Demedash Effects T-120 Deluxe Videotape Echo v2 Instruction Manual

Trails on/off
Trails - repeats that continue to echo out after you disengage
the effect, can be turned on or off by entering alt mode (by
holding down the 'Engage' footswitch while the effect is
active) and then pressing the 'Tap/Swell' footswitch.
The indicator LED will blink 3 times red if you have toggled
trails ON, or 3 times yellow if you've turned them OFF.
Your selection is saved to memory and will remain the same
even after power-cycling the unit. The factory setting is 'off'.
sTErEo oUTPUT
To utilize the stereo output of the T-120 DLX v2, use a TRS
to dual TS 'Y-Splitter' cable (if the next pedal in your chain
has separate left and right inputs, or if routing to two different
pedals), or a simple TRS cable if the next pedal in the chain
has a TRS stereo input jack.
The stereo output is similar to many stereo chorus pedals
in that it creates a wide depth of field. It does not perform
stereo effects such as ping-ponging, however.
PowEr
9VDC, center-negative 2.1mm adapter required (not
included)
100mA current consumption
No battery compartment.
DEMEDASH
EFFECTS
Made by hand,
Tuned by ear.
Winnipeg, Manitoba, Canada
demedasheffects.com
© 2020 Demedash Effects, all rights reserved
