BITMINE RIG-V6 Manual

BITMINE
RIG-V6
(rev-05)
Mounted Frame (rev.03) Frame (Rev.04)
ENGLISH MANUAL
CONGRATULATIONS ON YOUR PURCHASE
The product has been specially developed for mining farm needs and made available to the retail sector to
help decentralize mining of
The frame is developed vertically to allow an optimization of the air flow on GPUs as well as a smaller
system footprint and easy transportability.
Heat rising upwards generates a hot air flow that increases and accelerates the air exchange of each GPU
(fireplace effect), also the arrangement of GPUs at the correct distance from each other also allows you to
cool the GPU backplate without having to add additional fans. In the GPU below the backplate is cooled by
the air that rises by convention from the holes in the base.
If you install GPUs with large powers, above 150 watts per GPU, you can add 14 centimeter fans on the
front panel with 9 self-tapping screws (3 per fan).
IMPORTANT: Usually only one fan installed below is sufficient, which cools the
hottest video cards and stabilizes the temperatures of all Mining-Rig GPUs.
PCI- NORMAL RISER OR ANGLE RISER
Angle pci-riser is recommended (illustration 1). Traditional riser pci in some kits
have shorter cables and the last GPU below may have problems with cable length.
In this case it is recommended to use a slightly longer cable, or the new angled riser
kits that are esthetically better and make the wiring more ordered and solid.
Illustration 1:
To connect the last GPU in the bottom with the short reserved and straight PCI-
ANGLE PCI-RISER
Riser cables, the cable must be routed between the 5th and 6th GPUs (see illustration 3).
