Outdoor Bed Swing
SHOPPING LIST
• 8 Eyebolts (4 for the bed and 4 for the ceiling)
• Approximately 24' of chain (for a standard 8' ceiling)
• 3 – 2×6 boards (8' or stud length)
• 2 - 2×4 boards (8' or stud length)
• 12 – 1×2 Furring Strips, 8' Length
Outdoor Bed Swing
• 6 – 1×3 Furring Strips, 8' Length
CUT LIST
• 2 – 2×6 @ 76 ½" (Support Frame Sides)
• 2 – 2×6 @ 37 ½" (Support Frame Ends)
• 2 – 2×4 @ 73 ½" (Cleat Supports)
• 12 – 1×3@ 37 ½" (Slats)
• 2 ½" Screws*
• 1 ¼" Nails*
• Wood Glue
• Finishing Supplies
• Twin Mattress
*Choose exterior fasteners for exterior applications
• 8 – 1×2 @ 40 ½" (End Trim)
• 8 – 1×2 @ 78" (Side Trim)
culpeperwood.com
15487 BRAGGS CORNER ROAD
P.O. BOX 1148
CULPEPER, VA 22701
(800) 817-6215
Advertisement
Summary of Contents for Culpeper KK050520
- Page 1 • 8 – 1×2 @ 78” (Side Trim) • 2 – 2×6 @ 37 ½” (Support Frame Ends) • 2 – 2×4 @ 73 ½” (Cleat Supports) • 12 – 1×3@ 37 ½” (Slats) 15487 BRAGGS CORNER ROAD culpeperwood.com P.O. BOX 1148 CULPEPER, VA 22701 (800) 817-6215...
- Page 2 STEP 1 STEP 2 Use 2 1/2″ screws and glue to build your support frame. I would use 3 screws per corner. Check fo Use 2 ½” screws and glue to build your support frame. Recommend 3 screws per corner. Check for square. STEP 2 Attach your cleats ¾”...
- Page 3 STEP 3 A more expensive wood can be used here (while keeping the stud grade frame) to make the lounger bed even more refined looking. Bottom and end edges are flush, top will create a lip for you bed to keep it from sliding off the platform. STEP 4 STEP 4 Add side trim just like the end trim.
- Page 4 STEP 5 STEP 5 STEP 6 STEP 6 Predrill and install the eye bolts in the corners as shown above. It is very important that the eye bolts are attached to the longer 2×6, as the weight of the bed will be transferred from the slats to the cleats to the side 2x6s and then to the...
