Information Provided in this Exhibit:
Assembly Drawing – Page 2
Assembly Parts List Expanded View – Page 3 is an expanded view of the parts list from the
Assembly drawing of page 2
Product Information Primer – Pages 4-11. There are no tune- up procedures for the hardware
device itself. During installation, the hardware is positioned for best signal transmission and
reception as well as proper polarization. The Product Information Primer supplies information for
installation and adjustment.
4/5/00
Exhibit 10 – Parts List/Tune –up Information
SpectraPoint Wireless LLC
Customer Premises Equipment Roof Unit 2.0
FCC ID: NNSRTU2000-00
Model Number: RTU2000-28-3
Exhibit 10
FCC ID: NNSRTU2000-00
Advertisement
Summary of Contents for SpectraPoint 2000
- Page 1 Exhibit 10 – Parts List/Tune –up Information SpectraPoint Wireless LLC Customer Premises Equipment Roof Unit 2.0 FCC ID: NNSRTU2000-00 Model Number: RTU2000-28-3 Information Provided in this Exhibit: Assembly Drawing – Page 2 Assembly Parts List Expanded View – Page 3 is an expanded view of the parts list from the Assembly drawing of page 2 Product Information Primer –...
- Page 4 ™ SpectraPoint 2000 Rooftop Unit (RTU) Model No. RTU2000-28-3 Product Information Primer 24 in. 13 in. 610 mm 330 mm Antenna 26 in. 680 mm Mast* Pivot Bolts* *Note: Penetrating Roof Mounts (consisting of mast, pivot bolts, and foot) are sold separately.
- Page 5 ™ RTU Equipment Parts Part Model Number RTU-2000-28-3 SP2000 Rooftop Unit, NA-A Band Plan, Version 2.0 Each of the models listed above include the following parts: • RTU antenna assembly with electronics card • Antenna mount clamp bracket • Product Information Primer (PIP), SP2000 Series RTU...
- Page 6 ™ 2. Secure the mount foot into a sturdy surface to provide a secure base for the mount. a) When mounting the foot to solid wood construction, use six 8 mm (5/16-in.) diameter, 25 mm (1-in.) long hex lag screws. b) For hollow wall or roof construction, align the foot so bolts or screws through the center holes will penetrate a stud or rafter whenever possible (see Figure...
- Page 7 ™ Setting the Horizontal or Vertical Polarization RX cable connector Antenna clamp Electronics package Letter H on right side for horizontal polarization AGC port with connector cap Letter V on left and right (location varies) of backplate for vertical polarization TX cable connector Lugbolt Mount and foot...
- Page 8 ™ Installing the Antenna Grounding Wire Warning! 1) The ground wire must be located at least 1.8 m (6 feet) away from lightning rods, or antennas should be bonded to the lightning protection system. 2) Prior to attaching the ground wire, apply a non-oxidizing agent, such as “NO-OX”, to both mating surfaces.
- Page 9 ™ Attaching the Cable to the Mount Use level to make sure top part of mask is vertically level. Use RG-6 or RG-11 cables. Use RG-6 or RG-11 cables. Route RG-6 cables (dotted line) Route RG-11 cables (solid line) up through the mast and out of along the outside of the mast the post clamp at the top.
- Page 10 ™ Connecting the RX Coaxial Cable to the RTU and the NIU Warning! The RX cable carries DC power which under some circumstances is sufficient to cause injury. Stay in back of the transmitter antenna when the transmitter is connected to limit body exposure to RF radiation. Attention Never connect the RX cable to the TX port or the TX cable to the RX port.
- Page 11 18. Recheck all bolts for tightness. 19. Connect the coaxial cable marked TX from the grounding block to the TX port on the RTU. Use a torque of 271 N-cm (24 in-lbs) SpectraPoint Wireless P.O. Box 742466 LISTED Dallas, Texas 75374 Tel: 800-296-4268 I.T .E.
