Summary of Contents for Aqua Blaster FE100
- Page 1 FE100 MANUAL Custom Elite Manufacturing, LLC · PO Box 968 · Lake Geneva, WI 53147...
- Page 2 ASSEMBLY INSTRUCTIONS The Aqua Blaster belly plate unit is shipped assembled. The water flow components and adjustable locking clamp are ready to use. The Aqua Blaster height adjustment range is 4”. VELCRO STRIPS BELLY PLATE STEP 1. Attach radiused vertical Velcro pieces to belly plate.
- Page 3 FRAME FRAME TOP MIDDLE SECTION SECTION STEP 4. Attach frame top section to frame middle section with two ¼” – 20 x ¾” carriage bolts and two ¼” - 20 serrated flange lock nuts. HOOKS FRAME TOP FRAME SECTION MIDDLE SECTION STEP 5.
- Page 4 PARTS LIST PART NO. DESCRIPTION Belly plate unit, shipped completely FE100-P0000 assembled FE100-P0005 Belly plate only FE100-P0009 Belly plate pad FE100-P0001 Arm hook FE100-P0008 Arm hook pad FE100-P0002 Frame top section FE100-P0003 Frame middle section FE100-P0004 Frame bottom section FE100-P0006...
- Page 5 Aqua Blaster. Arm hook and belly pads are not fire resistant. Make sure the Aqua Blaster is pointed in a safe direction before charging. During freezing conditions, the Aqua Blaster must be drained when not in use to prevent damage.
- Page 6 LIMITED WARRANTY 1/1/2020 The following warranty is the only warranty applicable to Custom Elite Mfg., LLC (CEM) products, and to the maximum extent permitted by law, overrides any other conditions or warranties expressed or implied on CEM products. Other than legislative obligations to the contrary, CEM will not be liable for any incidental or consequential damages arising from the ownership or use of a Product.
