Black Dragonfly Agriculture Drone Instruction Book

Drone No.：

Agriculture Drone C-20

Instruction Book

Manufacturer：WENZHOU BLACK DRAGONFLY UAV

TECHNOLOGY CO.,LTD

Address：

Floor 12,Building 1,No.355,Binhai 12th Branch

Road,Economic and Technological Development Zone,Wenzhou

City,Zhejiang Province

Web：http://www.hqtuav.com

Tel/fax：0577-28959998

Instruction Book No. ：

Issue Date ：

Table of Contents

Need help?

Do you have a question about the C-20 and is the answer not in the manual?

Questions and answers

Summary of Contents for BLACK DRAGONFLY C-20

Page 1 Black Dragonfly Agriculture Drone Instruction Book Drone No.： Agriculture Drone C-20 Instruction Book Manufacturer：WENZHOU BLACK DRAGONFLY UAV TECHNOLOGY CO.,LTD Address： Floor 12,Building 1,No.355,Binhai 12th Branch Road,Economic and Technological Development Zone,Wenzhou City,Zhejiang Province Web：http://www.hqtuav.com Tel/fax：0577-28959998 Instruction Book No. ： Issue Date ：...
Page 2 Black Dragonfly Agriculture Drone Instruction Book Warning Black Dragonfly multi-rotor drones are produced and sold by Wenzhou Black Dragonfly UAV Technology Co.,Ltd. The drones can operate in low altitude. But this drone is not a toy even when the drone is empty loading . It is dangerous to be operated by a unprofessional people . The drone is not only controlled by human, but also by kinds radio signal, inductor.we have tried our best to...
Page 3: Table Of Contents
Black Dragonfly Agriculture Drone Instruction Book Content 1) Brief Introduction ..............................1 2) Warning .................................. 1 3) Cautions ................................. 2 4) Operate Instruction ..............................3 5) Mobile app operate steps ............................4 6) Drone Maintainance ............................... 7 7) Transportation ..............................8 8) Battery Maintainance and Cautions ........................
Page 4: Brief Introduction
Black Dragonfly Agriculture Drone Instruction Book 1) Brief Introduction From over years researching in Black Dragonfly drone system and within huge investment , we have got more then 30 patents and own independent property rights. Our flight control use adaptive synovium algorithm,the drones can be one button to fly under bad conditions .The positioning can be accurated to centimeters .
Page 5: Cautions
Black Dragonfly Agriculture Drone Instruction Book 3) Cautions When you are trying to use our drones , please follow below notes: 1、The installation has been be completed by our company , we not allow do it privately.The user open packageds ,spread the wings and put on battery then can use the drone . If you changed motor or paddles , you need check the paddle positive and negative rotation before start flying.
Page 6: Operate Instruction
Black Dragonfly Agriculture Drone Instruction Book 4) Operate Instruction 1、Remote control and the buttons C-20 Remote Control...
Page 7: Mobile App Operate Steps
Black Dragonfly Agriculture Drone Instruction Book 2、C-20 Drone Structures 5) Mobile app working steps 1、connect to bluetooth,initial password is 1234. 2、Register by your real name like picture 1 , details see picture 2, Note：1、you must remember your username and password 2、User type choose flyer...
Page 8 Black Dragonfly Agriculture Drone Instruction Book Picture 2 3、Connect to handle mapping device steps: on right top position，click setting,choose “handle mapping device”in device 3.1、Click this button type , see picture 3. 3.2、Click “unconnected ”on left top position,connect to handle mapping device,then find your handle device name .
Page 9 Black Dragonfly Agriculture Drone Instruction Book 5、Click regional dot start dotting , if there has obstacle , you can set obstacle point after regional dot.see picture6,preserve when you finish, see picture 7. Picture 6 Picture 7 6、Disconnect the device , then start to connect drone , working steps are similar with connect handle mapping device , if you are successful , it will show like picture 8 .
Page 10: Drone Maintainance
Black Dragonfly Agriculture Drone Instruction Book 7、Click “call the work”, call the newest dotted plot,the history dotted plots are in See picture 9,click start work,see picture 10 . Note：longer time , the greater error on map , we need recalibrate map.
Page 11: Transportation
8) Battery Maintenance and Cautions The batteries of Black Dragonfly drones are customized make , we own independent intellectual property rights . Quality is reliable , the power is enough for spray out the full container pesticides. Before charging read instruction book carefully and know very well the cautions.
Page 12 ● Please use the special charging device for Black Dragonfly UAV battery. Do not use any other charger. ● Do not overheat the battery cell at any time.After the temperature of the cell is as high as 60℃, there will be safety risks, or even combustion.
Page 13 Black Dragonfly Agriculture Drone Instruction Book Battery in charging /discharging ● When charging, the battery should not be accessible or placed directly on a flammable material. ● Do not charge unattended, please charge in the temperature of 0-45℃. ● When the drone is operating at low temperature, the battery working time should be reduced to ensure flight safety.
Page 14: Charger Use ,Maintainance And Cautions
Black Dragonfly Agriculture Drone Instruction Book 9) Charger Maintenance and Cautions (1) Parts Name （2) Operation Instruction 1．Start and self inspect Check all the wiring connections－confirm all is right－turn on main switch on charger－LCD screen 和 LED indicators will on light－At the same time, the buzzer is turned on. When the buzzer ends, the charger completes normal startup and self inspection.
Page 15 Black Dragonfly Agriculture Drone Instruction Book automatic charging after connecting for 10 seconds; The red light is always on: it means the charger is charging the battery, and the display screen shows the detailed status of charging in real time;...
Page 16: Flight Control
（4）Charger Maintenance 1, thank you for buying our company's charger, Wenzhou Black Dragonfly UAV Technology Co., Ltd. will do our best to provide you with perfect after-sales service, fully protect your rights and interests, if your products fail, please contact Wenzhou Black Dragonfly UAV Technology Co., Ltd.
Page 17 Black Dragonfly Agriculture Drone Instruction Book Remote Control out of control protection： From the perspective of safety, the current remote control is still irreplaceable for plant protection drone. In order to ensure the safety of drone flight, and for the actual demand of large area self-spraying, the more complete remote control safety protection strategy is designed.
Page 18 Black Dragonfly Agriculture Drone Instruction Book RGB Status Fault Status Instruction All lights are not working Line fault or light fault All lights are on working,but System Halted ground station cannot connect Red light and white light twinkle Initialize Flight Control...
Page 19 Black Dragonfly Agriculture Drone Instruction Book During electrical calibration , it must be in the state of no paddle. The prompt sound of different manufacturers' electric adjustment may be different. Please refer to the manual of electric adjustment. Accelerometer Calibration When our flight control leaves the factory, the acceleration has been calibrated.
Page 20 Black Dragonfly Agriculture Drone Instruction Book Unlock and Lock Unlockable mode: Altitude hold /GNSS assist/position hold mode Lockable mode: Altitude hold /GNSS assist/position hold mode Unlock method： Maximum pitching, minimum throttle volume, heading right full lever, roll left full lever, ；...
