EUROKOMAX Ltd.
Address: 1174 Budapest, Orgoványi str. 34. - Hungary
Phone: +36-70-421-77-87
Email:
marketing@eurokomax.hu
INSTRUCTION MANUAL
EUROKOMAX MS650 UNI
Block and Stone Bench Saw (with diamond blade)
WARNING: Please read and understand perfectly the present instruction before
using the machine.
Dear Customer! Thank you for your trust. We are happy you chose to purchase a cutting machine
produced by our company. We hope you will be satisfied with your purchase over a long period of
time.
Please read through all safety warnings and instructions carefully, because any failure to do so may
result in accidents involving serious personal injury. For future reference, please keep this manual in a
safe place. Using the machine for its intended purpose will provide you with long-term trouble free
operation.
Advertisement
Table of Contents
Summary of Contents for EUROKOMAX MS650 UNI
- Page 1 Phone: +36-70-421-77-87 Email: marketing@eurokomax.hu INSTRUCTION MANUAL EUROKOMAX MS650 UNI Block and Stone Bench Saw (with diamond blade) WARNING: Please read and understand perfectly the present instruction before using the machine. Dear Customer! Thank you for your trust. We are happy you chose to purchase a cutting machine produced by our company.
- Page 2 3.) The warranty does not cover any damage caused by the normal wear, undue usage, overloading, inadequate installation or bad conservation of the machine. 4.) All repairs under WARRANTY will solely be effectuated by EUROKOMAX KFT or by its authorised dealers or repair centres.
-
Page 3: General Description
1. General description The MS650 brick cutter is a multi-functional machine used for wet cutting of floor tiles, flagstones, stairs, natural stone, masonry, hollow blocks. The diamond plate is only suitable for cutting bricks, block bricks, concrete and reinforced concrete. When cutting materials other than this, apply for a special diamond plate at our customer service. - Page 4 - The staff should be checked for adherence to the instruction manual and due attention to the risk factors affecting safety. - For safety reasons, long hair should be suitably protected. Closed working clothes should be worn. Wearing jewellery (e.g., rings) should be avoided. Moving parts of the machine present a hazard to persons wearing such items, and may lead to accidents.
- Page 5 - The machine should not be operated by persons under the influence of alcohol or drugs. - Only the operator may be present within the operational range of the machine. - Always disconnect the machine from electricity before installing a blade. - Disconnect the machine from electricity before replacing a used blade, and wait until the blade stops.
- Page 6 - Prevent liquid and greasy substances, especially high temperature liquids, from getting into contact with your skin. In such an event, thoroughly clean the skin to remove such substances. - Follow the safety regulations relating to such substances. - In case of contact with eyes, rinse immediately with plenty of water and seek medical advice. 2.6 Gas, dust, vapour, smoke - Certain processes (soldering, grinding) involving the risk of fire or explosion, as well as jobs requiring the use of open flame, may be performed only in possession of a licence.
- Page 7 - Please make sure to read through the instruction manual before putting the machine into operation. - The MS650 has removable legs. Before commencing work, insert the legs and secure them using the lobe knobs. - The machine can be moved with the wheels on the back legs. Roll the machine on the wheels. - Make sure the machine is placed on a level surface.
-
Page 8: Maintenance
- If the machine gets overheated and switched off, allow the machine to cool off before restarting it (checking the cutting blade and the amount of water is also recommended). 3.3 Starting - Press the green button to start the water pump and the motor. Use the red button to stop them. - Starting up will affect both the water pump and the motor. -
Page 9: Technical Description
5. Technical description 5.1 The frame - The frame is a welded reinforced steel construction which ensures perfect stiffness. The machine is complete with a high capacity water tray, supplied with a drain plug. The frame includes a built-in transporting handle and wheels to assist transportation. 5.2 The cutter - The welded bracket is supplied with a tip shaft, rotating in highly loadable bearings. - Page 10 Technical data of the EUROKOMAX MS650 UNI brick cutting machine: Blade diameter: 650 mm Internal bore diameter: 25.4 mm Cutting depth max.: 270 mm Max. cutting length: 870 mm Motor capacity: 4 kW / 400 V / 50 Hz Machine dimensions : l x w x h...
- Page 11 MANUFACTURER’S DECLARATION...
