- Page 1 Assembly Instruction GEOHOME Pet Bedside Table : I602-40 / I602-41 MODEL DIMENSION : 60 cm(W) x 60 cm(D) x 65.7 cm(H) TOOL REQUIRED MADE IN MALAYSIA...
- Page 2 EXPLODED VIEW IMPORTANT NOTE: Place all wooden parts on a clean and smooth surface suchas a rug or carpet to avoid the parts from being scratched. Check to be sure that you have all parts and hardware. Remove all wrapping materials, including staples & packing straps before you start to assemble. Do not tighten all screws/bolts until all completely assembled.
- Page 3 PARTS LIST TOP PANEL 1 PC CENTER PANEL 1 PC BOTTOM PANEL 1 PC BACK PANEL 1 PC SIDE PANEL 1 PC DOOR SIDE PANEL 2 PCS DOOR PANEL 2 PCS MADE IN MALAYSIA...
- Page 4 HARDWARE LIST LONG POLE 4 PCS SHORT POLE 4 PCS 4 PCS WOOD DOWEL 17 PCS MAGNET 4 PCS FLAT SCREW 4 PCS DOOR SPRING 4 PCS SUPPORT LEG 2 PCS MADE IN MALAYSIA...
- Page 5 STEP 1 CENTER PANEL 1 PC 1 PC BOTTOM PANEL MAGNET 4 PCS STEP 2 DOOR PANEL 2 PCS FLAT SCREW 4 PCS DOOR SPRING 4 PCS TOOL REQUIRED MADE IN MALAYSIA...
- Page 6 STEP 3 BACK PANEL 1 PC 1 PC SIDE PANEL DOOR SIDE PANEL 2 PCS WOOD DOWEL 17 PCS STEP 4 TOP PANEL 1 PC SHORT POLE 4 PCS MADE IN MALAYSIA...
- Page 7 STEP 5 ASSEMBLED UNIT 1 PC CENTER PANEL LONG POLE 4 PCS STEP 6 YOU CAN CHOOSE DOOR SIDE LEFT OR RIGHT ASSEMBLED UNIT LEFT RIGHT BACK PANEL 1 PC SIDE PANEL 1 PC DOOR SIDE PANEL MADE IN MALAYSIA...
- Page 8 STEP 7 ASSEMBLED UNIT MAGNET SIDE BOTTOM PANEL 1 PC 4 PCS * LEFT DOOR SIDE SHOWN. STEP 8 ASSEMBLED UNIT SUPPORT LEG 2 PCS MADE IN MALAYSIA...
- Page 9 STEP 9 ASSEMBLED UNIT STEP 10 ASSEMBLED UNIT DOOR PANEL 2 PCS MADE IN MALAYSIA...
- Page 10 Recommended Maximum Weight *Unit in Pound(lbs.) WARNING: >This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. >DO NOT allow children to climb on unit. > Put heavier items on lower shelves. MADE IN MALAYSIA...
