Summary of Contents for Caper 2
- Page 1 USER MANUAL SMART SHOPPING CART Model 2 Caper – V011.0 Copyright © 2021-2022 Instacart Inc. All Rights Reserved...
-
Page 2: Table Of Contents
TABLE OF CONENTS IMPORTANT SAFETY INSTRUCTIONS ..................3 Read All INSTRUCTIONS BEFORE USE ................... 3 Technical Safety ........................4 Operation Safety…………………………………………………………………………………………………………………4 Charging Safety ......................... 5 Maintenance Safety ......................... 6 Disposal Safety ......................... 6 SPECIFICATIONS & DIMENSIONS ..................... 7 Front View ............................ 7 Top Module .......................... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the device. The guidelines are separated into “WARNINGS” and “CAUTION” as described below. This symbol is displayed to indicate matters and opearations that can cause risk. Read the part with this symbol carefully and follow the instructions in order to avoid risk. -
Page 4: Technical Safety
Technical Safety • This product can be used by children aged from years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instructions concerning use of the device in a safe way and understand the hazards involved. -
Page 5: Charging Safety
Charging Safety • Do not modify the power plug provided with the product. If it does not fit the outlet, please talk with manufacturer and replace the defect power plug, or have a proper outlet installed by a qualified electrician. •... -
Page 6: Maintenance Safety
Maintenance Safety • Disconnect the device from the power supply (power cable and battery) before cleaning the device. Turn off the switch does not disconnect the device from power supply. • Do not repair or replace any part of the device. All repairs and servicing must be performed by qualified service personnel unless specifically recommended in this User’s Manual. -
Page 7: Specifications & Dimensions
SPECIFICATIONS & DIMENSIONS ● Appearance and specifications may change without notice to improve the quality of the product. Front View Top unit heat sink Bottom unit fence Bottom unit cover Payment terminal 5-inch rear wheels Front Cover Top unit main LED light bar 5-inch front wheels Top unit CV camera PC Side Panel... -
Page 8: Top Module
Top Module Payment Terminal Barcode Scanner Top unit encasing LCD touch screen Personal Basket Side LED indicator Produce - Camera Cup holder IR sensor lens Side LED Indicator Handrail... -
Page 9: Top View Dimensions
Top View Dimensions 560 mm 322.6 mm 580 mm 516 mm 261.3 mm 358.6 mm... -
Page 10: Side View Dimensions
Side View Dimension 1156 mm 1040 mm 929 mm 496 mm 993 mm 1118 mm... -
Page 11: Five Cart Stacking Dimension
Five cart stacking dimensions 2718.36 mm 1600 mm... -
Page 12: Specifications
Specifications AIOC3399 Operating System Android Charger input voltage AC100V∽240V Charging condition DC24V,6.25A Battery output 21-18V, 8A Battery life 24 hours (Stand by); 10 hours (normal usage) Battery capacity INR 18650 3200 mAH * 18 = 57600 mAh, 367.0*206.0*58.1mm, SBS1.1, Imax=8A Charging time Approx. -
Page 13: Extra Options And Functions
Extra Options and Functions This feature is only available if client choose to install specific accessories and services. • OTA update • Magnetic Charging • Charging Station • Silicone Waterproof P/T Cover... -
Page 14: Operations
1 - Basic Shopping - Transaction Overview 1. Shopper taps on “Start Shopping!” Button 2. Shopper goes through Onboarding Tutorial by tapping "NEXT" 3. At the end of tutorial, shopper taps “I’m Ready” to begin shopping. 4. Shopper takes any item and puts it in the cart. Barcode must be clearly visible to any of the cameras facing the inside of the cart 5. -
Page 15: Add Produce And Plu Items
2 - Add Produce and PLU items A. Adding by Quantity Steps 1. Shopper starts on Shopping Home screen 2. Shopper taps on “Add Item Without Barcode” 3. Shopper searches for item by PLU or Name 4. Shopper puts produce into the cart 5. - Page 16 B. Adding by Weights Steps 1. Shopper starts on Shopping Home screen 2. Shopper taps on “Add Item Without Barcode” 3. Shopper searches for item by PLU or Name 4. Shopper puts produce into the cart 5. Cart stabilizes and calculates weight of the produce 6.
-
Page 17: Removing Items From The Shopping List
1. Items can be removed directly from the cart. The cart uses computer vision and weight logic to determine what has been taken out of the cart. 2. Item card will be automatically removed from the shopping list. *If the cart cannot confirm what was removed, shopper will be prompted with a "Multi-Match Removal"... - Page 18 1. Items can also be removed by first tapping on the trash can icon next to the item name on your shopping list. 2. Shopper will be prompted to take item out of your cart. 3. Item can be removed from the cart 4.
-
Page 19: Checking Out
4 – Checking Out 1. When shopper is done shopping, shopper taps “Checkout” 2. Shopper is directed to make their way to checkout area. 3. Shopper taps "Pay for Cart" 4. Shopper confirms prices and taps "Pay $__." 5. Shopper instructed to insert or swipe credit card into card reader 6. -
Page 20: Staff Audit
5 – Staff Audit 1. Store Admin reaches shopping home screen. 2. Admin taps on "HELP" on the top right corner of the screen 3. Admin taps on "Person" icon 4. Admin logs in with following information Username/Password: Please inquire Caper staff 5. -
Page 21: Maintenance
• Never use harsh chemicals, abrasive cleaners, or solvents to Cleaning SOP: clean the device. They may damage the finish. 1. Cleaning the exterior 2. Cleaning the basket 3. Cleaning the bottom unit 4. Cleaning the top unit 5. Cleaning the battery housing... -
Page 22: Troubleshooting
Our smart shopping cart is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the device does not function properly or does not function at all. Check the table below before calling Caper Service Center. -
Page 23: Leagl And Regulation
FCC Identifier, any warning statements, or other information that the Commission’s rules would otherwise require to be shown on a physical label attached to the device (See 47 CFR § 2.935) - Page 25 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 26 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
