Owner's Manual
2
DASHCAM M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2 and is the answer not in the manual?

Questions and answers

Related Manuals for AQP M2

Summary of Contents for AQP M2

  • Page 1 Owner’s Manual DASHCAM M...
  • Page 3 English...
  • Page 4 C A M E R D U A L AQP M2 Dash Cam GPS Module 2-Port USB Car Charger Trim Removal Tool Mini USB Charging Cable (10ft) 2*3M Adhesive Mount Happy ? Owner’ s Manual DASHCAM X1 Owner's Manual After sales card...

  • Page 5: Safety Instructions

    Safety Instructions Please read and understand all instructions before using this product. If damage is caused by the failure to follow the instructions, the warranty does not apply. •Keep these instructions. •Do not drop, puncture or disassemble this product. •This product shall not be exposed to dripping or splashing. •Avoid long exposure to direct sunlight, which may cause damage.
  • Page 6 At a Glance C A M E R D U A L Reset button Speaker TF card slot LED indicator Microphone Charging indicator: red, charging is always on, and fully on and off. Camera lens Recording indicator: blue, steady on in preview state.

  • Page 7: Inserting Memory Card

    Inserting Memory Card Do not remove or insert microSD / TF card when this product is powered on, which may damage the card. For reliable operation, use a Class 10 microSD / TF card. For a 64GB/128GB card, format it before using. It is recommended to format the card regularly. Card Capacity 3840*2160 30fps 2560*1440 30fps + 1920*1080 30fps...

  • Page 8: Installing Your Dashcam

    Installing Your DashCam •Never install this product while driving. •Install this product near the rear-view mirror to obtain the best open-field view. Do not install in a location that will obstruct your required driving view. •Make sure that the lens is within the wiping range of the windscreen wiper to ensure a clear view even when it rains.
  • Page 9 Select a location (A or B) on the windshield behind the rear-view mirror, clean with clear water and make it fully dry. Remove 3M adhesive sticker and firmly affix the mount onto the windshield. Use the crowbar to press and hide the charging cable into the seams and weatherstrips around the edge of the dashboard.

  • Page 10: Connecting To Power

    Connecting to Power Connect the car charger and DashCam by using the charging cable. Plug the other end of the car charger to your vehicle’s cigarette lighter socket. C A M E R D U A L Once the car engine is started, DashCam will automatically power on and start recording.
  • Page 11 Downloading AQPCAM App Search "AQPCAM" in App Store or Google Play to Download. Connect DashCam with Smartphone When successfully connecting with your smartphone via built-in Wi-Fi, you can s ave and playback the driving recording videos on your smartphone. You can also change settings of the DashCam via AQPCAM app.

  • Page 12: Using Your Dashcam

    Using Your DashCam As a driver, you have full responsibility to drive safely and adhere to all applicable traffic regulations. Record Videos When connected to a car charger, DashCam automatically starts recording, The red dot on the upper left corner of the screen blinks, the current recording，Upper right corner duration is displayed, and the current date and time is displayed.

  • Page 13: Playback Videos

    Playback Videos The DashCam stops recording while viewing videos or settings. Press the button to pause/start shooting, when the shooting mode is paused, long press the button to enter the photo mode, and long press button again to switch to the playback mode. The playback icon is displayed in the upper left corner of the screen, long press the button again to return to the shooting interface.

  • Page 14: System Setup

    System Setup To adjust DashCam's settings, tap Menu Options Description Available Options Adjusting parameters Video of taking video QHDP30+FHDP30 Resolution Set a desired video resolution. FHD P30+FHD P30 Dual-lens Recording Enable dual lens or single lens Off/On Off/ Set the duration of each Loop Recording 1Minute/3Minutes/5Minutes recording video clip.
  • Page 15 Setup Use WiFi to connect WIFI Off/On Mobile Apps Date/Time Time/date modification YY/MM/DD Time setting of automatic Off/1Minutes/3Minutes/ Auto Power Off shutdown after pausing video 5Minutes The screen turns off automatically, Off/1Minute/3Minutes/ Backlight 5Minutes but will record normally Beep Sound Beep sound setting Off/On Choose the language that...

  • Page 16: Specifications

    Specifications Specifications are subject to change without notice. Screen: 3" IPS (360x640) Camera sensor: Front facing Lens Sony Exmor IMX 307 Rear facing Lens AHD1080P Camera lens: wide-angle lens 170°/150° Chipset: Novatek NT96670 Power input: 5V = 650MA Max video resolution: Front/rear 1080P 30FPS (1920x1080) Video clip format: NTSC/PAL Wi-Fi: 2.4GHz Band Battery capacity: 200mAh...
  • Page 17 Can not record? •Check if the memory card is inserted properly and there is enough free capacity. •Check the battery level. Blurred image? •Use a clean, soft lens-cleaning cloth to gently clean the lens. Malfunction or crash? •Short press the Reset button by using a sharp object to restart the machine.
  • Page 18 Notice This product complies with the radio interference requirements of the European Community.Operating Frequency Range: 2400-2483.5 MHz; Max Output Power: 15 dBm This product is designed and manufactured with high quality materials and components, which can be recycled and reused. This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate collection facility for recycling.
  • Page 19 20cm the radiator your body: Use only the supplied antenna. FCC ID: 2AUAA-M2 Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc., registered in the U.S.
  • Page 20 12-month limited warranty Lifetime technical support Email:aqpsupport@aqpcam.com...
