- Page 1 RP-AFRM Non-Powered Awning Installation Manual...
-
Page 2: Parts And Components
& Parts Components CONTENTS Package Components............4 Preparation................5 Installation...............6-11 Steps to Extend..............12 Steps to Retract............14-15 Maintence................16 □ ITEM DESCRIPTION □ Fabric sail track □ Fabric roller □ Frame set left arm □ Frame set right arm □ Upper mount bracket □... -
Page 3: Package Contents
Preparation Package Contents 1.Open the package and check to make sure that all the parts and accessories are included. 2.Prepare your installation tools, including an electric drill, pliers, measuring tape, screwdriver, and pencil. 3.Using the below picture, note points A, B, C, and D. These points will need to be fixed directly to the RV. -
Page 4: Installation
Do not fix D bracket to RV 8' 9' 10' 11' 12' 13' 14' 15' 16' 17' 18' 19' 20' 21' 3" Please ensure the arms are vertical to the ground and parallel to each other. 5⅛" " " " Step 5 Attach fabric lock rail. - Page 5 Connect Arms Step 6 Step 8 Connect the fabric roller. Take out the roller connector from the tube, located in ATTENTION the left and right end caps. Then, connect the tube piece by piece. Align the holes The awning roller has been pre Connect the left arm.
- Page 6 ATTENTION To tension springs, awning must be in the extended position. These fabric tubes come pre-tensioned, however, if the tension fails or is otherwise unsatisfactory, they can be re-tensioned. To add tension to fabric tubes: Remove fabric tube from both arms. With the right side, use a screwdriver and insert it through the tension hole.
- Page 7 Release the arm locks on each Lift up the arms by opening the handle lock on the outer arms and Release the arm locks on each side. side.Switch down the spring lock on the stretching them as long as you would like (ranging from 6 feet to 9 ½ feet). fabric tube with pull rod.
- Page 8 Step 7 Step 8 Steps for retracting the awning Holding tension on the pull strap, turn up Close the arm locks on both sides. the safety spring lock on the fabric tube. Step 1 Step 2 Loosen the Pull out the pegs wheel lock on from the bottom each arm.
-
Page 9: Warranty Information
DO NOT allow dirt, leaves, or other debris to accumulate on the awning, as this could RecPro Awning Assemblies are covered under warranty for a period of 1 cause abrasion and stains. Mildew could grow on dirt and organic debris, causing year and includes replacement or refunds for shipping or manufacturing permanent discoloration, stains, and odors to awning fabric.
