INSTRUCTION MANUAL
SingleCell
v1.0
hall-precision.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SingleCell and is the answer not in the manual?

Questions and answers

Summary of Contents for Hall-Precision SingleCell

  • Page 1 INSTRUCTION MANUAL SingleCell v1.0 hall-precision.com...

  • Page 2: Table Of Contents

    � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � SingleCell v1.0- Instruction manual...

  • Page 3: Introduction

    • Do not overtighten screws! Acrylic can crack especially under the pressure of a screw head. Always use the Washer_v1 with screws when instructed. • We recommend printing the 3D printable files beforehand. • All 3D/FFF files can be found here https://www.hall-precision.com/downloads SingleCell v1.0- Instruction manual...

  • Page 4: Build Of Materials

    3DPrint - Knob Assem 3DPrint - Hinge Assem 3DPrint - Spool Holder Assem 3DPrint - Filter Assem 3D Print - PSU Vent Assem Panel Gasket LED Light Strip 12 x 15”, 8 x 18”, 12 x 22” SingleCell v1.0- Instruction manual...

  • Page 5: Assembly

    Ensure you’re hammering squarely so that the connector is installed straight. c) Trim away any plastic shavings with a utility knife or similar. 2� Install 2x ‘F2’ Single Flange frame pieces onto corner connectors. Ensure flange is facing up. SingleCell v1.0- Instruction manual...
  • Page 6 Assembly 3� Install 2x corner connectors into the Single Flange frame marked ‘F3’ (either one will work, they are the same). 4� Join pieces together. SingleCell v1.0- Instruction manual...
  • Page 7 Assembly 5� Install 2x ‘F4’ pieces (they are the same). 6� Install 1x ‘F5’ and 1x ‘F6’ (has holes for hinges). Ensure holes are facing out. SingleCell v1.0- Instruction manual...
  • Page 8 7� Slide the panels into grooves. They will remain loose until you secure them with panel gasket at a later step. Note the cutout positions. Top View Frame Groove Panel 8� Construct the frame section below. SingleCell v1.0- Instruction manual...
  • Page 9 Assembly 9� Slide ‘Panel Top’ into channel/groove. 10� Construct the frame section below. SingleCell v1.0- Instruction manual...
  • Page 10 You will need to trim to the final length and miter the corners. There are three lengths included, 15”, 18” 22”. Install on both sides of the panels. See example below. Install on both sides of panel SingleCell v1.0- Instruction manual...

  • Page 11: Filter

    2� Press Diverter Flap into Diverter Housing at a 90° angle, and then fold flat. 3� Mount Cartridge Adapter and Filter Diverter assembly onto Panel Top using 4 screws. Some components are hidden to increase clarity. SingleCell v1.0- Instruction manual...
  • Page 12 Assembly 4� Mount Fan onto Panel Top using 4 screws. 5� Install Filter Cartridge by aligning tabs, pressing upwards, and twisting. Align tabs and press up. Twist clockwise to secure. SingleCell v1.0- Instruction manual...

  • Page 13: Grommet

    Assembly Grommet 1� Install PSU Cable Grommet PSU Vent 1� Install PSU Vent. Do not overtighten screws or the panel will crack! Some components hidden to improve clarity. Use 3D printed washers or panel will crack! SingleCell v1.0- Instruction manual...

  • Page 14: Door

    1� Install 2x Hinge Male parts onto Frame ‘F6’ using 4 screws. 2� Peel away the protective mask around the hinge area, and then install 2x Hinge Female parts onto Panel Door using 4 Screws and 4 Washers. SingleCell v1.0- Instruction manual...
  • Page 15 Assembly 3� Mount door to frame by setting the hinge females onto the hinge males. 4� Thread Knob and Knob Insert together. SingleCell v1.0- Instruction manual...
  • Page 16 6� Press this assembly into the Knob Latch to set the magnets. You may need to tap with a hammer to fully seat the magnets. They should be protruding a little bit from either surface to ensure contact. Only gentle force is needed. One magnet will be transferred to the latch. SingleCell v1.0- Instruction manual...
  • Page 17 Thread knob and knob insert together so that they sandwich the panel. Tighten until snug. Top View 8� Install Knob Latch into frame. Press until it snaps into place. Adjust along the frame track until it aligns with the doorknob. Adjust to align withdoorknob. SingleCell v1.0- Instruction manual...

  • Page 18: Spool Holder

    Spool Holder 1� Install bearings into bearing sleeves and then press bearings onto the shafts. 2� Snap Spool Holder mounts onto frame. They can slide the length of the frame to fit just about any spool holder. SingleCell v1.0- Instruction manual...

  • Page 19: Lighting

    Bottom View Integration 1� Set Enclosure over Printer. Run Power cable through grommet and plug into printer. Position printer so that the PSU sits snugly against the PSU vent. SingleCell v1.0- Instruction manual...
  • Page 20 Assembly 2� Load Spool onto Spool Holder and feed through slot in Panel Top to the extruder. 3� Remove any remaining protective film and then see the following guidelines for printing with your new enclosure! SingleCell v1.0- Instruction manual...

  • Page 21: Guidelines For Printing With An Enclosure

    Alternatively, you can leave the fan off until the end of the print and then run it full speed for 10- 30 minutes while the part cools. As mentioned above, the part will continue to smell (emit organic gasses) until it has cooled completely. Email us with any questions, comments, or concerns! matt@hall-precision.com Thank you! SingleCell v1.0- Instruction manual...
