- Page 1 User Manual 45M626U1UK-02 For maschine type: NOVOSUPERVISION™ FV-626 CF2 Kernel 8.2 Austrian Gaming Industries GmbH © 09 2008 Wiener Strasse 158 A-2352 Gumpoldskirchen Austria Europe Tel.: +43-2252-606 www.austrian-gaming.com e-mail: support@novomatic.com...
- Page 2 AUSTRIAN GAMING INDUSTRIES GmbH gives no guarantee and accepts no legal responsibility (neither as a liability nor in any other way) for any errors and consequences that may arise from incorrect statements or incorrect use.
-
Page 3: Table Of Contents
T A B L E O F C O N T E N T S Table of contents 6.2.2 Cleaning of the coin acceptor 1 Legend and safety precautions ......5 MC40 ..........128 Legend ............5 6.2.3 Cleaning of the coin optics board .. 129 Safety precautions ........ - Page 4 T A B L E O F C O N T E N T S Key panel module ........185 7.8.1 Pin assignment ......185 7.8.2 Exchange of the key panel module 186 Top light ........... 187 7.9.1 Exchange of the top light ....189 7.9.2 Exchange of the top light illumination ........
-
Page 5: Legend And Safety Precautions
L E G E N D A N D S A F E T Y P R E C A U T I O N S L E G E N D Legend and safety precautions Legend DANGER Risk of electric shock with possible serious injury or death. WARNING Warning of a possible injury or death. -
Page 6: Safety Precautions
L E G E N D A N D S A F E T Y P R E C A U T I O N S S A F E T Y P R E C A U T I O N S Safety precautions The below service instructions are for use by authorised or trained personnel only! The owner of the machine has to ensure that all service work is performed only by qualified or trained... -
Page 7: Warning
L E G E N D A N D S A F E T Y P R E C A U T I O N S S A F E T Y P R E C A U T I O N S •... - Page 8 For safety reasons any exchange of defective parts has to be accomplished with original or manufacturer-approved parts. Spare parts that were not delivered by Austrian Gaming Industries are not tested and not approved by Austrian Gaming Industries. The manufacturer accepts no liability for damage that results from the use of components and spare parts that are not original or manufacturer-approved.
-
Page 9: Machine Data
M A C H I N E D A T A D I M E N S I O N S Machine data Dimensions Z_626CF2_Abmessungen.eps Illustr. 2-1 Machine dimensions NOVOSUPERVISION™ (in mm) 45M626U1DE-02 © 09 2008 AGI GmbH... -
Page 10: Operating Elements
M A C H I N E D A T A O P E R A T I N G E L E M E N T S Operating elements Attendant keyswitch Door-in-Door lever Coin slot Bill insertion Main door lock Main door lever Drop door lock F_626CF2_Gesamtansicht.jpg... -
Page 11: Components
M A C H I N E D A T A C O M P O N E N T S Components F_626CF2_Komponenten.jpg Illustr. 2-3 Description of components NOVOSUPERVISION™ 1 Top light 8 Ticket printer 14 COOLFIRE II backplane 2 Topper 9 Monitors 15 Stacker box 3 Square top frame illumination... -
Page 12: Technical Data
M A C H I N E D A T A T E C H N I C A L D A T A Technical data Machine type FV-626 CF2 NOVOSUPERVISION™ Dimensions (depending on model) 540 mm without base 1354 mm (without Topper) 1726 mm (with Topper) 413 mm Dimensions (depending on model) -
Page 13: Block Diagram
M A C H I N E D A T A B L O C K D I A G R A M Block diagram N PE N PE Z_BD_CF2_DL_UK.eps Illustr. 2-4 Block diagram NOVOSUPERVISION™ 45M626U1DE-02 © 09 2008 AGI GmbH... - Page 14 M A C H I N E D A T A B L O C K D I A G R A M 45M626U1DE-02 © 09 2008 AGI GmbH...
-
Page 15: Power Up
P O W E R U P I N S P E C T I O N ( D A M A G E S C A U S E D B Y T R A N S P O R T ) Power up Inspection (damages caused by transport) Remove the shipping carton and the material used to secure machine components during transport... -
Page 16: Power Up
P O W E R U P P O W E R U P Power up Before start check the line voltage. The machine has been designed to sustain 230 V ± 10 %, 50 Hz or 110 V ± 10 %, 60 Hz. Make sure that the line voltage corresponds to the voltage indicated on the machine. -
Page 17: Error Handling
E R R O R H A N D L I N G E R R O R H A N D L I N G Error handling 4.1 Error handling Attendant keyswitch F_626CF2_Schluesseschalter.jpg Illustr. 4-1 Attendant keyswitch for error handling If an error occurs, the machine will interrupt the current game and switch automatically to failure mode. -
Page 18: Explanation For Clearing Errors
E R R O R H A N D L I N G E X P L A N A T I O N F O R C L E A R I N G E R R O R S Explanation for clearing errors Locate the error code according to the tables on the next pages. - Page 19 E R R O R H A N D L I N G E X P L A N A T I O N F O R C L E A R I N G E R R O R S CAUTION If an error message is triggered by a malfunction of non-activation of individual meters the device must be removed from operation and the meters circuit board must be exchanged.
-
Page 20: 4.3 Software Error Message
E R R O R H A N D L I N G S O F T W A R E E R R O R M E S S A G E 4.3 Software error message 4.3.1 Overview of possible errors Event messages (can be viewed in the AUDIT MENU under EVENTS) 8 - Stacker full 27 10 - Bill rejected...
