Page 1 Patharity Smart Camera Model ECS1 User Manual 安装...
Page 2: Table Of Contents
Catalogue General descriptions An introduction to data acquisition system General descriptions Log in software system Icon descriptions Page icon descriptions Safety descriptions Auto focus function White balance function Foreword Depth of field overlay Congradulations! Panoramic image stitching function Standard configuration and optional accessories Case list page Instrument overview System update...
Page 3 Catalogue (continued) Care & Maintenance Troubleshooting Care & Maintenance Troubleshooting Spare parts lists Technical specifications ECS1 Dimensions Attention：ECS1 is only used for research purpose. ESC1 User Manual...
Page 4 Version: Chinese V1.0 April 2021 Congratulations on your purchase of the ESC1 Smart Camera, please contact us if you have any questions: info@singularity.ai ECS1 User Manual...
Page 5: General Descriptions
General descriptions General descriptions ECS1 User Manual...
Page 6 General descriptions Maintenance Clean  Repair work can only be performed by  Try to keep all optical components clean. maintenance technicians trained by Qingge Medical.  If there is thick dust on the surface of the optical components, please use a brush to ...
Page 7: Icon Descriptions
Icon descriptions Before using the device, please read and understand this user manual carefully. Important information This icon indicates additional information or explanation. General descriptions ESC1 User Manual...
Page 8: Safety Descriptions
Safety descriptions  If it is not specifically designated for use in diagnostic Place of use procedures, do not use ECS1 or its components for this  The distance between electrical components and purpose. the wall must be greater than 10cm. ...
Page 9: Foreword
Foreword Foreword ESC1 User Manual...
Page 10: Congradulations
• 1080P: 1920 (H) x1080 (V) 2.21MPixel https://live.singularity.ai • 4K: 3840 (H) x2160 (V) 8.85MPixel Or contact our local sales representative to get in • MAX: 4000 (H) x3000 (V) 12MPixel touch.
Page 11: Standard Configuration And Optional Accessories
Standard configuration and optional accessories Accessories 1. USB cable, used to connect the camera and the smart Standard configuration computing box 1. ECS1 Microscope Smart Camera 2. Power cord, used to connect the camera 2. Intelligent computing box 3. Power cord, used to connect smart computing box 4.
Page 12: Instrument Overview
Instrument overview 1. Camera power extension cord jack/power jack 2. USB cable socket, used to connect the camera and the smart computing box 3. Intelligent computing box power jack 4. USB socket, used to connect the camera USB cable 5. Ethernet (Ethernet) CAT-5/CAT-6 wired network interface 6.
Page 13: Assembling
Assembling ESC1用户手册装配...
Page 14 A must for installation! Installing the camera requires basic tools and local network information. Please prepare the following items before starting the installation: 1) The SSID/Password of the local network (network name and password, you should be able to obtain this information from the IT staff).
Page 15: Assembling The Camera
Assembling the camera Assembling The ECS1 camera is connected to the microscope 1. Screw the camera onto the C-mount. through the C-type interface. If you do not have a 2. Screw the camera onto the trinocular head of the microscope suitable interface, please contact our sales using the C-mount from step 1.
Page 16 Assembling the camera The angle of the camera and the adapter on the trinocular head of the screw microscope are very important for the panoramic image stitching function. Please adjust the camera by loosening the screw (the screw is the one that installs the adapter on the trinocular microscope) (see the picture on the right, the camera logo is on the front) ).
Page 17: Assembling Intelligent Computing Box
Assembling intelligent computing box Assembling 1. Use the USB cable to connect the smart box and the camera; 2. Connect the power cord of the smart computing box, and it The smart computing box is the "brain" of will take about 5 minutes to start up for the first run. Please the camera, please place it in a safe and wait for a while.
Page 18 Login collection system After the system is assembled, use your computer to capture images, connect to Wifi empath, and access the camera through a browser to capture images: Visit address: http://10.0.0.1:5000 The initial input user name and password are both admin. Assembling ESC1 User Manual...
Page 19: Setting Up Smart Computing Box Network
Set up smart computing box network (optional) Method 1: Wired network connection When the user needs to use the local external Please insert the network cable into the smart box. network to access the camera, a smart Make sure that the network cable can be connected to computing box network needs to be set up.
Page 20 Set up smart computing box network (optional) Method 2: QR code to quickly set up a wireless network (Wifi) connection If you are using an iphone or other Apple products, 1. Connect to the wifi of the smart computing box: the QR code can be identified by the camera that comes with your device.
Page 21 Set up smart computing box network (optional) Method 2: QR code to quickly set up a wireless network (Wifi) connection (continued) During the setup process, your device is not 2. Connect to the local network: allowed to connect to other networks. After your device is successfully connected to the smart After connecting to the network, please contact box wifi network, scan the following QR code with your...
Page 22 Set up smart computing box network (optional) Method 3: Manually set up the wireless network (Wifi) connection After connecting to the network, please contact 1. Connect smart box wifi: your IT staff to know the IP address assigned to the camera (it is recommended to ask the IT Use your device (mobile phone/computer/tablet) staff to set a fixed IP).
Page 23: Log In Software System
Log in the data acquisition system After setting up the network in any of the above three methods, ask your IT staff to find the IP address assigned to the camera (it is recommended to ask the IT staff to set a fixed IP). After obtaining the IP, use your computer for capturing images, connecting to the network you set up, and accessing the camera through a browser to capture images: Visit address: http://IP:5000...
Page 24 An introduction to the data aquisition system Capture images ESC1 User Manual...
Page 25: Page Icon Descriptions
Page icon descriptions  Case list: display the collected case images  Image acquisition: real-time image acquisition page  Add case: add a new case  Personal Information: Edit user information  Settings: Advanced settings such as system update and restart An introduction to data acquisition system ESC1 User Manual...
Page 26 Page icon descriptions (continued) Add case page • Manage slice types: You can add or delete slice types. • Add case: Fill in the pathology number and slice number of the case, and select the slice type to add a case. An introduction to data acquisition system ESC1 User Manual...
Page 27 Page icon descriptions (continued) Capture image page Name the captured image: • Click the settings icon • Select case: You need to add a case before you can select a case in this position. • Select magnification: refers to the magnification of the microscope objective.
Page 28 Page icon descriptions (continued) Capture image page：  Automatic white balance  Take a picture  Settings  Back to main page  Depth-of-field overlay  Panoramic image stitching sWSI An introduction to data acquisition system ESC1 User Manual...
Page 29: Autofocus Function
Autofocus function Left-click the area you are interested in on the image for autofocus. White balance function modes 1. Click on the white balance icon on the page, the icon starts flashing and enters the white balance state. 2. Left-click the white area of the image as a white reference, at this point you can take a picture.
Page 30: Depth Of Field Overlay
Depth of field overlay 1. Drag to set the interval and number of steps. 2. Click the depth-of-field superimposition icon to take a depth-of-field superimposition image. 3. After the depth-of-field superimposed image is completed, the page prompts to notify that the depth-of-field superimposed image has been completed.
Page 31: Panoramic Image Stitching Function
sWSI (panoramic image stitching function) 1. Click the icon to start panoramic stitching, and slowly Before the panoramic image stitching, adjust the move the field of view under the mirror to stitch. condenser to Koehler illumination: After the sample 2. Left-click the panoramic stitching process map in the upper is focused, the aperture is gradually reduced, and the image in the field of view becomes smaller.
Page 32: Case List Page
Case list page  After the image is collected, click the homepage to return to the case list page.  Left-click on a row of cases to enter the case image viewing page. ESC1 User Manual An introduction to data acquisition system...
Page 33 Case list page  Image viewing page, you can slide the mouse wheel or drag the page scroll bar to view all the images in the case.  Left-click an image to enter the image viewing page. An introduction to data acquisition system ESC1 User Manual...
Page 34: System Update
Syetem update System restart When the software is connected to the Internet, the Click the system restart icon to restart the smart acquisition system can be upgraded by checking the computing box. new version. An introduction to data acquisition system ESC1 User Manual...
Page 35 Care and maintenance ESC1用户手册保养和维护...
Page 36: Care & Maintenance
Care and maintenance Care  Do not disassemble or replace plugs, optical systems,  Try to keep all optical components clean. and mechanical parts, unless specifically permitted and described in the manual.  If there is thick dust on the surface of the optical components, please use a brush to gently remove the dust before wiping.
Page 37 Care and maintenance Dust-proof When the microscope camera is not used for a long  time, please cover it with a dust cover (optional accessory). Or place it in a dust-free place. Service  Repair work can only be performed by maintenance technicians trained by Qingge Medical.
Page 38: Spare Parts Lists
Spare parts Number Qingge Name of spare parts medical item number QGPN-CAUSB USB cable, used to connect the camera and the smart computing box QGPN-CAADAP Power cord, used to connect the camera QGPN-ADAP Power cord, used to connect smart computing box QGPN-5XC C-mount 0.5X interface (optional).
Page 39: Technical Specifications
Technical specifications Technical specifications ESC1 User Manual...
Page 40: Ecs1
ECS1 smart camera Camera Environmental conditions  Weight: 420g (camera only) • Working temperature: 0℃～50℃  Sensor: 1/1.7” (7.53 x 5.64 mm) CMOS type • Working/storage relative humidity: 10%-90%  Maximum resolution: 12MP • Pollution degree 2  Pixel size: 1.85 x 1.85 µm •...
Page 41: Dimensions
Dimensions Unit：mm Technical specifications ESC1 User Manual...
Page 42 Troubleshooting ESC1用户手册故障排除...
Page 43: Troubleshooting
Troubleshooting  When the image acquisition page does not display the field of view under the microscope: Please refresh the page and click the reset all icon. If the view under the lens is still not visible, please restart the camera power extension switch (the camera indicator turns from red to blue to complete the restart), wait five minutes, refresh the page again, and click the reset icon again.
Page 44 Contact Us Singularity, Inc. info@singularity.ai www.singularity.ai 安装...
Page 45 FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
