Nutfield Technology 3XB User Manual

3-axis
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3XB
3-Axis User Manual
Nutfield Technology, Inc.
1 Wall St., Suite 113
Hudson, NH 03087
USA
91-0017 Rev. E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3XB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nutfield Technology 3XB

  • Page 1 3-Axis User Manual Nutfield Technology, Inc. 1 Wall St., Suite 113 Hudson, NH 03087 91-0017 Rev. E...
  • Page 2 This Page Intentionally Left Blank...

  • Page 3: Table Of Contents

    Table of Contents Copyright Notice Safety Precautions Laser Shutter Installation Installation Safety Requirements Safety Precautions During Usage Introduction Unpacking Setup and Connection Guide Generate the Correction File Mount the 3-Axis Scan Head and Laser Set the Working Distance (Y-Radius) Connect the Scan Controller Start the WaveRunner application.

  • Page 4: Copyright Notice

    Copyright Notice Nutfield Technology, Inc. (NTI) has produced this document for internal use and for use by its licensees, and potential licensees. Use of this document does not grant the user any license or warrantee beyond the terms and conditions set forth in the written contracts and license agreements between Nutfield Technology, Inc.

  • Page 5: Safety Precautions

    You must thoroughly familiarize yourself with all this information before proceeding. The first consideration in a safety analysis is the laser mated to the Nutfield Technology product. The hazard level of the laser is roughly indicated by the Laser Class label that is on the device.

  • Page 6: Laser Shutter Installation

    Nutfield Technology Scanners provide you with the ability to aim the laser beam over a roughly polyhedral (pyramid) volume. The divergence of the focused beam beyond the focal point, which is a function of the lenses selected and their position, can cause radiation to exit the pyramid.

  • Page 7: Installation Safety Requirements

    Using optical instruments with this product increases eye hazard. Safety Precautions During Usage To maintain the necessary safety during usage of Nutfield Technology scanners please take following actions: a. Please avoid any mechanical tension on the interconnection cables.

  • Page 8: Introduction

    This manual covers the installation and use of the 3XB, 3-Axis Scanning System. Nutfield’s 3XB is designed to deliver large field sizes up to 2000mm without the use of large scanning lenses, XY tables, or gantries. These field sizes are achieved while delivering equal to or better, field-size/spot-size ratios then those of standard laser scanning lenses.

  • Page 9: Unpacking

    -3-Axis System -25-Pin XY2-100 interface cable c. Remove the 3XB from the shipping box, and place on a table top; remove the packing material, and the protective plastic bag. d. Remove the cover from the 3XB by removing eight 1.5mm button-head socket cap screws.

  • Page 10: Setup And Connection Guide

    Setup and Connection Guide COVER X-SERVO Y-SERVO Z-SERVO D/A RECEIVER BOARDS (X/Y & Z) 25-PIN XY2-100 X-GALVO INTERFACE 9-PIN POWER CABLE TO +/- 15VDC P.S. INPUT LASER Y-GALVO BEAM X-MIR. Y-MIRROR LINEAR TRANSLATOR FOCUS ADJUST OBJECTIVE LENS OUTPUT BEAM Linear Translator MARKING FIELD Shipping Restraint NOTE:...

  • Page 11: Generate The Correction File

    8.1 Generate the correction file a. Open CorCalcII.exe the Nutfield supplied Correction File Utility. The following screen will appear. In a typical installation, the CorCalcII Installation can be found in the directory string \Scanner Application\Scanner Software\doc\CorCalcII V3.0 Install NOTE: See Appendix A for wavelength specific CorCalcII Input values. b.

  • Page 12: Mount The 3-Axis Scan Head And Laser

    Kinematically mount the 3XB and the laser to a rigid structure MAKING SURE not induce any mechanical distortion to the 3XB or the Laser though the act of fastening the equipment to the structure. b. Install any ancillary components. For example, laser mounts, beam expanders, mechanical shutters, etc.

  • Page 13: Start The Waverunner Application

    Specifications section of this manual for detailed power requirements. a. Confirm the primary power is not connected to the power supply and it is not powered b. Connect the 9-pin power cable to the 3XB’s Power Input connector. 8.6 Start the WaveRunner application.
  • Page 14 f. Click the Advanced Button Under the Optic Tab.

  • Page 15: Focus Adjustment

    In the Mode field, select the appropriate laser type. h. Power ON the 3XB’s +/-15VDC power supply. NOTE: GREEN LEDs will be illuminated on the 3XB’s servo boards. There should be no RED LEDs illuminated, the galvo’s mirrors should be stiff and not be moving.
  • Page 16 e. Rotate the Focus Knob back-and-forth to achieve the brightest plume of light at the work surface. This method of focusing will achieve the most ideal focus taking all system tolerances into consideration. The system should now be ready for use.

  • Page 17: Connections

    Connections NTERFACE SSIGNMENT - SENDCLOCK + SENDCLOCK - SYNC + SYNC - X-DAC CHANNEL + X-DAC CHANNEL - Y-DAC CHANNEL + Y-DAC CHANNEL - Z-DAC CHANNEL + Z-DAC CHANNEL - STATUS RETURN + STATUS RETURN don’t connect don’t connect don’t connect don’t connect don’t connect 25 Pin D-Sub female, XY2-100...

  • Page 18: Specifications

    Select a high quality power supply with good clean DC outputs. Power supplies with excessive ripple or noise will cause scanning problems in your system. The electronics internal to the 3XB have generous output capacitors that supply instantaneous peak current to the output drive amplifiers, and lower the peak output requirements of your system power supply.

  • Page 19: Outline Drawing

    11.0 Outline Drawing...

  • Page 20: Service And Support

    If a product is to be returned to the factory, please go to our web-site: http://www.nutfieldtech.com/nutfield/service.asp and fill out the RMA request form. 14.0 Contact Information Nutfield Technology, Inc. 1 Wall St., Suite 113 Hudson, NH 03087 TEL: 603-893-6200 FAX: 603-893-6214 www.nutfieldtech.com...

  • Page 21: Warranty

    15.0 Warranty Nutfield Technology, Inc. (NTI) warrants this product to be free from defects in materials and workmanship for 12 months from the date of shipment. Nutfield Technology, Inc. will, at its option, repair or replace the product if it is defective within the warranty period and returned, freight pre-paid, to a service center designated by NTI.

  • Page 22: Appendix - A Corcalcii Information

    Appendix A - CorCalcII Information 10mm Aperture, 266nm NOTE: 6.0mm Entrance Beam Required...
  • Page 23 10mm Aperture, 355nm, NOTE: 1.31mm Entrance Beam Required...
  • Page 24 15mm Aperture, 532nm NOTE: 4.0mm Entrance Beam Required...
  • Page 25 30mm Mirror Aperture, 1064nm NOTE: 8.10mm Entrance Beam Required...
  • Page 26 30mm Aperture, 10.6um NOTE: 11.55mm Entrance Beam Required...
  • Page 27 45mm Aperture, 10.6um NOTE: 14mm Entrance Beam Required...

  • Page 28: 30Mm Aperture, Dual Wavelength (532Nm And 1064Nm)

    30mm Aperture, Dual Wavelength, 1 of 2 532nm NOTE: 6.1mm Entrance Beam Required...
  • Page 29 30mm Aperture, Dual Wavelength, 2 of 2 1064nm NOTE: 6.1mm Entrance Beam Required...
  • Page 30 30mm Aperture, 355nm NOTE: 3.5mm Entrance Beam Required...
  • Page 31 30mm Aperture, 532nm NOTE: 6.0mm Entrance Beam Required...

  • Page 32: Appendix - B Typical System Block Diagram

    Appendix B – Typical System Block Diagram Shutter or Mounting Plate Shutter uses 15-24 VDC to open Laser Beam or Fiber Beam XY(Z) Laser Expander Scan head (Optional) +/- 15 volt Power Supply 24 volt Power Supply XY2/100 Data 37pin to Laser Pipeline Controller WaveRunner Software...
