ITEM #814
ALL PURPOSE STEEL GOAL
PREPARATION FOR FRAME ASSEMBLY
• Lay out all parts
• Read instructions completely prior to assembly
• Assemble goal on a smooth, flat surface
• Adult supervision recommened for assembly
TUBING
A. Back and Bottom Crossbars (2)
B. Bottom T-Connector (1)
C.
Sidepieces (2)
D. Bottom Front Upright Posts (2)
E.
Top Front Upright Posts (2)
F.
Top Front Crossbar (1)
G. Back Top Crossbars (2)
H. TopT-Connector (1)
I.
Back Support (1)
HARDWARE/TOOLS
2
Bolts
1
Allen Wrench
NETTING
1
Net
Prior to assembly, remove black protective tube caps.
37 Commercial Drive, Winchendon, MA 01475 — Phone 978-297-0089 — www.mylec.com - Follow us @mylechockey
x 2
x 1
x 2
A
B
C
x 2
x 2
x 1
D
E
F
x 2
x 1
x 1
G
H
I
FRAME
BOLT
E
D
C
(CONTINUED ON BACK)
G
H
G
I
BOLT
E
A
B
A
D
C
Advertisement
Summary of Contents for MYLEC 814
- Page 1 G. Back Top Crossbars (2) H. TopT-Connector (1) Back Support (1) HARDWARE/TOOLS Bolts Allen Wrench NETTING (CONTINUED ON BACK) Prior to assembly, remove black protective tube caps. 37 Commercial Drive, Winchendon, MA 01475 — Phone 978-297-0089 — www.mylec.com - Follow us @mylechockey...
- Page 2 A piece of tube will slide into each sleeve. STEP 1 Lay the net out flat, so the Mylec logo is facing up. Logo area is the top/front of the net. (See net diagram) STEP 2 Starting with the bottom of the goal, insert (A) through white nylonback/bottom sleeve, and connect (A) into bottom T-Connector (B).
