Summary of Contents for JF-Airclean E-BG-06
- Page 1 Directory Producer Health License No.: ZZ (2019) No.0108 Wall-mounted UAD01-type digital atomization disinfection machine Operating manual...
-
Page 2: Table Of Contents
Directory Chapter I overview ………………………………………………………………………….3 1.1 Product name ……………………………………………………………………………………. ………….. 3 1.2 Specification and parameters ……………………………………………………………………… ….…...3 1.3 Equipment appearance and structure………………………………………………………… ……...…4 1.4 Execution Standard ……………………………………………………………………………….….…………..6 1.5 Equipment function introduction ……………………………………………………….…..…………6 1.6.1 working principle …………………………………………………………………………………… ……...6 1.6.2 Scope of application…………………………………………………………………………………………...7 1.6.3 Main functions and features…………………………………………………………………………... -
Page 3: Chapter I Overview
Chapter I Overview 1.1 Product name Wall-mounted digital atomization disinfection machine 1.2 Specification and technical parameters Product model: E-BG-06 Move feature Disinfection function Novel coronavirus, influenza virus, herpes virus, Salmonella atomization Funicide virus, Escherichia coli, Reservoir chamber of + of L (storage... -
Page 4: Equipment Appearance And Structure
Spray Disdisinf Subchlorate is 80-100mg /l; > 5 m distance ectant Spray rate: 50ml/min; Overall size: long General object surface Disinfect Size 454mm* wide 231mm* high disinfection action time is 5 weight 429mm; net weight: minutes, air disinfection action scheme approximately 8.4kg time is 30 minutes The disinfection parameters can be local or remote, one key to start, the... -
Page 6: Execution Standard
1.4 Implement the standards 1.G B 4706.1 — Safety for household and similar appliances — Part 1: General requirements 2. Disinfection Technical Specification, 2002 Edition 1.5 Equipment function introduction The disinfection staff will install the disinfection machine in the supporting disinfection environment area, and measure the spatial volume of the area requiring disinfection. -
Page 7: Scope Of Application
1.6.2 Scope of application This equipment is suitable for air disinfection in hospitals, schools and other public places and indoor homes. 1.6.3 Main functions and their characteristics 1） Start with one button by configdisinfection parameters locally or remotely 2） Enter the room volume to automatically measure the disinfectant time 3）... - Page 8 [Timiming mode] Click the touch button on the device to the timing mode, input the hours and minutes you want disinfection click to start disinfection, the equipment can automatically start the spray work. [Smart Mode] 1, can set the local start time of a single disinfection; 2, can set circular disinfection mode, only daily;...
- Page 9 4, If you need to set up circular disinfection on a day or days of a week (such as weekday disinfection), it can be set on the mobile WeChat small program, which will be automatically synchronized to the local end. [Disinfection Report] The disinfection report can be uploaded to the mobile phone end, and the disinfection start time, disinfection end time and disinfection...
- Page 10 Low water Yellow Low water Reminde Working level flashe buzzer level r of low properly (working rings at reminder water status) interval interface level Low water Yellow None Low water Reminde level flashe level r of low (standby reminder water state) interface level...
-
Page 11: Service Life
1.6.5 Service life The design service life of the whole machine is 3-5 years. 1.6.6 Disdisinfectant description The disinfectant machine uses hypochlorite disinfectant and the validity period is 24 months. In order to ensure the disinfection ability of the disinfectant machine, do not change the disinfectant model at will. -
Page 12: Transport And Storage
1.6.7. Transportation and storage The disinfectant machine and disinfectant shall be stored in dry, clean and well-ventilated warehouses. Stay away from kindling, heat sources, and direct sunlight. Room temperature below 40 °C, relative humidity remains below 75%, pay attention to moisture and rain. Keep the container sealed and note that the label is intact. -
Page 13: Chapter Ii Matters Needing Attention
Chapter II Notes 2.1 When operating the disinfection machine and treating hypochlorite acid, it must follow the instructions in this operation manual.The operator must review all precautions before operating and maintaining the disinfection machine. 2.2. Install this equipment, do not skew and install it horizontally. 2.3 If the power cord is damaged, the manufacturer must be replaced by the repair professionals in order to avoid danger. -
Page 14: Chapter Iii Daily Maintenance
Chapter III Routine Maintenance and Maintenance 3.1. Shutdown Unplug the power plug, unscrew the cover of the drain port and drain the disinfectant of the storage tank and the atomization room, which is located directly below the equipment. (Because the acid is unused for a long time, the effect of hypochlorite is weakened, which will cause mildew and miscellaneous bacteria reproduction) Important:... -
Page 15: Chapter Iv Faults And Solutions
Chapter IV Fault and Solution 4.1. Troubleshooting it Verification corrective Failure / problem measures Check whether the power plug is The disinfection machine properly connected; can not be turned on Check the power supply for power supply. Touch-screen operation Try the power switch to restart the fails terminal. -
Page 16: Chapter V Appendix
Chapter V: The Appendix 5.1. After-sales sales 1） If the product fails during the warranty period, the original quality or production problems, you can get free warranty or replacement. 2） Any fault or damage caused by improper user operation, unauthorized repair or modification, and taking the operation or falling against the use instructions shall not be within the warranty.
