Orange-Casual
5-Pieces Conversation Set
WK-OC-21Y-02
1
Thank you for choosing Orange-Casual!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it Immediately. Send us an email at
help@orange-casual.com.
If you are not satisfied with our
customer service, pls send your comments to
complaint@orange-casual.com.
Happy?
Please leave us a review!
You can make others happy too!

Advertisement

loading
Need help?

Need help?

Do you have a question about the WK-OC-21Y-02 and is the answer not in the manual?

Questions and answers

Related Manuals for Orange-Casual WK-OC-21Y-02

Summary of Contents for Orange-Casual WK-OC-21Y-02

  • Page 1 Orange-Casual 5-Pieces Conversation Set WK-OC-21Y-02 Thank you for choosing Orange-Casual! Our goal is to provide high quality outdoor furniture with outstanding customer service-all at an affordable price. Please let us know how we are doing! Problems? (Missing pieces, wrong pieces...) We will fix it Immediately.

  • Page 2: At The End Of The Season

    IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Safety For domestic use only.   Don't tighten all the bolts before the product is fully assembled.   It would be useful to ask someone to help you assemble the product. ...
  • Page 3 Tips for Cushions In order to compress the package, we put the cushions in the gap of some parts. So there may be crinkle on the fabric. Don’t worry. Just flap every corner of the cushion evenly and it will get back into its original shape soon. - 2 -...
  • Page 4 COMPONENT LIST - ARMCHAIR X 2 Item Reference Description Qty. Image Seat Base Right Armrest Left Armrest Seat Back Washer M6X35 Head Cap Screws Allen Key Seat Cushion Pillow - 3 -...
  • Page 5 NOTE: When tightening the screws, tighten sequentially. DO NOT tighten any screws fully and then move on to the next one. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned,loosen the screws and execute this same process.
  • Page 6 Attach the Seat Back (D) to the Right Armrest (B) and Seat Base (A) by securing with Head Cap Screws (F) and Washers (E). Do this in 3 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 5 -...
  • Page 7 Attach the Left Armrest (C) to the Seat Back (D) and Seat Base (A) by securing with Head Cap Screws (F) and Washers (E). Do this in 4 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 6 -...
  • Page 8 Tighten all 9 Screws into place with Allen Key (G). NOTE: IF ANY SCREW HOLES CANNOT BE ALIGNED, LOOSEN ALL THE SCREWS AND GO BACK STEP 1 AND RESTART ASSEMBLY. Place the chair on a level surface, then place Seat Cushion (H) and Pillow(P) on the chair.
  • Page 9 COMPONENT LIST - TABLE Item Reference Description Qty. Image Table Top Table Leg Table Leg Back Panel Table Bottom Washer M6X35 Head Cap Screws Allen Key - 8 -...
  • Page 10 NOTE: When tightening the screws, tighten sequentially. DO NOT tighten any screws fully and then move on to the next one. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned,loosen the screws and execute this same process.
  • Page 11 Attach the Back Panel (M) to the Table Leg (K) and Table Top (J) by securing with Head Cap Screws (F) and Washers (E). Do this in 2 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 10 -...
  • Page 12 Attach the Table Leg (L) to the Table Top (J) and Back Panel (M) by securing with Head Cap Screws (F) and Washers (E). Do this in 2 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 11 -...
  • Page 13 Attach the Table Bottom (N) to the Table Legs (L) &(K) and Back Panel (M) by securing with Head Cap Screws (F) and Washers (E). Do this in 3 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 12 -...
  • Page 14 Tighten all 8 Screws into place with Allen Key (G). NOTE: IF ANY SCREW HOLES CANNOT BE ALIGNED, LOOSEN ALL THE SCREWS AND GO BACK STEP 1 AND RESTART ASSEMBLY. Place the table on a level surface and adjust height for balance. Your table is ready for use.
  • Page 15 COMPONENT LIST - OTTOMAN X 2 Item Reference Description Qty. Image Ottoman Side Panel Connecting Rod Washer M6X30 Head Cap Screws M6X15 Head Cap Screws Allen Key Seat cushion - 14 -...
  • Page 16 NOTE: When tightening the screws, tighten sequentially. DO NOT tighten any screws fully and then move on to the next one. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned,loosen the screws and execute this same process.
  • Page 17 Attach the Connecting Rod (U) to the Side Panels (T) by securing with M6*15 short Head Cap Screws (V) and Washers (E). Do this in 2 places. NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY. - 16 -...
  • Page 18 Tighten all 8 Screws into place with Allen Key (G). NOTE: IF ANY SCREW HOLES CANNOT BE ALIGNED, LOOSEN ALL THE SCREWS AND GO BACK STEP 1 AND RESTART ASSEMBLY. Place the Ottoman on a level surfaceand adjust height for balance,then place Seat Cushion (W) on the ottoman.
