UV HEPA Air Purifier
BA-02
Owner's
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA-02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Integrum 3D BA-02

  • Page 1 UV HEPA Air Purifier BA-02 Owner’s Manual...
  • Page 2 Hello! Thank you for purchasing the BA-02 HEPA UV Air Purifier. We hope this effective, modern system of cleanliness is just what you have been looking for. Before using the BA-02 HEPA UV Air Purifier, please explore all its features in this manual and on our website.

  • Page 3: Table Of Contents

    Content Unit and Component ..............1 Disinfection Principle and Product Structure ......2 Using Guide ................3 Precautions ................4-5 Operation ................6-7 Disinfection and Purification Function ........8 Technical Parameters ..............9 Cleaning and Maintenance ............10 Troubleshooting ...............11 After-Sales Service ..............12 After-Sales Warranty Card ............13...

  • Page 4: Unit And Component

    Unit and Component BA-02 HEPA Air Purifier Unit High Efficiency UV Resistant Composite Filter Manual Power Cord V e r s i o n A u g 2 0 2 0...

  • Page 5: Disinfection Principle And Product Structure

    2. Disinfection Principle and Product Structure Disinfection Principle This product adopts the form of circulating wind to drive the polluted air into the ultraviolet air purifier. The polluted air then goes through the primary filter, the high efficiency HEPA filter, the UV resistant layer, the high intensity UV sterilization, and lastly anion purification.

  • Page 6: Using Guide

    3. Using Guide V e r s i o n A u g 2 0 2 0...

  • Page 7: Precautions

    4. Precautions Forbidden Disassembly Do not put any foreign matter into Do not disassemble and reform by inlet or outlet to avoid electric non-professionals as to avoid shock and injury. damage and injury. Remove power cord before Do not turn on the UV lamp after cleaning the machine.
  • Page 8 Precautions Continued Do not use this machine under Do not use this machine in high lampblack environments damp environments such as such as the kitchen. Doing so bathrooms. Doing so increases will result in damage to the the chances of electric leakage, product.

  • Page 9: Operation

    5. Operation Turn On Push the touch button to turn on the machine. After Starting up the machine, it will enter automatic mode immediately and will turn on the UV lamp. The icon is always bright after booting up. When the corresponding function is enabled, the text indicator light will be on, the digital area will be displayed with “- - -“...
  • Page 10 Operation Continued Child Lock Function 1. Push “child lock” key to enter the child lock function. A long press for 3 seconds can unlock. 2. Long press “child lock” key for 3 seconds to check out the cumulative working time of filters. The working time will indicate on PM 2.5 digital area, the filter indicator light will be on, and will show four- digital running display.

  • Page 11: Disinfection And Purification Function

    6. Disinfection and Purification Function Physical Filtration of Bacteria and Dust • The dust and bacteria in the air are filtered by physical filtration while the air is sterilized by combining with a high intensity ultraviolet ray. At the same time, the influence of dust on the UV lamp radiation intensity is effectively prevented by the filter.

  • Page 12: Technical Parameters

    7. Technical Parameters Type Detailed Parameters Product Name BA-02 HEPA UV Air Purifier Rated Voltage 110V Rated Frequency 60Hz Rated Input Power UV Lamp Power Ultraviolet Wavelength 253.7nm App Area 538 ft. Disinfection Method UV + Filters (Primary + HEPA)

  • Page 13: Cleaning And Maintenance

    8. Cleaning and Maintenance Main Machine: please wipe the surface of the machine regularly with a damp cloth and a small amount of detergent water. Clean the air inlet and outlet with a brush. UV Lamp: the radiation intensity height of the UV lamp will affect the air disinfection effect.

  • Page 14: Troubleshooting

    9. Troubleshooting Please confirm the faults before sending for maintenance. Below are cases with a list of things the user should check if there is an issue. Abnormal Situation Inspection Items The machine cannot run 1. Check if the power cord is connected to the socket or not.

  • Page 15: After-Sales Service

    After-Sales Service One-Year Warranty and Terms This device comes with a one-year warranty. From the date of purchase the warranty period is one year and the warranty period is free of charge. The following situations are not covered: A. The machine is damaged due to human factors. B.

  • Page 16: After-Sales Warranty Card

    11. After-Sales Warranty Card BA-02 UV Air Purifier Warranty Card Model Warranty Period DD-MM-YY Name Buyer Phone Address Name Seller Phone Address After-Sales 1. Warranty Treaty Service a. From the date of purchase, the warranty period is one Description year, and the warranty period is free of charge.
  • Page 17 It is recommended that you store the manual properly for reference when needed. Note: Due to product updates and replacements, if there is any difference in this manual, refer to the actual product. Company Name: Integrum 3D Address: 1071 N. Batavia Street Orange, CA 92867 14 |...
