Thank you for including the KP7, 7 button keypad, as part of
the user interface strategy for your customer. The KP7 has been
designed to provide years of trouble free operation when wired
and installed properly. The KP7 has been designed for installation
in low humidity environments and should never be installed
outdoors or in high humidity areas.
Included in the box
1ea KP7 keypad
10ea Alternate key caps
2ea Mounting screws
1ea Quick Install Guide (this document)
Introduction
To install the KP7 you will need a standard 1 gang box rated
for 20 cu. in. or more.
© 2015 Core Brands, LLC. All rights reserved.
Core Brands, LLC, a Nortek company.
KP7 – Keypad
Quick Install Guide
Specifications
Dimensions
4.12" x 1.75" x 1.24"
104.65 mmm x 44.45 mm
x 31.5 mm
Buttons
5 individually capped
2 shared for rocker capping
LED
5 individually controlled white
2 shared control white
Network
10/100/1000
Connections
LAN/PoE
RJ-45
Power Requirements
PoE IEEE 802.3at,
13 W maximum draw
(@48V
P/N 9901364 Rev. B 02/2015
/ 270 mA max.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Core Brands KP7

  • Page 1 1ea Quick Install Guide (this document) • 2 shared control white Network 10/100/1000 Introduction Connections To install the KP7 you will need a standard 1 gang box rated LAN/PoE RJ-45 for 20 cu. in. or more. Power Requirements PoE IEEE 802.3at, 13 W maximum draw (@48V / 270 mA max.)
  • Page 2 Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Install in accordance with the manufacturer’s instructions. 8.
  • Page 3 The KP7 requires a mounting depth of at least 1 ¾” (4.5cm) and it is recommended that a 20cu in or larger switch box or a 1 gang low voltage bracket be used. The KP7 will gang with other low voltage devices utilizing a standard decorator-style trim plate.
  • Page 4 B120R (old work) 20 cu in junction box or virtually any low voltage bracket. If you plan to use a different brand box please verify that the KP7 will fit without issue. 20 cu. in. New Const. Junction Box 20 cu.
  • Page 5 Bezel Connecting the KP7 The KP7 is powered by the output of a PoE Ethernet switch or by a PoE injector. The KP7 cannot be directly powered by a power supply. If you have terminated the CAT-5 wiring be sure to continuity test the wire before connecting the KP7. Insert the RJ-45 connector into the receptacle on the rear of the KP 7 and listen for the tab to click.
  • Page 6 Mounting the KP7 Being careful not to pinch the CAT5 wire, slide the KP7 into the box and secure with the included screws. The KP7 fits a standard decorator-style opening and is gangable with other low voltage decorator-style devices. Note the MAC ID of the KP7 on your System Worksheet to assist with programming completion.
