Assembly Instructions &
Parts List for EZPinball
Cabinet.
Model Number
EZStern‐01

Advertisement

loading
Need help?

Need help?

Do you have a question about the EZStern-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for EZPinball EZStern-01

  • Page 1 Assembly Instructions &  Parts List for EZPinball Cabinet. Model Number  EZStern‐01...
  • Page 2 Items Needed to assemble your EZPinball Cabinet Titebond #2 Wood Glue Wood Glue Brush Base Cabinet Screws Back Box Trim Screws Volume Control Screws Ratchet Strap (Two Preferred)
  • Page 3 Parts Needed to assemble the  Base Cabinet...
  • Page 5 Assembling the Base Cabinet Step 1 – Locate Item #2, 3, 4, and 5. Lay the panels on a flat surface as  shown on the photo on the left. Step 2 – With a ratchet strap dry fit the panels  together to ensure all corners are tight  and free from interference.   Note the  cabinet is assembled with the bottom  of the cabinet facing up Step 3 – Dry fit Item #6 (Support Strut) in the  dado joints as shown in the photo on  the left Step 4 ‐‐ Apply Titebond #2 to all  corners and support struts.  Secure  with ratchet strap.  Remove excess glue  from corners both internal and  external.   Use a Ratchet Strap to secure  the panels together. Optional ‐‐ use two or more ratchet  straps to create tighter corners.
  • Page 6 Step 5 – Immediately install Item 1 (Bottom  Panel) in the orientation shown in the  photo to the left after gluing the side  panels.  This ensures perfect 90° corners while the glue dries.   Optional – You can glue in the bottom  panel or use the screws provided. Step 6 – Rotate the cabinet 180° so it is facing  up.  Glue and insert Item 6 (Support  Strut) at the rear of the cabinet.  The  strut should be below the top of the  side panel.  Wipe away excess glue. Step 7‐‐ Dry fit Item #7 (Head & Neck Mount  Panel) with the recessed cut facing the  front of the cabinet as shown.  Glue the  panel to the cabinet and wipe away  excess glue. Step 8 ‐‐ Locate Item #8 (Right Side Playfield Lift  Bracket) noting the hole cut in this  piece.  Glue this piece into it’s  corresponding channel on the plunger  side of the cabinet panel.  Wipe away  excess glue.
  • Page 7 Step 9 – Glue in Item #11 (Prop Rod Holder)  ensuring this piece has a hole drilled  through it.  It will be placed on the right  cabinet panel below the Right Side  Playfield Lift Bracket. Step 10 ‐‐ Glue in Item #9 (Left Side Playfield Lift  Bracket.)  It will attach to the  corresponding channel on the left  cabinet panel. Step 11 – Item #10 (Left & Right Playfield  Support) will be game dependent to  allow the playfield to be supported in  the left and right cabinet panels.   Optional, use screws to mount the  supports to allow movement if you  should decide to change themes later.
  • Page 8 Step 12 ‐‐ Allow the cabinet glue to dry 24 to 48  hours before removing the ratchet  strap(s). Optional – Lightly sand the entire cabinet once dry  to remove any remaining excess glue. Step 13 – Glue in Item #12 (Front Leg Bolt  Support) in the corners closest to the  front door.  Ensure that the leg bolts  will easily fit from the front of the  cabinet through these blocks.  Wipe  away excess glue. Step 14 – Glue in Item #13 (Rear Leg Bolt  Support) in the corners closest to the  back box.  Ensure that the leg bolts will  easily fit from the front of the cabinet  through these blocks.  Wipe away  excess glue.
  • Page 9 Parts Needed to assemble the  Back Box...
  • Page 10 Assembling the Back Box Step 1 ‐‐ Locate Items 15, 16, 17, 18, 19, 20, &  Lay the panels on a flat surface as  shown on the photo on the left. Step 2 – Dry fit the two side panels, cabinet top,  and cabinet bottom to ensure panels  are tight and free from interference.   Remove top and bottom panels noting  the alignment of the side panels.  Apply  Titebond glue and reassemble Items  #17 & #18 (Side Panels).  Wipe away  excess glue. Step 3 – Apply glue to Item #16 (Bottom Panel)  and assemble.  Wipe away excess glue.
  • Page 11 Step 4 – Apply glue to Item #19 (Top Panel) and  assemble.  Wipe away excess glue.  Use a Ratchet Strap to secure the  panels together making sure the strap  is oriented at least 2” from the front of  the cabinet. Step 5 – Using the Back Box Trim screws pre‐ install the screws in the left side panel  with 1/16” protruding as shown in the  photo. Step 6 – Take Item #20 (Left Side Trim) and  secure the screws to the panel. Step 7 – Using the Back Box Trim screws pre‐ install the screws in the right side panel  with 1/16” protruding as shown in the  photo.  Secure Item #21 (Right Side  Trim) by tightening the three screws.
  • Page 12 Step 8 – Using the Back Box Trim screws pre‐ install the screws in the top side panel  with 1/16” protruding as shown in the  photo. Step 9 – Take Item #22 (Top Trim) and secure  the screws to the panel. Step 10 – Take Item #24 (Insert Panel Support)  and glue into the back box so it is flush  with the left side of the cabinet and  flush with the front of the main left  cabinet side panel as shown in the  photo to the left.  This gap needs to  accommodate the backglass and lift rail Step 11 – Glue Item #25 (Lower Backglass Support) to the bottom back box panel  as shown in the photo on the left.   It is STRONGLY recommended you use  either smalls nails or countersunk  screws to fasten this panel as the entire  weight of the backglass will rest upon  it.  ...
  • Page 13 Step 12 – Wipe away excess glue and Allow the  back box glue to dry 24 to 48 hours  before removing the ratchet strap. Optional – Lightly sand the entire back box once  dry to remove any remaining excess  glue.
  • Page 14 Parts Needed to assemble the  Neck connecting the base  cabinet to the head.
  • Page 15 Assembling the Neck Step 1 – Locate Items #27, #28, #29, #30 Lay the panels on a flat surface as  shown on the photo on the left. Step 2 – Ensure Item #29 (Rear Support) is  facing up allowing the power cord to  lay in this notch once assembled.  Using  Titebond #2 glue the four supports  together and wipe away excess glue.  Allow the glue to dry 24 to 48 hours  before removing the ratchet strap(s).  Step 3 – Place the Neck assembly onto Item #7  of the base cabinet and glue the neck  assembly to the base cabinet ensuring  neck is flush with the back of the  cabinet and properly centered. It is  STRONGLY recommended you use  either small nails or countersunk  screws to fasten this panel as the entire  weight of the back box will rest upon it.   Optional – Lightly sand the entire cabinet once dry  to remove any remaining excess glue.
