Summary of Contents for INNOVASUB Nerites FX-I
- Page 1 Nerites FX-I INSTRUCTION MANUAL 2014 Copyright © Bogazici Uluslararası Egitim Dan Mrk ve Ltd Ş 01.11.2014...
- Page 2 WARNING! Nerites FX-I is not a dive computer and does not replace a dive computer. It does not alert the diver in case of risk of Decompression Sickness (DCS). It does not alert the diver in case of low pressure of air or gas mix in the tank.
- Page 3 In case of failure or need of maintenance of Nerites FX-I, contact Innovasub. CAUTION! Do not use compressed air to blow water off the Nerites FX-I. Do not use solvents or other cleaning fluids that might cause damage. Do not test or use the unit in pressurized air. WARNING! The Nerites FX-I functions at a maximum depth of 100m.
- Page 4 Figure 11 - Nerites - USB Interface – Live Diagnostic ...............17 © INNOVASUB, Rasimpasa Mh. Yavuzturk Sk No: 32/1, 34716 Kadikoy Istanbul - TURKEY Phone: +90 216 337 95 59 Fax : +90 216 330 21 15 / E-mail: info@innovasub.com...
- Page 5 1. WELCOME TO NERITES FX-I SYSTEM 1.1. What is it? Nerites FX-I is a patented technology that monitors the breathing of the diver. It will emit a loud sound underwater in case the diver stops breathing in order to alert his dive buddies and the surrounding divers.
- Page 6 Figure 1 – Nerites FX-I Components Figure 2 - Nerites FX-I Components © INNOVASUB, Rasimpasa Mh. Yavuzturk Sk No: 32/1, 34716 Kadikoy Istanbul - TURKEY Phone: +90 216 337 95 59 Fax : +90 216 330 21 15 / E-mail: info@innovasub.com...
- Page 7 Nerites FX-I Instruction Manual www.innovasub.com Figure 3 - Nerites FX-I LEDs © INNOVASUB, Rasimpasa Mh. Yavuzturk Sk No: 32/1, 34716 Kadikoy Istanbul - TURKEY Phone: +90 216 337 95 59 Fax : +90 216 330 21 15 / E-mail: info@innovasub.com...
- Page 8 1.3. Connecting Nerites FX-I to Your BC Use the quick connectors of Nerites FX-I to plug it between the Low Pressure hose of your regulator and the BC inlet as displayed in the figures below. Do not open the tank pressure before ensuring that the Nerites FX-I is properly connected.
- Page 9 To start the device, press the button once. Each LED should blink once, followed by a buzzer short sound. Your device is now running and ready for diving. Nerites FX-I will turn off after 3 minutes of inactivity or if the button is pushed three times in a row.
- Page 10 The alarms are the primary and most important function of Nerites FX-I and are describe in the table below. The alarms are active while Nerites FX-I is ON, meaning they can be triggered if their conditions are met. The buzzer sound triggered by the alarm can be turned off by pressing the button.
- Page 11 Nerites FX-I if the USB/Battery LED is blinking red. In order to charge the battery, plug a USB cable to the Nerites FX-I to either a PC or a USB charger adaptor. There is no need for the Nerites FX-I to be mounted on diving equipment for charging its battery.
-
Page 12: Usb Interface
3.1. Information Page Figure 6 – Nerites - USB Interface – Information Page © INNOVASUB, Rasimpasa Mh. Yavuzturk Sk No: 32/1, 34716 Kadikoy Istanbul - TURKEY Phone: +90 216 337 95 59 Fax : +90 216 330 21 15 / E-mail: info@innovasub.com... - Page 13 Figure 7 - Nerites - USB Interface – Download Dive Logs Page 3.3. Parameters The USB Interface allows you to modify the parameters for the use of Nerites FX-I. Namely: X1: the time without breathing before the Breathing Low Alarm triggers ...
- Page 14 You can adjust the values of the parameters on this page and press Apply to apply the new values to the Nerites FX-I. © INNOVASUB, Rasimpasa Mh. Yavuzturk Sk No: 32/1, 34716 Kadikoy Istanbul - TURKEY Phone: +90 216 337 95 59 Fax : +90 216 330 21 15 / E-mail: info@innovasub.com...
- Page 15 3.4. Live Diagnostic The Nerites FX-I must be mounted on a BC, connected to a scuba regulator hose and the tank pressure must be open (as if ready to dive) in order to run a live diagnostic. The live diagnostic allows you to run live measures on the Low Pressure hose and check whether the Low Pressure is within the desired range.
- Page 16 3.5. Firmware Update The firmware update can be done when Innovasub notifies you of a major update for the Nerites FX-I firmware. In such case, you will receive or will have downloaded a firmware file provided by Innovasub. In the Firmware Update of the USB Interface, you will need to select the firmware file and click Run Firmware Update.
- Page 17 Figure 11 - Nerites - USB Interface – Live Diagnostic © INNOVASUB, Rasimpasa Mh. Yavuzturk Sk No: 32/1, 34716 Kadikoy Istanbul - TURKEY Phone: +90 216 337 95 59 Fax : +90 216 330 21 15 / E-mail: info@innovasub.com...
