Summary of Contents for EASEWELL EW-16003SP
- Page 1 Manual Book EASEWELL MASSAGE CHAIR EW-16003SP Please read this manual carefully before using the product, and keep the operation manual in good condition for reference.
- Page 2 FCC CAUTION This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
-
Page 3: Table Of Contents
EW-16003SP MASSAGE CHAIR Thank you for purchasing this product, please read this manual in detail before you use it to learn the correct use of this product. Please pay special attention to important safety warnings and keep the operation manual in good condition for reference. -
Page 4: Important Safety Warnings
Important Safety Warnings to use product. use this product properly to prevent you and others from being hurt or damaged. Caution: If used incorrectly, the user may be harmed, or the items may be harmed or damaged, which includes the damage to houses, household property, livestock, and pets. - Page 5 The following people must consult your doctor before using: Patients with cancers Maternal or menstrual period High fever Patients with acute illness (painful) Patients with osteoporosis Patients with perceptual disturbance Cardiopath Anemia Users of cardiac rhythm devices or other implanted devices Spine abnormalities or curvatures People receiving treatment or feeling physically abnormal For use in previously treated or injured areas...
- Page 6 Before using, please make sure that you are not wearing any accessories to avoid injury. Please control the massage time within 15 minutes. In addition, please control the massage time of the same part within 5 minutes. Continuous massage for too long may cause muscle and nerve pain.
- Page 7 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
-
Page 8: Chair Installation
Chair Installation Remove main body and accessories from the packing box Accessories Main Body Left/Light Side Panel Remote Control Bracket Foot Massager Headrest Backrest Cover Manual Book Kits Power Cord... - Page 9 Chair Installation Installation Guideline Installation of Foot Massager I, Installation of Foot Massager 1, Align the foot machine with the connecting holes on both sides of the seat and insert rivets and plug. * Figure ① 2, Use rivets and plug to dock the seat bottom putter with the foot machine putter.
- Page 10 Chair Installation Installation of side panels Step I 1, Align the holes of the inner panel with the mounting holes of the seat frame by locking 5 screws. Figure ① (M6x20 hexagon socket screw*1, M6x20 round head screw*5) 2, Install air bags into the air inlet connector which must be connected with the corresponding colors;...
- Page 11 Chair Installation Step two 3, After the installation of the inner panel is completed, install the outer panel should push the fixed latch firstly from front to back, then use 3.5x16 round head pointed tail lock. sliding direction 3.5x16 round head pointed tail Step Three 4, When installing the upper cover of the left armrest, install the hand controller bracket first, and then slide into the fixed mortise.
- Page 12 Chair Installation Massage Chair Placement Please place the massage chair in a flat place, and space should be left around the chair. When placing the massage chair, be sure to leave enough space around the chair so that the legs and backrest of the chair can rise and fall freely. It is recommended to place a cushion under the product to avoid damage to the ground or carpet.
-
Page 13: Names Of Parts And Function
Names of parts and function Massage chair Speaker and mood lightening Headrest Please turn to the back side Waist and back heating while massage Shoulder Armrest Air pressure massage for Air pressure massage for arms shoulder Backrest Quick Zoom Buttons massage the entire back Adjust the intensity quickly Quick Adjust Buttons... - Page 14 Hand Controller Key Functions Hand Controller Home Page Timing Display and adjustment Fault Number Display Setting 5 languages & Screen brightness adjustment Massage Mode Display Fixed Point Adjustment Neck & Shoulder Adjustment For Manual mode only Air Bag action real-time display Back and Waist Heat Massage Strength Adjustment 7 levels...
-
Page 15: Before Each Massage
Before Each Massage Connect to the Power 1. Plug the power plug into the socket 2. Turn on the power switch (It is located below the back of the seat.) Items to Check 1. Check the surroundings Confirm that there are no people, no pets, and no objects around the back of the massage chair or below the legrest. -
Page 16: Adjustment Method Of Chair
Adjustment method of Chair Sitting Posture Adjustment A. Hand Controller - Sitting Posture Adjustment Interface 1. Press to enter the sitting posture adjustment interface, there are 4 sitting modes: is Zero Gravity is Cradle is Lie Down is get up 2. -
Page 17: Automatic Massage Programs
Quick Start - Connecting the power of the chair. - Pressing the on/off button located on the back of the chair next to the electrical plug. - Remove shoes and sit in the chair. - Press the button, the initial touch screen displays as below. - Page 18 Automatic Massage Programs 3. After detection is complete. The touch screen will show your back curve as shown on the right. Then the chair will start the massage program. 4. The touch screen displays the automatic program currently in the massage. Timing Display and adjustment Home Page Setting...
- Page 19 Automatic Massage Programs 8. Calf and Feet heat: touch to turn on or turn on the heat function for calf and feet. 9. Air-pressure Adjustment: touch to increase the pressure, and touch to decrease the pressure. When the intensity is reduced to 0, the air pressure function is turned off. When the pressure intensity is increased from 0 to 1, the Master Recommended mode is turned on by default.
-
Page 20: Basic Massage Methods
Basic Massage Methods Touch the manual mode on the screen to select the preferred program. Basic Methods Knead Up Deep Knead 1 Bottom-up kneading massage From bottom to top massage muscles Knead Down Deep Knead2 Kneading massage from top to bottom Knead muscles powerfully from top to bottom Rolling Neck Relax... - Page 21 Quick Start - Connecting the power of the chair. - Pressing the on/off button located on the back of the chair next to the electrical plug. - Remove shoes and sit in the chair. - Press the button, the initial touch screen displays as below.
-
Page 22: Manual Massage Mode
Manual Massage Mode 4. Under the manual program, the massage position can be selected from 4 options: full body, shoulder & neck, waist & hip, Spot. 5. Massage speed adjustment: touch to select from three speed: "strong, medium, and weak". This function may be not available for all massage methods. selected, and the blue means not been selected yet. -
Page 23: Air Pressure Mode
Air-Pressure Massage Mode Quick Start - Connecting the power of the chair. - Pressing the on/off button located on the back of the chair next to the electrical plug. - Remove shoes and sit in the chair. - Press the button, the initial touch screen displays as below. - Page 24 Air-Pressure Massage Mode 3. The touch screen displays the manual program currently in the massage. Timing Display and adjustment Home Page Setting Massage position Massage mode display Neck & Shoulder Massage Roller Position Adjustment Back & Hip heating Air pressure Calf &...
-
Page 25: Other Functions
Other Functions 1. Settings Bluetooth 2. Bluetooth ， 3. Timing 4, Quick Zoom Buttons Stop the massage halfway Anti-Pinch Function... -
Page 26: Cleaning And Storage
Cleaning and Storage Cleaning Instructions Cleaning the Chair Synthetic Leather Wipe off the synthetic leather with a soft dry cloth. directions for use. 1. Soak a soft cloth into a solution of 3% to 5% neutral detergent a nd hot water. Wring it out. 2. -
Page 27: Troubleshooting
Troubleshooting Never disassemble, repair or modify the chair without permission. This may cause sparks or injuries due to abnormal operation. During the massage, the following sounds or feelings are caused by the structure, they are not abnormal, and they’ll have no effect on the service life. The sound of the massage rollers moving up and down. -
Page 28: Maintenance & Warranty
Maintenance & Warranty Maintenance Check if the following If you haven't phenomena occur? used it for To prevent malfunctions many years, or accidents, turn off the power and unplug the be sure to Stop and plug are power plug. Be sure to ask for Using abnormally hot... -
Page 29: Product Specification
The Company reserves the right to make improvements to the products and to explain improvemen product is subject to change without prior notice. The ts. The appearance of the product is based on the physical object.
