE Le non-respect de cet avertissement peut entraîner des DOMMAGE MATÉRIEL blessures corporelles ou la mort. Le non-respect de cet avertissement peut entraîner des Débranchez toute l'alimentation électrique de l'unité...
- Page 5 ISO-Aire Thank you for purchasing an ISO-Aire system. ISO-Aire is a family of commercial air purifiers designed to provide clean air through proven technology. ISO-Aire is the ideal solution for facilities to protect staff and customers by adding filtration capability to their facilities. ISO-Aire utilizes a medical-grade HEPA filter with a combination of options such as ozone-free bipolar ionization and UVC sterilization.
- Page 6 Startup and Install The ISO-Aire commercial air purifier is easy to install and plugs into a standard 110 volt outlet. The startup process is as follows: Determine desired location for unit (ensure 1-2 ft of space around the intake for proper airflow); Adjust grille fins if needed for desired air path;...
-
Page 7: Specifications
Specifications Power Requirements and Filtration 300 & 400 CFM Models (RSF250, RSF300) 2,000 CFM Models (RSF2000) Power Requirements: 115 VAC/Single Phase/60hz Power Requirements: 115 VAC/Single Phase/60hz Motor: 1 HP Motor: 1/10 HP Filtration: HEPA 99.9%, 0.3 μ filter; MERV-8 pre-filter Filtration: HEPA 99.99%, 0.3 μ... -
Page 8: Pre-Filters
Pre-Filters ISO-Aire uses a MERV-8 pre-filter to extend the life of the HEPA filter. A high capacity, extended-life pre- filter is available for purchase from ISO-Aire which provides a longer lifespan compared to standard pre- filters. A standard pre-filter is a common filter that can be purchased from many suppliers or retail stores (the same kind used in a typical furnace). -
Page 9: Hepa Filters
HEPA Filters ISO-Aire uses a medical-grade and high capacity HEPA filter. When ordering a replacement filter use the part number below to purchase from the OEM filter the unit came with. Failure to use proper filtration will void warranty and could result in damage or decreased performance out of the system. Ensure minimum efficiency of 99.99% at .3 microns. - Page 10 UVC Sterilization (Optional) ISO-Aire is available with UVC sterilization which has been carefully designed into our unit to ensure efficacy and proper exposure / duration to pathogens. The UVC is properly contained within the ISO-Aire system to prevent exposure to occupants without proper PPE. Anytime the unit is being serviced and is equipped with UVC, the unit should be turned off and the UVC unplugged.
- Page 11 UVC Sterilization Installation If you've ordered an ISO-Aire unit equipped with UVC, the bulbs and housing are shipped loose to prevent damage to the UVC during transit. Installation of the UVC once the unit is in place is easy. This is the same procedure for installing replacement bulbs.
- Page 12 Ozone-Free Bipolar Ionization (Optional) ISO-Aire uses a UL 2998 listed needle point bipolar ionization device that is ozone-free and available on all models. Bipolar ionization emits positive and negative ions which helps to neutralize pathogens and causes them to also agglomerate and fall to the floor. The bipolar ionization is also effective on mold, odors, VOCs, allergens, and other airborne contaminants.
- Page 13 Fan Speed Setting Selection ISO-Aire uses a long-life and high quality, variable speed ECM fan to provide the desired fan speed and CFM output. The speed controller is located next to the on/off switch and can be adjusted as needed. Use the tables below based on your model for CFM at various fan speed %.
-
Page 14: Filter Maintenance
Filter Maintenance RSF250 & RSF300 Series (non UVC equipped) For RSF250 and RSF300 without UVC, before replacing the HEPA or pre-filter ensure unit is first turned off. See pages 5 and 6 for filter part numbers, sizes, and service intervals. To replace the HEPA, first slide out the enclosure resting tabs on the left and right side so that the enclosure does not fall when the screws are removed in step 2 (See Figure A). - Page 15 Filter Maintenance RSF250 & RSF300 Series (non UVC equipped), Continued When all 11 screws have been removed, the enclosure is now ready to be removed. Simply lift straight up and clear the inner core and set the enclosure off to the side. Now that the inner core is exposed, remove the lower bolt on each filter bracket (one on each side, 4 total) (See Figure D), then lift the fan assembly back on the filter.
- Page 16 Filter Maintenance RSF300 Series (UVC equipped) For RSF300, before replacing the HEPA or pre-filter, ensure the unit is first turned off. See pages 5 and 6 for filter part numbers, sizes, and service intervals. To replace the HEPA, release the enclosure for removal from the inner core by removing the 11 screws along the bottom on each side of the main body (3 screws on the front, left, and right sides;...
- Page 17 Filter Maintenance RSF300 Series (UVC equipped), Continued When all 11 screws have been removed, the enclosure is now ready to be removed. Simply lift straight up and clear the inner core and set the enclosure off to the side. Now that the inner core is exposed, remove the lower bolt on each filter bracket (one on each side, 4 total) (See Figure D), then lift the fan assembly off of the filter.
- Page 18 Filter Maintenance RSF500 and RSP1000 Series Before replacing the HEPA or pre-filter ensure unit is first turned off. See pages 5 and 6 for filter part numbers, sizes, and service intervals. The HEPA filter is secured using a tensioning mechanism which holds the filter secure in place. To replace, remove the rear service panel (see Figure A).
- Page 19 Filter Maintenance RSF1000 Series (Gen 2 - Current) Series Before replacing the HEPA or pre-filter ensure unit is first turned off. See pages 5 and 6 for filter part numbers, sizes, and service intervals. The HEPA filter is secured using a tensioning mechanism which holds the filter secure in place. First, remove the main rear service panel by removing the 14 screws (see Figure A).
- Page 20 Filter Maintenance RSP750, RSF750 CFM, FSF1000 Series (Gen 1, obsolete) Before opening the access door and changing filters or performing maintenance, be sure to turn off unit. Replacing the pre-filter or HEPA filter requires removal of the access door. Lift up using the handle and pull the bottom outwards.
- Page 21 Filter Maintenance RSH800 and RSH1000 CFM Hanging Models Before opening the access door and changing filters or performing maintenance, be sure to turn off unit and unplug the UVC if equipped. Replacing the pre-filter can be done through the access door, it is secured with two sliding tabs at the bottom.
-
Page 22: Limited Warranty
For a period of twelve (12) months from the date of purchase, that all products and components, excluding filters, will be free from defects in material and workmanship under normal use and service. Ducts and Cleats, Inc Limited Warranty will not apply when the failure is from causes beyond Ducts and Cleats control. Such events or circumstances include, but are not limited to the following: Acts of nature, and/or weather related events;...
