document version: 1.0.0 - English


WARNING
Read Instruction Manual thoroughly before use and follow all safety
precautions – improper use can cause serious or fatal injury.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.



This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.



Children should be supervised to ensure that they do not play with the appliance during
mowing or while the mowing motor is activate.

The Toadi Order BV, Belgium
Instruction manual
Models: Toadi & Toadi Pro
European instruction manual
Original Instruction
Page
1
of
47

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Toadi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EEVE Toadi

  • Page 1 Instruction manual document version: 1.0.0 - English Models: Toadi & Toadi Pro European instruction manual
 WARNING Read Instruction Manual thoroughly before use and follow all safety precautions – improper use can cause serious or fatal injury. This appliance can be used by children aged from 8 years and above and persons with...

  • Page 2: Table Of Contents

    8.7. Anti-theft alarm 8.8. Safety flaps 9. Installing the worker robot 9.1 Prepare the lawn 9.2 Installing the Toadi app on your smartphone 9.3 Installing the Docking Station 9.4 Setup the digital perimeter 9.4.1 grass border 9.4.2 fixed digital perimeter 10.
  • Page 3 19.2 Toadi Pro 19.3 Docking station 19.4 Symbols used on the worker robot and docking station 19.5 Declaration of Conformity 20. Replacement parts and equipment 21. Disposal 22. Limited Warranty 23. Addresses The Toadi Order BV, Belgium Original Instruction Page...

  • Page 4: Introduction

    1.0.0 - English 1. Introduction Thank you for your purchase. The information contained in this manual will help you receive maximum performance and satisfaction from your Toadi worker robot and, if followed, reduce the risk of injury from its use.
 IMPORTANT
...

  • Page 5: Main Parts

    Instruction manual document version: 1.0.0 - English 2. Main parts 1. Toadi / Toadi Pro Charger station 2. The front screen, containing: • The worker robot’s eyes, one left and one right eye. • The emergency button to disable the device. Located between the eyes, in the middle.

  • Page 6: Safety Symbols

    Installation material
 Docking station stakes, used to secure the docking station. Toadi products must not be disposed of in the household trash, but only in accordance with local, state and federal laws and regulations and as provided in this manual.

  • Page 7: Important Safety Instructions

    The model Toadi Pro is intended for performing surveillance in yards up to approximately 3.6 acre (15.000 m2). • The model Toadi is intended for cutting grass in yards up to approximately 0.6 acre (2400 m2).
 The model Toadi Pro is intended for cutting grass in yards up to approximately 1.02 acre (4.200 m2).

  • Page 8: Personal Operator


 WARNING • According to The Toadi Order’s current information, the electric motor of this worker robot should not interfere with a pacemaker. However, persons with a pacemaker or other implanted medical device should consult their physician and device manufacturer before operating this worker robot.
  • Page 9 — Although certain unauthorised attachments may fit The Toadi Order worker robots, their use may be extremely dangerous. Only attachments supplied by The Toadi Order or expressly approved by The Toadi Order for use with the specific Toadi model are recommended.

  • Page 10: Integrated Battery

    Use of parts that are not authorized or approved by The Toadi Order may cause serious or fatal injury or property damage. The Toadi Order recommends that only identical Toadi replacement parts be used.
  • Page 11 • Although water can be used to put out a battery fire, use of a multi-purpose, dry chemical fire extinguisher is preferable. • Consult the fire department regarding proper disposal of the burned battery. The Toadi Order BV, Belgium Original Instruction Page...

  • Page 12: Using The Worker Robot

    –  Never attempt to modify or override the controls or safety devices in any way. –  If your worker robot or any part is damaged or does not function properly, take it to your authorized Toadi Center Partner. Do not use the worker robot until the problem has been corrected.
  • Page 13 If the vegetation being cut or the surrounding ground is coated with a chemical substance, such as a pesticide, fertilizer or herbicide: Read and follow the instructions and warnings that accompanied the substance coating the vegetation or surrounding ground.
 The Toadi Order BV, Belgium Original Instruction Page...

  • Page 14: Operating Instructions

    (between the eyes of the robot) for 3 seconds until you see OFF The Toadi Order BV, Belgium Original Instruction...
  • Page 15 After disabling the worker robot, inspect the cutting assembly (mowing blade, blade shaft and blade mount). If the unit continues to function abnormally, take it to an authorized Toadi Center Partner for service before restarting and allowing the worker robot to operate.
...

  • Page 16: Docking Station

    Consult a qualified electrician. 12) WARNING: Not for use with receptacles that are weatherproof only when the receptacle is covered (attachment plug cap not inserted and receptacle cover closed). The Toadi Order BV, Belgium Original Instruction Page...

  • Page 17: Warnings And Instructions

    • Read and follow all cautionary markings on the docking station and worker robot and all instructions in this manual before using the docking station. • Use the docking station only for charging the Toadi worker robot. Using the docking station for other purposes is prohibited and may lead to fire, explosion or electric shock, resulting in serious or fatal personal injury and property damage.
  • Page 18 –  Immediately disconnect the power supply from the outlet and prepare to contact the authorities in the event of fire or explosion. –  Have the docking station and power supply inspected and repaired by an authorized Toadi Center Partner before use.

...

  • Page 19: Maintenance, Repair And Storage



 WARNING There are no user-authorized repairs for the worker robot, docking station or power supply. To reduce the risk of fire, electric shock or other personal injury and property damage: The Toadi Order BV, Belgium Original Instruction Page...
  • Page 20 – Replace the mowing blades when it becomes worn or damaged. – Tighten all nuts, bolts and screws after replacing the mowing blades. Use of parts that are not authorized or approved by The Toadi Order may cause serious or fatal injury or property damage.
  • Page 21 –  Store the worker robot only within an ambient temperature range of 32 °F to 122 °F (0 °C to 50 °C).
 SAVE THESE INSTRUCTIONS
 The Toadi Order BV, Belgium Original Instruction Page...

  • Page 22: Operating Principal

    The worker robot is equipped with several devices to help reduce the risk of personal injury or property damage during use. If a safety device has a malfunction, do not operate the worker robot and take the it to an authorized Toadi Center Partner to be repaired.

  • Page 23: Disabling Device

    8.7. Anti-theft alarm The anti-theft alarm is activated when the worker robot is removed from your yard. • An alarm signal sounds (Optional for Toadi’s with serial number below 900). The Toadi Order BV, Belgium Original Instruction Page...

  • Page 24: Safety Flaps

    If you replace the docking station or worker robot after completing the initial setup, you will need to inform your worker robot via the Toadi app on your smartphone before your worker robot will operate again.

  • Page 25: Installing The Docking Station

    Always install the docking station on a stable surface.

 WARNING

 Since the docking station the charging process, do not operate the docking station on a The Toadi Order BV, Belgium Original Instruction Page...
  • Page 26 • The docking station is installed on a flat surface, with minimum 11 square feet or one square meter of flat area in front of the docking station. The flat surface needs to be 0° horizontal flat.

 The Toadi Order BV, Belgium Original Instruction Page...
  • Page 27 • For longer service life, Toadi recommends installing the docking station in a protected, shady location. • For ease of working and to receive the software updates at all times, Toadi recommends installing the docking station in a location with a strong WiFi reception.

  • Page 28: Setup The Digital Perimeter


 WARNING Your worker robot will always drive in a straight line towards you. Be sure there are no obstacles, water, pits or steps higher than 2 cm between you and Toadi. The Toadi Order BV, Belgium Original Instruction Page...

  • Page 29: Grass Border

    fixed digital perimeter we advise you strongly to take 150cm safety margin into account when using the fixed digital perimeter function.
 Please see following video on how to setup the digital perimeter:
 https://www.youtube.com/watch?v=Z6JmY7jyuzc The Toadi Order BV, Belgium Original Instruction Page...

  • Page 30: Charge The Worker Robot

    Instruction manual document version: 1.0.0 - English To activate the fixed digital perimeter function contact the Toadi customer support desk at support@toadi.com 10. Charge the worker robot Read and follow the worker robot and docking station safety precautions and instructions in this manual.

  • Page 31: Active Working Time

    When she detects a person during that timeframe she will capture a photo and send it to the Toadi application on your smartphone. The Toadi application will receive an alert message and ring a notification to you. You will be able to see the picture via your Toadi application.

  • Page 32: Adjusting The Mowing Height

    1.0.0 - English 13. Adjusting the mowing height There are two different Toadi and Toadi Pro versions, one with a manual mowing height adjusting system and one with an electronic mowing height adjusting system, called the Da Vinci’s Pencil. Toadi’s from serial number 600 onwards have the Da Vinci’s Pencil.

  • Page 33: Transporting Your Worker Robot

    Normally, no further conditions have to be met by the user in order to transport this worker robot by road to the operating site. Check and comply with any special regulations that may apply to your situation. The Toadi Order BV, Belgium Original Instruction Page...

  • Page 34: Storing The Worker Robot And The Docking Station

    • Store the worker robot and docking station indoors in a dry and secure location, out of the reach of children and other unauthorized persons. NOTICE
 Charging the battery fully before storage will help prevent damage and prolong its useful life. The Toadi Order BV, Belgium Original Instruction Page...

  • Page 35: Cleaning

    Never use a hose or a pressure washer to clean the worker robot or docking station. Spraying the mower or docking station with water or other liquids could lead to permanent damage. The Toadi Order BV, Belgium Original Instruction Page...

  • Page 36: Inspection And Maintenance

    Never attempt to sharpen the mowing blade. The mowing blade must be replaced when it becomes dull, or every 200 operating hours, whichever occurs first. Toadi recommends having your Toadi's mowing blade replaced by an authorized Toadi Center Partner to reduce the risk of severe or fatal injury from an improperly mounted mowing blade.

  • Page 37: Inspect The Mowing Blades

    • Replace the mowing blade. A reminder will appear in the display. Annually: • Have the worker robot and the docking station inspected and maintained by an authorized Toadi Center Partner after the mowing season ends.
 17.2 Inspect the mowing blades. WARNING The mowing blade has sharp edges.

  • Page 38: Replace The Mowing Blades

    • Mount the new blade. • Use a new fastening screw to fixate the blade. Turn Blade the fastening screw until it is fixated and you cannot turn it Blade anymore with normal force. The Toadi Order BV, Belgium Original Instruction Page...
  • Page 39 Instruction manual document version: 1.0.0 - English The Toadi Order BV, Belgium Original Instruction Page...

  • Page 40: Troubleshooting Guide

    Messages provide information on active errors, faults and recommendations. They are displayed in the application on your smartphone. You will receive a notification for each message. You can view the message on the message wall of your Toadi application. Message Possible cause...

  • Page 41: Worker Robot

    flower bed or grass border. border. stuck in the border. Contact support@toadi.com to capture images from your flowerbed and have Toadi trained to recognise the flowerbed. The worker robot drives your worker robot doesn’t recognise Contact support@toadi.com to over obstacles.

  • Page 42: Eyes

    Your worker robot is A) Show the QR code. searching for:
 A) A QR code incase you are B) Go stand in front-of Toadi, at +- 4 setting up your app / WiFi meter distance. connection. B) You, or a human to follow around the yard to determine the digital perimeter.
  • Page 43 During shutdown you will see OFF in the eyes of Toadi. Once the message has disappeared your worker robot is completely shutdown. The Toadi Order BV, Belgium Original Instruction Page...

  • Page 44: Specifications

    • Protection rating: IPX4 (protected against spraying or splashing water from all directions) • Permissible ambient temperature range during use: 26.6°F to 113°F (-3°C to 45°C). • Permissible ambient temperature range during storage: 32°F to 122°F (0°C to 50°C). The Toadi Order BV, Belgium Original Instruction Page...

  • Page 45: Docking Station

    • Permissible ambient temperature range during storage: 32°F to 122°F (0°C to 50°C). 19.4 Symbols used on the worker robot and docking station The Toadi Order products must not be disposed of in the household trash, but only in accordance with local, state and federal laws and regulations and as provided in this manual.

  • Page 46: Replacement Parts And Equipment

    The Toadi Order recommends the use of genuine Toadi replacement parts. Genuine Toadi parts can be identified by the Toadi part number, the Toadi logo and, in some cases, by the Toadi parts symbol.

  • Page 47: Disposal

    fire or explode.

 Toadi products must not be thrown in household trash or disposed of except as outlined in this manual. • Take the Toadi to an authorized Toadi Center Partner to have its integrated battery removed and recycled.
