Summary of Contents for AVECO ASTRA Server 1U
- Page 1 ASTRA Server 1U Technical Reference Sheet TRS-1020-03...
- Page 2 ASTRA Server 1U Technical Reference Sheet TRS-1020-03 Aveco www.aveco.com Publication Date: April 2020 Copyright © 2020 Aveco All product and application features and specifications are subject to change at Aveco's sole discretion at any time and without notice. ASTRA Server 1U TRS-1020-03...
-
Page 3: Table Of Contents
Power Supply LED Status ......................6 List of Figures 1. ASTRA Server 1U ..........................1 2. ASTRA Server 1U - Front Panel Schematic ..................3 3. ASTRA Server 1U - Back Panel Schematic ..................3 4. Pinout of GPI Connectors - GPI 1.1 ....................4 5. -
Page 4: Introduction
INTRODUCTION OVERVIEW Aveco’s automation servers are industrial PC computers with a mission critical real-time operating system QNX. Automation software consists of a large set of dedicated software modules that can be used to build the required solution, from all-in-one automation server providing MCR and Studio automation together with the MAM, up to large networks of geographically distributed redundant automation servers, always acting as one automation system. -
Page 5: Package Contents
ASTRA Server 1U Technical Reference Sheet PACKAGE CONTENTS When delivering ASTRA Server 1U, Aveco will include the server unit and only the power cables necessary to supply power to the server. Content ASTRA Server 1U Power cable, 1m VRP6 Card (optional) Package Contents ©... -
Page 6: Technical Specifications
ASTRA Server 1U Technical Reference Sheet TECHNICAL SPECIFICATIONS ASTRA SERVER SPECIFICATIONS Figure 2. ASTRA Server 1U - Front Panel Schematic Control Panel USB2 USB2 Figure 3. ASTRA Server 1U - Back Panel Schematic Optional VRP6 Card IPMI GPI 1.1 EXT. REF. -
Page 7: Server Connectors
ASTRA Server 1U Technical Reference Sheet SERVER CONNECTORS (OPTIONAL) VRP6 CARD CONNECTORS Figure 4. Pinout of GPI Connectors - GPI 1.1 © 2020 Aveco Technical Specifications Version:TRS-1020-03 Server Connectors... -
Page 8: Operation
ASTRA Server 1U Technical Reference Sheet OPERATION CHASSIS CONTROL PANEL The chassis control panel is found in the upper right corner of the front panel. The control panel contains a power button, reset button, and several LED indicators. Figure 5. Chassis Control Panel POWER ON THE SERVER The server is switched on using the POWER button on the front panel of the server. -
Page 9: Hard Disk Led Status
ASTRA Server 1U Technical Reference Sheet NIC1: Indicates network activity on GLAN1 when flashing. NIC2: Indicates network activity on GLAN2 when flashing. HDD: Indicates SAS/SATA activity when flashing. Power: Indicates power is being supplied to the system’s PSUs. This LED is normally illuminated when the system is powered on. - Page 10 ASTRA Server 1U Technical Reference Sheet Drive Carrier LEDs Solid Amber System is powered off but plugged in Blinking Amber Internal temperature is at or above 63°C and will shut down if the temperature reaches 70°C The Information LED on the chassis control panel will also indicate a power failure.
