INCLUDED IN THE PACKAGE
INDEX
A
B
C
D
E
F
G
H
I
J
DESCRIPTION
PMB (Power Management Box)
Pressure Vessel (with T-connector)
Pump Unit
Solar Panel
25mm tube (0,8m)
16mm Air Outlet Tube (0,8m)
8mm Air Hose
Extension kit (3 pcs)
Spowdi tool
Extra Membrane (Spare part)
QTY
1 pcs
1 pcs
1 pcs
1 pcs
1 pcs
1 pcs
1 pcs
1 kit
1 pcs
1 pcs

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mobile Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Spowdi Mobile Pro

  • Page 1 Pump Unit 1 pcs Solar Panel 1 pcs 25mm tube (0,8m) 1 pcs 16mm Air Outlet Tube (0,8m) 1 pcs 8mm Air Hose 1 pcs Extension kit (3 pcs) 1 kit Spowdi tool 1 pcs Extra Membrane (Spare part) 1 pcs...

  • Page 2: Before Installing

    BEFORE INSTALLING Info: The Spowdi Mobile Pro pump is developed to be used with a Spowdi drip BEFORE YOU irrigation kit. The system works best when the START 1 highest point of the irrigation area is less than 5 meters above the water source surface and less than 50 meters from the water.
  • Page 3 INSTALLING PART 1 - CONNECTING THE SOLAR PANEL AND CHARGING THE SYSTEM Unfold the Solar Panel (D) and connect the STEP 1 short cables on the inside using the power connectors. Connect the Solar Panel (D) to the PMB (A) STEP 2 with the longer cables using the matching power connections on the backside.
  • Page 4 PART 2 - ASSEMBLY OF THE SYSTEM Connect the Pressure Vessel (B) and the Pump Unit (C) using the 25mm Tube (E) (either the STEP 5 0,8m included for flat ground or if you have prepared a longer tube for an elevated area) Connect the 16mm Air Outlet Tube (F) to the Pump Unit (C) by pushing it into the 16mm air STEP 6...
  • Page 5 Turn off the system and prepare your Spowdi Drip Kit (or whatever you want to connect to your Spowdi Mobile Pro). Then connect it to the free end of the T-connector on the STEP 12 Pressure Vessel (B).
  • Page 6 PART 4 - OPTIMIZING THE SYSTEM Start the pump with the receiving system connected and in use (if you are using Spowdi Drip Kit, open the valves to start irrigating), let STEP 13 the pump run for a few minutes, so the...

  • Page 7: Part 4 - Optimizing The System

    PART 4 - OPTIMIZING THE SYSTEM Turn off the system by pressing the front STEP 17 button on the PMB (A), and take the Pump Unit (C) out of the water. Remove the Filter Can on the Pump Unit (C) by STEP 18 using the golden screws on top of it.
  • Page 8 Note! These values are only recommendations and you might find an other 100-200 setting, optimal for your intended use of the Spowdi Mobile Pro. When you are done, attach the Filter Can on STEP 22 the Pump Unit (C) using the golden screws.
  • Page 9 Kit (H). Disconnect the tube you want to STEP 25 prolong, cut the length that you need and connect it between the extension part and the intake/outtake. The system is now complete, and you can STEP 26 enjoy the Spowdi Mobile Pro pollution-free timesaving water pumping.

  • Page 10: Maintenance

    - Wipe the Solar Panel with a damp cloth. MAINTENANCE: - Do not expose the PMB to direct sunlight or water. - To change the membrane, read the specific manual for this or ask your Spowdi Agent. Periodically have service done by a Spowdi SERVICE: ackredited service agent.
