Orange-Casual
3-Pieces
Conversation Set
sku:OC-WK-022
1
Thank you for choosing Orange-Casual!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it Immediately. Send us an email at
help@orange-casual.com.
If you are not satisfied with our
customer service, pls send your comments to
complaint@orange-casual.com.
Happy?
Please leave us a review!
You can make others happy too!
Advertisement
Related Manuals for Orange-Casual OC-WK-022
Summary of Contents for Orange-Casual OC-WK-022
- Page 1 Orange-Casual 3-Pieces Conversation Set sku:OC-WK-022 Thank you for choosing Orange-Casual! Our goal is to provide high quality outdoor furniture with outstanding customer service-all at an affordable price. Please let us know how we are doing! Problems? (Missing pieces, wrong pieces...) We will fix it Immediately.
-
Page 2: At The End Of The Season
Orange-Casual IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Safety For domestic use only. Don't tighten all the bolts before the product is fully assembled. It would be useful to ask someone to help you assemble the product. - Page 3 Orange-Casual Tips for Cushions In order to compress the package, we put the cushions in the gap of some parts. So there may be crinkle on the fabric. Don’t worry. Just flap every corner of the cushion evenly and it will get back into its original shape soon.
-
Page 4: E Back Cushion
Orange-Casual COMPONENT LIST - ARMCHAIR Item Reference Description Qty. Image Right Armrest Left Armrest Seat Base Seat Back Back Cushion Seat Cushion Washer M6X30 Head Cap Screws Allen Key - 3 -... - Page 5 Orange-Casual NOTE: When tightening the screws, tighten sequentially. DO NOT tighten any screws fully and then move on to the next one. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned,loosen the screws and execute this same process.
- Page 6 Orange-Casual Attach the Left Armrest (B) to the Seat Back (D) and Seat Base (C) by securing with Head cap screws (H) and Washers (G). Do this in 4 places. Then tighten all 8 screws into place with Allen Key (J).
- Page 7 Orange-Casual COMPONENT LIST - ARMLESS CHAIR Item Reference Description Qty. Image Right Panel Left Panel Seat Back Seat Base Bottom Panel Back Cushion Seat Cushion Washer - 6 -...
- Page 8 Orange-Casual COMPONENT LIST - ARMLESS CHAIR Item Reference Description Qty. Image M6X30 Head Cap Screws Allen Key NOTE: When tightening the screws, tighten sequentially. DO NOT tighten any screws fully and then move on to the next one. This may cause the frame to warp.
- Page 9 Orange-Casual Attach the Seat Base (N) to the Panels (K)& (L) and Seat Back (M) by securing with Head cap screws (H) and Washers (G). Hand tighten to line up all the pieces. Pls don’t fully tighten in this step. Do this in 4 places.
- Page 10 Orange-Casual Attach the Bottom Panel (O) to the Panels (K)& (L) by securing with Head capscrews (H) and Washers (G). Hand tighten to line up all the pieces. Do this in 4 places. Then Pls don’t fully tighten in this step.
- Page 11 Orange-Casual COMPONENT LIST - ARMLESS CHAIR Item Reference Description Qty. Image Table Leg Table Top Glass Washer M6X15 Head Cap Screws M6X30 Head Cap Screws Allen Key - 10 -...
- Page 12 Orange-Casual NOTE: When tightening the screws, tighten sequentially. DO NOT tighten any screws fully and then move on to the next one. This may cause the frame to warp. If there is still wobbles or screw holes cannot be aligned,loosen the screws and execute this same process.
- Page 13 Orange-Casual Place the table on a level surface, then place the Glass (S) on the table. Your table is ready for use. - 12 -...
