Anchor 1.4 User Manual
DIMENSIONS
WEIGHT
POWER SUPPLY
POWER
REQUIREMENTS
TEMPERATURE
RADIO RANGE
UWB ANTENNA
WARM-UP TIME
PLACEMENT
*DEPENDS ON LINE OF SIGHT CONDITIONS, RADIO SETTINGS AND ENVIRONMENT
Sewio Networks, s.r.o,
V1.2
www.sewio.net,
70x74x25 mm
72g
USB or Passive PoE
1.5W
USB DC 5V, ≈ 300mA
Passive PoE 48V, ≈ 30mA
0 – 50 °C
15-50m*
Omnidirectional
20 minutes
For Indoor Use Only
Office, Warehouse, and Light industry environment.
email:info@sewio.net
1
Advertisement
Table of Contents
Related Manuals for Sewio Anchor 1.4
Summary of Contents for Sewio Anchor 1.4
- Page 1 Anchor 1.4 User Manual DIMENSIONS 70x74x25 mm WEIGHT POWER SUPPLY USB or Passive PoE POWER 1.5W REQUIREMENTS USB DC 5V, ≈ 300mA Passive PoE 48V, ≈ 30mA TEMPERATURE 0 – 50 °C RADIO RANGE 15-50m* UWB ANTENNA Omnidirectional WARM-UP TIME...
- Page 2 Never connect “Power+Data” ports to the computer or other network devices. When the Anchors are connected to a stable power supply, a blue LED should start to blink on the side of the enclosure. Sewio Networks, s.r.o, V1.2 www.sewio.net, email:info@sewio.net...
- Page 3 2) Go to the Anchors’ Settings tab. Change the IP address of each Anchor here. To confirm, press the “Update” button: Then the IP reconfiguration is finished and you should see the address changed in the RTLS Manager. Make sure that the reconfigured Anchor is online. Sewio Networks, s.r.o, V1.2 www.sewio.net, email:info@sewio.net...
