Summary of Contents for globalpayments LSX4100
- Page 1 LSX4100 Coin Hopper Guide – March 24th, 2021 LSX4100 Coin Hopper Quick Guide March 24th, 2021 1 of 5...
- Page 2 LSX4100 Coin Hopper Guide – March 24th, 2021 Revision History Version Date Author Comments 3-24-21 Susan Initial Draft Anderson 2 of 5...
- Page 3 LSX4100 Coin Hopper Guide – March 24th, 2021 Coin Hopper Overview The LSX4100 Coin Hopper is located in the Top Cabinet, which can be accessed by unlocking the cabinet door. Once the door is unlocked, the cabinet door slides up, providing access to the Coin Hopper.
- Page 4 LSX4100 Coin Hopper Guide – March 24th, 2021 2. Locate the cable on the backside of each hopper. Press the tab in the middle of the connector to disconnect the cable from the harness. 3. Push hopper towards the coin drop path to disconnect from base and lift.
- Page 5 LSX4100 Coin Hopper Guide – March 24th, 2021 Troubleshooting the Coin Hopper Use the following diagnostics to help troubleshoot issues with the Coin Hoppers 1. Failure to open COM port (COM5) and get status of hoppers a. Check the coin control board for the LED light indicating DC power.
